title Executing Tools
image https://og.composio.dev/api/og?title=Executing%20Tools
keywords
subtitle Learn how to execute Composio's tools with different providers and frameworks
hide-nav-links false

Tool calling is a feature of all frontier LLMs to allow them to interact with the outside world. Earlier you might be able to ask an LLM to write you a nice email, but you would have to manually send it. With tool calling, you can now provide an LLM a valid tools for example, GMAIL_SEND_EMAIL to go and accomplish the task autonomously.

Using Chat Completions

For non-agent providers—such as OpenAI, Anthropic, and Google AI—you can process tool calls using the tool call handlers provided by the Composio SDK. This approach works consistently across all supported non-agent providers.

To learn how to setup these providers, see Providers.

```typescript TypeScript (Anthropic) maxLines=60 import { Composio } from "@composio/core"; import { AnthropicProvider } from "@composio/anthropic";

const userId = "user@acme.com"; // User's UUID

const anthropic = new Anthropic(); const composio = new Composio({ apiKey: process.env.COMPOSIO_API_KEY, provider: new AnthropicProvider(), });

const tools = await composio.tools.get(userId, { tools: ["GITHUB_GET_THE_ZEN_OF_GITHUB"], });

const msg = await anthropic.messages.create({ model: "claude-3-7-sonnet-latest", tools: tools, messages: [ { role: "user", content: "gimme me some zen!!", }, ], max_tokens: 1024, });

const result = await composio.provider.handleToolCalls(userId, msg); console.log(result);


```python Python (Google) maxLines=60
import anthropic

from composio import Composio
from composio_anthropic import AnthropicProvider


# Initialize tools.
anthropic_client = anthropic.Anthropic()
composio = Composio(provider=AnthropicProvider())

# Get GitHub tools that are pre-configured
tools = composio.tools.get(user_id="default", tools=["GITHUB_GET_THE_ZEN_OF_GITHUB"])

# Get response from the LLM
response = anthropic_client.messages.create(
    model="claude-3-opus-20240229",
    max_tokens=1024,
    tools=tools,
    messages=[
        {"role": "user", "content": "gimme me some zen"},
    ],
)

# Execute the function calls.
result = composio.provider.handle_tool_calls(user_id="default", response=response)
print(result)

Using Agentic Frameworks

Composio also has first-party support for agentic frameworks which execute tools, feed the result to the LLM and continue the conversation.

Here, the tool execution is handled by the agentic framework. Composio makes sure the tools are formatted into the correct objects for the agentic framework to execute. ```typescript TypeScript (Vercel) maxLines=60 wordWrap import { Composio } from "@composio/core"; import { generateText } from "ai"; import { anthropic } from "@ai-sdk/anthropic"; import { VercelProvider } from "@composio/vercel";

const userId = "0000";

const composio = new Composio({ apiKey: process.env.COMPOSIO_API_KEY, provider: new VercelProvider(), });

const tools = await composio.tools.get(userId, { toolkits: ["LINEAR"], limit: 15, });

const { text } = await generateText({ model: anthropic("claude-3-7-sonnet-20250219"), messages: [ { role: "user", content: "Fetch all my projects", }, ], tools, maxSteps: 5, });

console.log(text);


```python Python (OpenAI Agents SDK)maxLines=60 wordWrap
import asyncio
from agents import Agent, Runner
from composio import Composio
from composio_openai_agents import OpenAIAgentsProvider

user_id = "0000"

# Initialize Composio toolset
composio = Composio(provider=OpenAIAgentsProvider())

# Get all the tools
tools = composio.tools.get(
    user_id=user_id,
    tools=["GITHUB_STAR_A_REPOSITORY_FOR_THE_AUTHENTICATED_USER"],
)

# Create an agent with the tools
agent = Agent(
    name="GitHub Agent",
    instructions="You are a helpful assistant.",
    tools=tools,
)

# Run the agent
async def main():
    result = await Runner.run(
        starting_agent=agent,
        input=(
            "Star the repository composiohq/composio on GitHub."
        ),
    )
    print(result.final_output)

asyncio.run(main())

Tools are scoped to a user

Each tool and tool action is scoped to a user. Hence, a user_id is required to fetch and execute tools.

The authentication state is checked and used while fetching and executing a tool.

You need to authorize the user to execute tools. For more information on authentication, see Authenticating Tools.

For Humans (deterministic tool calling)

In case you just want to call a tool manually -- not using any framework or LLM provider, you can do so using the execute method.

```typescript TypeScript maxLines=60 wordWrap const userId = "user@example.com"; const composio = new Composio();

const result = await composio.tools.execute("HACKERNEWS_GET_USER", { userId, arguments: { username: "pg", }, }); console.log(result);


```python Python maxLines=60 wordWrap

user_id = "user@example.com"
composio = Composio()

result = composio.tools.execute(
    "HACKERNEWS_GET_USER",
    user_id=user_id,
    arguments={"username": "pg"}
)
print(result)

Proxy Execute -- Manually calling toolkit APIs

You can also proxy requests to an API of any supported toolkit. This is useful when you want to manually call an API of a toolkit and inject the authentication state from Composio.

```typescript TypeScript maxLines=60 wordWrap // Send a custom request to a toolkit const { data } = await composio.tools.proxyExecute({ toolkitSlug: 'github', userId: 'user@example.com', data: { endpoint: '/repos/owner/repo/issues', method: 'GET' } }); console.log(data); ``` ```python Python maxLines=60 wordWrap response = composio.tools.proxy( endpoint="/repos//issues/1", method="GET", connected_account_id="ac_1234", # use connected account for github parameters=[ { "name": "Accept", "value": "application/vnd.github.v3+json", "type": "header", }, ], ) ```

If you're interested in extending toolkits and creating custom tools, see Custom tools.

Automatic File Handling

Composio SDK includes automatic file handling for tools that work with files. When enabled (default), the SDK automatically handles file uploads and downloads during tool execution.

File Upload

When a tool accepts file inputs (marked with file_uploadable: true), you can pass local file paths or URLs. Here's an example using Google Drive upload:

```typescript TypeScript maxLines=60 wordWrap import { Composio } from '@composio/core'; import path from 'path';

const composio = new Composio({ apiKey: process.env.COMPOSIO_API_KEY });

// Upload a local file to Google Drive const result = await composio.tools.execute('GOOGLEDRIVE_UPLOAD_FILE', { userId: 'default', arguments: { file_to_upload: path.join(__dirname, 'document.pdf') // Local file path } });

console.log(result.data); // Contains Google Drive file details


```python Python maxLines=60 wordWrap
import os

from composio import Composio

composio = Composio()

# Upload a local file to Google Drive
result = composio.tools.execute(
    "GOOGLEDRIVE_UPLOAD_FILE",
    user_id="default",
    arguments={
        "file_to_upload": os.path.join(os.getcwd(), "document.pdf")  # Local file path
    }
)

print(result.data)  # Contains Google Drive file details

The SDK automatically:

  1. Reads the file content
  2. Uploads it to secure storage
  3. Passes the file metadata to the tool

File Download

When a tool returns file outputs, the SDK automatically:

  1. Downloads the file to a local temporary directory
  2. Provides the local file path in the response
```typescript TypeScript maxLines=60 wordWrap // Download a file from Google Drive const result = await composio.tools.execute('GOOGLEDRIVE_DOWNLOAD_FILE', { userId: 'default', arguments: { file_id: 'your_file_id' } });

// Result includes local file path console.log(result.data.file.uri); // "/path/to/downloaded/file.pdf"


```python Python maxLines=60 wordWrap
# Download a file from Google Drive
result = composio.tools.execute(
    "GOOGLEDRIVE_DOWNLOAD_FILE",
    user_id="default",
    arguments={
        "file_id": "your_file_id"
    }
)

# Result includes local file path
print(result.data["file"])  # "/path/to/downloaded/file.pdf"

Disabling Auto File Handling

You can disable automatic file handling when initializing the Typescript SDK:

```typescript TypeScript maxLines=60 wordWrap const composio = new Composio({ apiKey: process.env.COMPOSIO_API_KEY, autoUploadDownloadFiles: false });

// Now you need to handle files manually using composio.files API const fileData = await composio.files.upload({ filePath: path.join(__dirname, 'document.pdf'), toolSlug: 'GOOGLEDRIVE_UPLOAD_FILE', toolkitSlug: 'googledrive' });

</CodeGroup>

For more details on file handling, see [Auto Upload and Download Files](/docs/advanced/auto-upload-download).
