feat(video): Monitoring with Prometheus and Kubernets

Author: timothystewart6

_posts/2022-07-23-kube-grafana-prometheus.md

@@ -0,0 +1,196 @@
+---
+layout: post
+title: "Monitoring & Beautiful Dashboards with Grafana and Prometheus on Kubernetes"
+date: 2022-07-23 10:00:00 -0500
+categories: kubernetes
+tags: kubernetes grafana prometheus alert-manager k3s
+---
+
+[![Beautiful Dashboards & Monitoring - Grafana and Prometheus Kubernetes Tutorial](https://img.youtube.com/vi/fzny5uUaAeY/0.jpg)](https://www.youtube.com/watch?v=fzny5uUaAeY "Beautiful Dashboards & Monitoring - Grafana and Prometheus Kubernetes Tutorial")
+
+If I could start my HomeLab all over, what would I choose?  Would I choose the same servers, rack, networking, gateway, switch, firewall, my pc conversion, and even my disk shelf NAS?  Did I make a good choice or a bad one?  Join me as we give each piece of my HomeLab a Keep or Upgrade rating.
+
+📺 [Watch Video](https://www.youtube.com/watch?v=fzny5uUaAeY)
+
+A HUGE thanks to Datree for sponsoring this video!
+
+Combat misconfigurations. Empower engineers.
+
+<https://www.datree.io>
+
+## Getting Started
+
+If you need to install a new kubernetes cluster you can use my [Ansible Playbook](https://docs.technotim.live/posts/k3s-etcd-ansible/) to install one.
+
+### k3s
+
+If you want to get metrics from your k3s servers, you will need to provide some additional flags to k3s.
+
+Additional k3s flags used in the video:
+
+```yml
+extra_server_args: "--no-deploy servicelb --no-deploy traefik --kube-controller-manager-arg bind-address=0.0.0.0 --kube-proxy-arg metrics-bind-address=0.0.0.0 --kube-scheduler-arg bind-address=0.0.0.0 --etcd-expose-metrics true --kubelet-arg containerd=/run/k3s/containerd/containerd.sock"
+```
+
+### helm
+
+```bash
+curl -fsSL -o get_helm.sh https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3
+chmod 700 get_helm.sh
+./get_helm.sh
+```
+
+Install helm
+
+The helm chart we will be using to install Grafana, Preometheus, and Alert Manager is [kube-prometheus-stack](https://github.com/prometheus-community/helm-charts/tree/main/charts/kube-prometheus-stack)
+
+## Installing
+
+Verify you can communicate with your cluster
+
+```bash
+kubectl get nodes
+```
+
+```console
+NAME     STATUS   ROLES                       AGE   VERSION
+k3s-01   Ready    control-plane,etcd,master   10h   v1.23.4+k3s1
+k3s-02   Ready    control-plane,etcd,master   10h   v1.23.4+k3s1
+k3s-03   Ready    control-plane,etcd,master   10h   v1.23.4+k3s1
+k3s-04   Ready    <none>                      10h   v1.23.4+k3s1
+k3s-05   Ready    <none>                      10h   v1.23.4+k3s1
+```
+
+Verify helm is installed
+
+```bash
+helm version
+```
+
+```console
+version.BuildInfo{Version:"v3.8.0", GitCommit:"d14138609b01886f544b2025f5000351c9eb092e", GitTreeState:"clean", GoVersion:"go1.17.5"}
+```
+
+Add helm repo
+
+```bash
+helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
+```
+
+Update repo
+
+```bash
+helm repo update
+
+```
+
+Create a Kubernetes Namespace
+
+```bash
+kubectl create namespace monitoring
+```
+
+Echo username and password to a file
+
+```bash
+echo -n 'adminuser' > ./admin-user # change your username
+echo -n 'p@ssword!' > ./admin-password # change your password
+```
+
+Create a Kubernetes Secret
+
+```bash
+ kubectl create secret generic grafana-admin-credentials --from-file=./admin-user --from-file=admin-password -n monitoring
+```
+
+You should see
+
+```console
+secret/grafana-admin-credentials created
+```
+
+Verify your secret
+
+```bash
+kubectl describe secret -n monitoring grafana-admin-credentials
+```
+
+You should see
+
+```console
+Name:         grafana-admin-credentials
+Namespace:    monitoring
+Labels:       <none>
+Annotations:  <none>
+
+Type:  Opaque
+
+Data
+====
+admin-password:  9 bytes
+admin-user:      9 bytes
+```
+
+Verify the username
+
+```bash
+kubectl get secret -n monitoring grafana-admin-credentials -o jsonpath="{.data.admin-user}" | base64 --decode
+```
+
+You should see
+
+```console
+adminuser%
+```
+
+Verify password
+
+```bash
+kubectl get secret -n monitoring grafana-admin-credentials -o jsonpath="{.data.admin-password}" | base64 --decode
+```
+
+```console
+p@ssword!%
+```
+
+Remove username and password file from filesystem
+
+```bash
+rm admin-user && rm admin-password
+```
+
+Create a values file to hold our helm values
+
+```bash
+nano values.yml
+```
+
+paste in values from [here](https://github.com/techno-tim/launchpad/tree/master/kubernetes/kube-prometheus-stack)
+
+Create our kube-prometheus-stack
+
+```bash
+helm install -n monitoring prometheus prometheus-community/kube-prometheus-stack -f values.yaml
+```
+
+Port Forwarding Grafana UI
+
+(be sure to change the pod name to one that matches yours)
+
+```bash
+kubectl port-forward -n monitoring grafana-fcc55c57f-fhjfr 52222:3000
+```
+
+Visit Grafana
+
+<http://localhost:52222>
+
+Examples:
+
+[Traefik Ingress example](https://github.com/techno-tim/launchpad/tree/master/kubernetes/kube-prometheus-stack)
+
