LLM-D Architectural Views: Inference Scheduler

Last Update: 2026-03-09

This document contains select component-level (i.e. low-level) architectural views such as UML sequence diagrams (to document certain interesting behaviors) and UML class diagrams pertaining to the LLM-D Inference Scheduler, which extends the Gateway API Inference Extension a.k.a. GIE or IGW. The Inference Scheduler implements optimized request routing logic that leverages dissagregated Prefill-Decode (PD) inference cluster topologies.

For high-level architectural views, consult the repos that this document references, as well as this excellent video by Robert Shaw presenting a technical overview of LLM-D's features:

LLM-D overview (YouTube)

Executive summary

  • Purpose: provide a concise, developer-focused reference tying configuration to runtime behavior so contributors can find where to implement new scheduling logic.
  • Scope: explains extension points (PrepareData, Filter, Scorer, ProfileHandler, PreRequest), the scheduling lifecycle (Prepare → Filter → Score → Pick → PreRequest/Response), and common plugin implementations with direct links to source files.
  • Deliverables: UML class/sequence diagrams, per-plugin examples and appendices, and configuration-to-runtime mapping to speed discovery and safe changes.
  • Use: read this first to decide the correct extension point and then follow the linked factories and files to implement or register plugins.

Limitations

  • Not exhaustive: this document does not attempt to list every plugin, interface, or runtime behavior across the repository or upstream dependencies — omissions are expected.
  • Work in progress: content, examples, and links may change; treat this as a living reference and open issues/PRs for corrections or additions.
  • Focus: the document concentrates on the LLM-D Inference Scheduler and scheduler-related extension points; other components are referenced but not comprehensively documented here.

Initialization sequence

Upon startin, the EPP performs the following intialization sequence:

Initialization Sequence

Director (per-request) sequence

At the heart of the EPP (which extends the Gateway API Inference Extension) is the Director, which is responsible for managing the lifecycle of incoming inference requests. This section describes the key classifiers and shows theire collaboration via a UML sequence diagram:

  • Director: request orchestration and plugin invocation.

    • Orchestrates the entire per-request lifecycle: accepts reqCtx, fetches the InferenceObjective, and sets defaults (priority, timeouts) when none is present. The InferenceObjective is a lightweight policy object (target model/profile, priority, placement hints, and tags) usually supplied by the request originator, an API/adapter, or by operator configuration and persisted in the Datastore. Plugins consult the InferenceObjective to influence behavior.

    • Calls the admission controller (Admit(...)) to allow or deny requests early, preventing unnecessary work for denied requests.

    • Uses contracts.PodLocator to discover candidate pods and converts them into scheduler endpoints.

    • Runs PrepareDataPlugin implementations to enrich or decorate the LLMRequest before scheduling based on InferenceObjective fields (preferred model, profile, or request-level hints); failures/timeouts are logged and treated fail-open. These plugins receive the LLMRequest and candidate endpoints, may mutate or attach metadata, and should avoid blocking indefinitely. Notable upstream/framework PrepareDataPlugin implementations referenced or used by the scheduler:

    • prefix prepare plugin (hashes the prompt and attaches longest-prefix match info to endpoints; see Appendix G)

    • predicted-latency prepare hooks (prepares SLO context and predictions used by latency-aware scoring; see Appendix H)

    • Runs AdmissionPlugin evaluates InferenceObjective constraints (priority, tenancy, policy) and can allow/deny a request (return nil to allow, non-nil error to deny). Admission plugins evaluate the LLMRequest and endpoints and return allow/deny with optional reasons.

    • Runs the Scheduler, which runs the concrete Filter + Scorer pipeline to apply objective preferences when ranking or excluding endpoints (e.g., prefer specific profiles or locality). The Filter and Scorer interfaces are declared here; examples live in pkg/plugins/filter and pkg/plugins/scorer. See the Scheduler (interface) and its concrete implementation.

    • Runs the Scheduler to pick a TargetPod/endpoint and returns a SchedulingResult used to prepare the outgoing request.

    • Executes PreRequest plugins to finalize headers, routing, or authentication and then returns a populated reqCtx to the handler.

    • On response paths, invokes response plugins for received, streaming, and complete events (for logging, metrics, or post-processing). Response plugins handle response events (received, streaming chunks, completion) and can transform, log, or emit metrics.

    • Exposes helper utilities used across flows (model rewrites, weighted model selection, metric conversion, random endpoint selection).

  • Scheduling types (dependency): https://github.com/kubernetes-sigs/gateway-api-inference-extension/blob/master/pkg/epp/framework/interface/scheduling/types.go — LLMRequest.

    • LLMRequest: canonical request model carrying payload, model id, metadata, priority, and timeouts passed to plugins and scheduler.
    • SchedulingResult: encapsulates the chosen pod/endpoint, scoring details, rewrites, and routing hints the Director uses to prepare the outbound request.

  • Pod locator / Scheduler: contracts.PodLocator (see Director) and scheduler implementations under pkg/scheduling/pd.

    • contracts.PodLocator: abstract discovery API used to list candidate pods matching request metadata (model, labels, locality).
    • Scheduler implementations convert discovered pods to endpoints, apply filters and scorers, and run selection algorithms.
    • The scheduling pipeline uses filter and scorer plugins (and may apply weighted-model selection or rewrite rules) to return the best endpoint(s).

  • Prepare/PreRequest/Admission/Response plugin implementations in the llm-d-inference-scheduler repo: pkg/plugins/pre-request/pd_prerequest.go, scorer plugins under pkg/plugins/scorer, filter plugins under [pkg/plugins/filter], and profile/PD deciders under [pkg/plugins/profile].

Director Sequence

Scheduler sequence

  • The Scheduler is responsible for converting candidate endpoints into a ranked/filtered selection suitable for routing. It is driven by two concepts:

  • SchedulerProfile (see Appendix I): a per-profile configuration that lists:

  • ProfileHandler: a single plugin instance per Scheduler that decides, for each scheduling cycle, which profiles should run (the Pick extension point) and how to consolidate their results into a final SchedulingResult (the ProcessResults extension point). Examples and implementations live under pkg/plugins/profile (notably the PD-aware handler pd_profile_handler.go).

Key behaviors (from the code):

  • The Scheduler.Schedule(...) loop repeatedly calls the configured ProfileHandler.Pick(...) to obtain a set of SchedulerProfile objects to run for this cycle. The loop continues until Pick returns an empty map.
  • For each selected profile the Scheduler calls profile.Run(...). Run executes the profile's plugins in strict order: Filters -> Scorers -> Picker. If filters remove all endpoints the profile run returns an error.
  • Filter plugins prune or mutate candidate endpoints before scoring. If all endpoints are removed the profile run fails and its result is recorded as nil (the ProfileHandler sees this in profileResults).
  • Scorer plugins return per-endpoint scores (normalized to [0,1]). The profile accumulates weighted scores across scorers using WeightedScorer weight values.
  • The Picker plugin selects the final endpoint(s) (one or more) from the scored candidates.
  • After all selected profiles have run, the Scheduler calls ProfileHandler.ProcessResults(...) to aggregate profile outputs and pick the PrimaryProfileName (which determines the default target endpoint used by the Director).
  • The scheduler records plugin latencies and an overall scheduler E2E latency metric.

PD (Disaggregated Prefill‑Decode) notes:

  • The PD-aware PdProfileHandler drives decode-first logic: it instructs the Scheduler to always run a decode profile first (so decode endpoints are located/scored), then decides whether to run a prefill profile based on a pdDecider plugin and the decode run results (see pkg/plugins/profile/pd_profile_handler.go).
  • ProcessResults in the PD handler will transform decode results into a Data‑Parallel form when primaryPort is configured (it rewrites endpoint metadata ports and populates a header with the decode pod for subsequent PreRequest handling). When prefill also ran, ProcessResults includes both profile results in the returned SchedulingResult.

Scheduler Sequence

Datastore Sequences (initialization, update, read)

This sequence shows how the EPP creates and populates the Datastore at startup and incrementally via pod watches. This behavior is implemented in the IGW, which the Inference Scheduler inherits.

  • Created at startup: Runner calls datastore.NewDatastore(ctx, epFactory, ...) to allocate internal maps and wire an EndpointFactory. See cmd/epp/runner/runner.go and pkg/epp/datastore/datastore.go.

  • Pool bootstrap (full resync): InferencePoolReconciler calls Datastore.PoolSet(...); PoolSet stores the pool and runs podResyncAll(...) which list pods via the controller reader and seeds the store via PodUpdateOrAddIfNotExist(...) for ready pods.

  • Pod watch updates: PodReconciler receives pod create/update/delete events filtered by pool selector and calls PodUpdateOrAddIfNotExist(...) (for ready/matching pods) or PodDelete(...) (for removed/not-ready pods). See pkg/epp/controller/pod_reconciler.go.

  • Endpoint creation & lifecycle: PodUpdateOrAddIfNotExist builds EndpointMetadata per target port and either creates endpoints via EndpointFactory.NewEndpoint(...) or updates an existing endpoint's metadata (ep.UpdateMetadata(...)). EndpointFactory starts per-endpoint collectors; ReleaseEndpoint tears them down on deletion. See pkg/epp/datastore/datastore.go and pkg/epp/datalayer/factory.go.

  • Querying: Runtime consumers (e.g., requestcontrol.PodLocator) call Datastore.PodList(predicate) to obtain candidate endpoints. PodList iterates the internal map and returns a slice of endpoints matching the predicate. See pkg/epp/requestcontrol/locator.go and PodList in pkg/epp/datastore/datastore.go.

Datastore Initialization Diagram

Class diagram (focused on Inference Scheduler)

Configuration model and class diagram

Appendix A — pkg/plugins/filter/by_label.go

  • Configuration: label (the label key to check), validValues (array of acceptable label values), and allowsNoLabel (boolean; if true endpoints missing the label are included).
  • Factory validation: the plugin factory validates name and label at startup and requires either validValues be non-empty or allowsNoLabel=true to avoid accidental exclusion of all endpoints.
  • Runtime behavior: the filter returns endpoints whose Metadata.Labels[label] is present in validValues. Endpoints missing the label are included only when allowsNoLabel=true. If the filter excludes all endpoints the scheduler will receive an empty candidate set unless other filters or fallback logic add candidates.
  • When to use: simple, single-dimension routing like model-version/profile routing, release tagging (release=canary), role-based placement (role=pd), or lightweight operational isolation. Use when you only need to check one label key and prefer a compact configuration over a full selector expression.
  • Interaction: less expressive than by_label_selector (which supports multi-key and set-based selectors). Combine by_label with scorers or broader filters when you want to prefer or restrict by a single key while still allowing fallbacks.
  • Caution: incorrect validValues or forgetting to set allowsNoLabel during migrations can unintentionally exclude endpoints—test configurations and prefer gradual rollouts.

Use Case: Canary Deployment

  • Goal: route a small percentage of incoming requests to an EPP variant that has the by_label filter enabled (canary), while sending the remainder to a primary EPP without that filter.

  • Two practical Envoy approaches:

  • Weighted-cluster split (simple, no custom sampling)

    # route: split 90/10 between primary and canary EPP services
match:
    prefix: "/"
route:
    weighted_clusters:
        clusters:
            - name: epp-primary
                weight: 90
            - name: epp-canary
                weight: 10

    Placement (route / weighted-cluster): Put the weighted_clusters route inside Envoy's RouteConfiguration for the HttpConnectionManager (path: static_resources.listeners[].filter_chains[].filters[name: envoy.filters.network.http_connection_manager].typed_config.route_config.virtual_hosts[].routes[].route.weighted_clusters). For Istio, configure an equivalent weighted split in VirtualService.spec.http[].route[]. Ensure clusters epp-primary and epp-canary exist in static_resources.clusters or are provided via CDS.

  • Header sampling + route-by-header (explicit sampling, sticky options)

    http_filters:
    - name: envoy.filters.http.lua
        typed_config:
            "@type": type.googleapis.com/envoy.extensions.filters.http.lua.v3.Lua
            inline_code: |
                math.randomseed(os.time() + (ngx and ngx.worker and ngx.worker.pid() or 0))
                function envoy_on_request(request_handle)
                    if math.random() <= 0.10 then
                        request_handle:headers():add("x-epp-variant", "canary")
                    end
                end

# route-by-header rules
- match:
        headers:
            - name: x-epp-variant
                exact_match: canary
    route: { cluster: epp-canary }
- match: { prefix: "/" }
    route: { cluster: epp-primary }

    Placement (Lua / header sampling): Add the Lua http_filters snippet into the HttpConnectionManager typed_config.http_filters list (place the Lua filter before envoy.filters.http.router). Use the route virtual_hosts[].routes[] to match on x-epp-variant (header) and route to the epp-canary cluster; default route should point to epp-primary. For Istio, insert Lua using an EnvoyFilter and use header-based VirtualService matches to split traffic.

  • Operational notes:

    • Deploy two EPP stacks (or two deployments of the same binary with different Runner/ConfigMap), one configured with the by_label filter enabled and the other without. Expose each as a distinct Envoy cluster (epp-primary, epp-canary).
    • Use weighted-cluster splitting for simple percentage-based rollouts; use Lua sampling when you need programmatic control (per-user hashing, sticky keys, cookies, or advanced sampling logic).
    • Monitor health, latency, and error metrics for the canary; ramp weights gradually (e.g., 1% → 5% → 10%).
    • For session stickiness, sample deterministically (hashing on a cookie or header) rather than pure random sampling.
    • If you prefer a single EPP service to make the routing decision internally, you can inject a header (via Envoy) and implement a PrepareData/Admission plugin or a Filter that reads x-epp-variant / headers and modifies InferenceObjective or filters endpoints accordingly.

Appendix B — pkg/plugins/filter/by_label_selector.go

  • Configuration: a selector (string or structured selector) supporting equality and set-based operators such as =, !=, in, notin, and exists (examples: region=us-west, gpu in (a100,t4), env for existence).
  • Factory validation: selector syntax is validated at plugin creation time; invalid selectors cause the factory to fail fast to prevent runtime surprises.
  • Runtime behavior: the filter retains only endpoints whose labels satisfy the configured selector. It supports multi-attribute and set-based matching (multi-key AND semantics). If the selector matches no endpoints the candidate set will be empty and the scheduler will have no endpoints to choose from unless other filters or fallback logic add candidates.
  • When to use: complex capability routing (GPU family, accelerator type, memory tier), locality/compliance routing (region, zone, jurisdiction), tenant/environment isolation (tenant=acme, env=staging), canary/blue‑green rollouts (release=canary), progressive migrations (shift traffic by changing selectors), and targeted debugging or testing.
  • Interaction: more expressive than by_label (which checks a single key and a whitelist of values). Combine by_label_selector with scorers or fallback filters when you want to prefer matching endpoints but still allow broader coverage under fallback conditions.
  • Caution: overly restrictive or misconfigured selectors can exclude all endpoints—test selectors carefully and prefer gradual rollouts or explicit fallbacks in production.

Appendix C — pkg/plugins/filter/pd_role.go

  • Key constants: the filter checks label llm-d.ai/role with well-known values prefill, decode, and both.
  • Plugin types: prefill-filter — matches endpoints with role prefill (strict); decode-filter — matches endpoints with role decode or both and allows unlabeled endpoints (fallback).
  • Configuration: these are instantiated by factory functions (no per-instance roles array). The plugin factories create the appropriately preconfigured ByLabel instances (PrefillRoleFactory and DecodeRoleFactory).
  • Runtime behavior: prefill-filter retains only endpoints whose llm-d.ai/role equals prefill. decode-filter retains endpoints whose llm-d.ai/role is decode or both, and because it allows unlabeled endpoints, endpoints missing the label are also kept.
  • When to use: route prefill workloads to P clusters optimized for throughput/memory and route decode or mixed workloads to Ds suited for low latency or mixed-capability pools. Use these filters to enforce PD‑level workload separation and cost/SLAs tradeoffs in a disaggregated PD architecture.
  • Interaction: use alongside by_label/by_label_selector when additional endpoint labels are present; combine with scorers to prefer certain PDs without hard exclusion. Note that decode-filter's allowlist behavior intentionally provides a fallback when PD labeling is missing.
  • Caution: because role metadata and labeling may be produced by external controllers, it can be absent or stale—prefer staged rollouts, monitor capacity, and avoid relying on strict exclusion unless you control labeling guarantees.

Appendix D — pkg/plugins/scorer/load_aware.go

  • Configuration: optional parameters for weight, smoothing/window size, and metric source (e.g., CPU, active requests); these tune how aggressively the scorer penalizes loaded endpoints.
  • Runtime behavior: consumes endpoint load metrics and produces normalized scores in [0,1], preferring lower-load endpoints. Normalization and smoothing prevent extreme score swings.
  • When to use: distribute traffic to avoid hotspots, reduce request latency by spreading load, and complement affinity-based routing.
  • Interaction: often combined with cache/warmth scorers (like NoHitLRU) and label-based filters; ensure weighting balances load vs. affinity needs.
  • Caution: relies on accurate, timely metrics—stale or missing metrics can misrank endpoints; consider graceful degradation to neutral scores when metrics are unavailable.

Appendix E — pkg/plugins/scorer/no_hit_lru.go

  • Configuration: parameters for LRU window size, decay, and whether to promote recently-hit endpoints aggressively.
  • Runtime behavior: maintains recency state for endpoints and boosts scores for endpoints with recent successful hits (warm). Endpoints without recent activity receive lower scores to de-prioritize cold instances.
  • When to use: reduce cold-start latency by favoring endpoints that have recently served similar requests, helpful for models with significant startup cost or cache warmups.
  • Interaction: pairs well with PreRequest plugins that update warm-state and with load-aware scorers to avoid overloading a few warm endpoints.
  • Caution: can starve cold endpoints if used alone; combine with load-aware scoring or occasional randomized selection to ensure capacity utilization.

Appendix F — pkg/plugins/scorer/precise_prefix_cache.go

  • Configuration: tuning options for prefix match thresholds, score bonus magnitude, and cache key strategies.
  • Runtime behavior: examines request content (prefixes/keys) and endpoint cache metadata to boost scores for endpoints likely to have a matching cached result, improving hit rates and latency for prefix-heavy workloads.
  • When to use: workloads where prefix or token-level caching yields large latency wins (e.g., autocomplete, code-completion, repetitive prompt patterns).
  • Interaction: use with NoHitLRU and load-aware scorers to balance cache affinity against load and freshness; ensure cache metadata is maintained by pre-request or background processes.
  • Caution: cache staleness or incorrect metadata can produce suboptimal routing; provide mechanisms to invalidate or soften cache bonuses when cache health is uncertain.

Appendix G — pkg/epp/framework/plugins/scheduling/scorer/prefix

  • Purpose: Compute and attach longest-prefix match metadata to endpoints so downstream scorers and filters can prefer endpoints with cache hits or affinity for the request prefix.

  • Files: pkg/epp/framework/plugins/scheduling/scorer/prefix/plugin.go (factory and prepare hooks).

  • Configuration: optional parameters: prefix_length (number of tokens/bytes to extract), hash_algo (e.g., fnv32, murmur), and include_metadata (boolean; attach match details to endpoint Metadata).

  • Factory validation: validates sensible prefix_length ranges and supported hash_algo values at startup; invalid configs cause factory failure to avoid silent misrouting.

  • Runtime behavior: extracts a canonical prefix from the request (by tokens or bytes), computes a short fingerprint, and compares it to endpoint cache keys. Annotates each candidate endpoint with a prefixMatch metadata structure containing matchedLength, score, and cacheKey. Runs as a PrepareData hook and is fail-open on timeouts/errors.

  • Inputs: request payload (prompt/text), candidate endpoint metadata (may include prefix_cache_keys), and configured prefix extraction rules.

  • Outputs: per-endpoint prefixMatch metadata and aggregated prefix statistics in the request cycleState for use by scorers and selection logic.

  • When to use: workloads with high prefix reuse (autocomplete, code completion, repetitive prompts) where cache affinity reduces TTFT/TPOT; helps prefer endpoints likely to have warm cached responses.

  • Interaction: pairs with precise_prefix_cache scorer and NoHitLRU to balance cache affinity against load. The prefix plugin must run before scorers so its annotations are available during scoring.

  • Caution: depends on timely, accurate endpoint cache metadata—stale or inconsistent metadata can mislead the scheduler. Use conservative prefix_length and monitor prefix-match rates when deploying.

  • Use Case: configure prefix to extract the first 32 tokens and enable include_metadata; combine with precise_prefix_cache to award score bonuses when matchedLength exceeds a threshold, reducing TTFT for autocomplete workloads.

Appendix H — predicted-latency plugin

  • Purpose: Predict per-endpoint Time-To-First-Token (TTFT) and Time-Per-Output-Token (TPOT) to select endpoints likely to meet request SLOs.
  • Main files:
    • pkg/epp/framework/plugins/scheduling/scorer/predictedlatency/preparedata_hooks.go — collect inputs (prefix-cache scores, request SLOs).
    • pkg/epp/framework/plugins/scheduling/scorer/predictedlatency/prediction.go — call predictor and validate predictions.
    • pkg/epp/framework/plugins/scheduling/scorer/predictedlatency/selection.go (+ helpers) — compute headroom and choose endpoints.
  • Inputs: endpoint metrics, request prompt/token counts, prefix-cache match scores, SLO headers (TTFT/TPOT).
  • Outputs: per-endpoint endpointPredictionResult (TTFT, TPOT, validity, headroom) stored in the request context for scoring/selection.
  • Where the model runs: predictions come from the latency predictor sidecar client under sidecars/latencypredictorasync:
    • bayesian_ridge: client caches coefficients and evaluates a local linear model (predictBayesianRidge). The model used is Bayesian Ridge, which provides predictions after only a few hunderd examples, and requires no tuning.
    • xgboost / lightgbm: predictions are normally performed via HTTP calls to configured prediction servers (/predict, /predict/bulk). The servers run Gradient Boosted Decision Tree (GBDT) models. The client can optionally fetch XGBoost trees for native use (UseNativeXGBoost).
  • Key endpoints: training (/add_training_data_bulk), model info (/model/download/info), metrics/trees (/model/.../xgb/json), prediction (/predict, /predict/bulk).
  • Notes: plugin falls back to composite scoring if predictor is unavailable; configuration and runtime model type are managed by the latency predictor sidecar.

Appendix I — ProfileHandlers and Profiles

Introduction — what they are and where they live

ProfileHandlers and SchedulerProfiles collaborate to implement the scheduler's policy decisions.

  • SchedulerProfile ("profile"): a small, per-profile pipeline that the Scheduler runs to pick endpoints for that profile. A profile is constructed from a list of pluginRefs and, at runtime, contains three logical pieces: a list of Filter plugins, a list of weighted Scorer plugins, and a single Picker plugin. The profile's implementation lives in the Scheduler package: .go/pkg/mod/sigs.k8s.io/gateway-api-inference-extension@v0.0.0-20260128235548-fd30cb97714a/pkg/epp/scheduling/scheduler_profile.go.

  • ProfileHandler: a single plugin instance the Scheduler consults each scheduling cycle to decide which profiles should run (via Pick(...)) and how to consolidate their outputs into the final SchedulingResult (via ProcessResults(...)). ProfileHandler implementations live under pkg/plugins/profile (examples: pd_profile_handler.go, dp_profile_handler.go) and are registered by the repo at startup (pkg/plugins/register.go).

  • How they relate to the Scheduler: the Scheduler is built with a configured ProfileHandler instance (injected via NewSchedulerWithConfig) and a map of named SchedulerProfile objects. During Schedule(...) the Scheduler repeatedly calls profileHandler.Pick(...) to get the next profiles to run; it then calls profile.Run(...) for each selected profile (the profile enforces Filters → Scorers → Picker) and finally calls profileHandler.ProcessResults(...) to aggregate results.

See the concrete scheduler implementation here: scheduler.go.

YAML examples

These examples show:

  1. top-level plugin instance declarations; and
  2. how schedulingProfiles reference those instances via pluginRef

Example (excerpt from deploy/config/epp-config.yaml):

# Sample EPP configuration for running without P/D
apiVersion: inference.networking.x-k8s.io/v1alpha1
kind: EndpointPickerConfig
plugins:                         # Declare plugin instances.
    - type: prefix-cache-scorer
    - type: decode-filter
    - type: max-score-picker
    - type: single-profile-handler

schedulingProfiles:
    - name: default              # Define a profile named "default" that references some of the declared plugins.
        plugins:
            - pluginRef: decode-filter
            - pluginRef: max-score-picker
            - pluginRef: prefix-cache-scorer
                weight: 2

Example (excerpt from deploy/config/dp-epp-config.yaml):

# Sample EPP configuration for running with Data Parallel
#
apiVersion: inference.networking.x-k8s.io/v1alpha1
kind: EndpointPickerConfig
plugins:
- type: precise-prefix-cache-scorer
    parameters:
        indexerConfig:
        tokenProcessorConfig:
            blockSize: 5
        kvBlockIndexConfig:
            maxPrefixBlocksToMatch: 256
- type: decode-filter
- type: max-score-picker
- type: data-parallel-profile-handler
    parameters:
        primaryPort: 8000

schedulingProfiles:
- name: default
    plugins:
    - pluginRef: decode-filter
    - pluginRef: max-score-picker
    - pluginRef: precise-prefix-cache-scorer
        weight: 2

Profiles (semantics and runtime mapping)

  • Minimal structure: a SchedulerProfile has filters (0..N), scorers (0..N, weighted) and a single picker.

  • Registration: when the Runner constructs a profile from schedulingProfiles[].plugins it looks up each named plugin instance and registers it with the profile according to the interfaces it implements:

    • Filter → appended to p.filters in the order encountered
    • WeightedScorer → appended to p.scorers (plain Scorer without a weight causes a factory/registration error)
    • Picker → assigned to p.picker (only one picker allowed)

  • Runtime execution order: SchedulerProfile.Run(...) invokes runFilterPlugins(...) → runScorerPlugins(...) → runPickerPlugin(...) unconditionally. This enforces the canonical Filters→Scorers→Picker pipeline regardless of declaration order in top-level plugins: or profile pluginRef lists.

  • Failure behaviour: if filters remove all endpoints the profile run returns an error and yields a nil ProfileRunResult; the ProfileHandler sees this in the profileResults map and can decide fallbacks.

  • Best practice: list profile pluginRefs in the human-friendly order (filters, then scorers, then picker) so configs are readable and reviewers don't get confused. Note: some example YAML snippets in this document do not show the picker listed last. That does not break runtime behavior — the SchedulerProfile construction and Run() logic register plugins by interface and then enforce the pipeline order (Filters → Scorers → Picker), so a picker declared earlier is stored and invoked only during the picker phase.

ProfileHandler (concrete handlers and configuration)

  • What a ProfileHandler does: for each scheduling cycle it implements two methods:

    • Pick(ctx, cycleState, request, profiles, profileResults) map[string]SchedulerProfile — which named profiles should run next
    • ProcessResults(ctx, cycleState, request, profileResults) (*SchedulingResult, error) — aggregate profile outputs into the final SchedulingResult

  • Where implemented: repository handlers live under pkg/plugins/profile and are registered by pkg/plugins/register.go.

  • Concrete handlers in the llm-d-inference-scheduler repo:

    • pd-profile-handler (PdProfileHandler) — pkg/plugins/profile/pd_profile_handler.go

      • Behavior: enforces a decode-first strategy. On the first cycle it returns the configured decode profile to run. If decode succeeds and a configured pdDecider indicates disaggregation is needed, it will instruct the scheduler to run the prefill profile next; finally ProcessResults rewrites endpoints into Data‑Parallel form when primaryPort is configured and includes both decode and prefill results when available.
      • Config params (factory):
        • decodeProfile: name of the SchedulerProfile to run first (the "decode" phase). Controls which profile the handler will select on the first cycle. (default: "decode")
        • prefillProfile: name of the SchedulerProfile to run for the prefill phase when PD disaggregation is required. Only used if the configured decider indicates prefill should run. (default: "prefill")
        • prefixPluginType: the plugin type to use for prefix preparation (a PrepareData plugin). Determines which prepare hook will annotate endpoints with prefix/cache metadata consumed by prefix-aware scorers. (default: prefix.PrefixCachePluginType i.e. prefix-cache-scorer) Note: PdProfileHandler stores this type/name so other plugins (scorers or LRU helpers) can locate prefix prepare-state in the scheduling CycleState. The handler itself does not call the prefix plugin at runtime; it only records the configured typed name for consumers that read prefix annotations.
        • prefixPluginName: the plugin instance name (from top-level plugins:) to run for prefix preparation. Allows selecting a specific configured instance when multiple prefix plugins exist. (default: same as prefixPluginType) Note: like prefixPluginType, the PdProfileHandler stores the configured instance name so other plugins can find the prefix prepare-state in the scheduling CycleState. The handler does not invoke the prefix plugin directly at runtime.
        • primaryPort: TCP port number used when rewriting endpoints into Data‑Parallel form; ProcessResults uses this to set the primary service port on rewritten endpoints and to populate routing headers. (default: 0 — no primary port / no rewrite)
        • deciderPluginName: name of the PD-decider plugin (from plugins:) used to decide whether to run prefill after decode. Controls the disaggregation decision logic. (default: AlwaysDisaggDeciderPluginType — typically "always-disagg-pd-decider")

    • data-parallel-profile-handler (DataParallelProfileHandler) — pkg/plugins/profile/dp_profile_handler.go

      • Behavior: intended for single-profile Data‑Parallel workflows; validates exactly one profile is configured and converts its run result into Data‑Parallel endpoints (rewrites ports and sets the DataParallel header) in ProcessResults.
      • Config params (factory): primaryPort.

  • How handlers are wired/configured:

    • Declare a handler instance in the top-level plugins: block (type pd-profile-handler or data-parallel-profile-handler) with any parameters.
    • When the Runner builds the Scheduler it injects the chosen ProfileHandler instance into SchedulerConfig and constructs named SchedulerProfile objects from schedulingProfiles.

  • Registration entry points: see pkg/plugins/register.go for the plugin.Register(...) calls that make these handler factories available at runtime.

Related files: - Runner config / loader: https://github.com/kubernetes-sigs/gateway-api-inference-extension/blob/master/cmd/epp/runner - Scheduler implementation: https://github.com/kubernetes-sigs/gateway-api-inference-extension/blob/master/pkg/epp/scheduling/scheduler.go - SchedulerProfile implementation: https://github.com/kubernetes-sigs/gateway-api-inference-extension/blob/master/pkg/epp/scheduling/scheduler_profile.go
