terraform-oci-ampere-a1-DeathStarBench

Description

Terraform code to launch Ampere A1 Shapes on Oracle Cloud Infrastructure (OCI) which automatically deploy and runs DeathStarBench

What is DeathStarBench?

DeathStarBench is an open-source benchmark suite for cloud microservices. DeathStarBench includes five end-to-end services, four for cloud systems, and one for cloud-edge systems running on drone swarms. For the purposes of this automation we will be using the DeathStarBench "Social Media" application, which deploys a "Twitter" like social media web service utilizting containers. For more information regarding Ampere platforms and DeathStarBench results please take a look at the following:

• Ampere DeathStarBench workload Brief
• YouTube Videos:

Requirements

• Terraform
• Oracle OCI Account

Automation Walkthrough

This automation is essentially a spealized fork of the terraform-oci-ampere-a1 module adding additional configuration steps. Thus this will configure all the networking and security settings for instances being deployed. The instances being deployed have four cores and thirty two gigs of RAM. Essentially the remaining automation falls into two phases.

1. Setup all the scaffolding and deploy two virtual machines passing different metadata into each host.
   1. The first host will be deployed as the DeathStarBench social media application.
      1. The deployment includes a single node Kubernetes cluster with Calico for Kubernetes network.
      2. Once the Kubernetes infrastructure is running, Helm charts are used to deploy aarch64 container images from a public container repository.
   2. The second virtal machine instance will pull the DeathStarBench source and build the client worker to generate load against the deployed DeathStarBench social media application.
      1. An Ngnix container is also deployed to allow the results of the load generation to be viewed via a simple HTML page.
2. While the systems are executing thier metadata, two scripts are being rendered with the dynamic external IP information and copied via SCP to the running instances.
   1. The rendering is done in order to faciliate connectivity to the DeathStarBench backend.
      1. Script ont he first node is used to load a default dataset into the DeathStarBench Social Media applicaiton after waiting for the application to be up and running.
      2. Build the Wrk2 client on the Second virtual machine instance from source, waiting until the DeathStarBench application is up and populated with data before executing the benchmark run.

Configuration with terraform.tfvars

The easiest way to configure is to use a terraform.tfvars in the project directory.
Please that Compartment OCID is NOT the same as Tenancy OCID for Root Compartment. You will need to supply the appropriate compartment ID.

The following is an example of what terraform.tfvars should look like:

tenancy_ocid = "ocid1.tenancy.oc1..aaaaaaaabcdefghijklmnopqrstuvwxyz1234567890abcdefghijklmnopq"
user_ocid = "ocid1.user.oc1..aaaaaaaabcdefghijklmnopqrstuvwxyz0987654321zyxwvustqrponmlkj"
fingerprint = "a1:01:b2:02:c3:03:e4:04:10:11:12:13:14:15:16:17"
private_key_path = "/home/bwayne/.oci/oracleidentitycloudservice_bwayne-08-09-14-59.pem"
compartment_ocid = "ocid.compartment.oc1.aaaaaabbbbbbbcccccccddddddddd111111222222333333544444455"
# For development purposes if needed
# deathstarbench_repository_url = "-b <YOUR_BRANCH> https://oauth2:<YOURTOKEN>@gitlab.com/<YOUR_FORK>/DeathStarBench.git"

Inputs

Name	Description	Type	Default	Required
ampere_a1_cpu_core_count	Default core count for Ampere A1 instances in OCI Free Tier	string	"4"	no
ampere_a1_vm_memory	Default RAM in GB for Ampere A1 instances in OCI Free Tier	string	"32"	no
compartment_ocid	OCI Compartment ID	any	n/a	yes
deathstarbench_repository_url	DeathStarBench repository url	string	"-b arm64-port https://github.com/AmpereComputing/DeathStarBench.git"	no
fingerprint	OCI Fingerprint ID for Free-Tier Account	any	n/a	yes
instance_prefix	Name prefix for vm instances	string	"dsb"	no
oci_vcn_cidr_block	CIDR Address Block for OCI Networks	string	"10.1.0.0/16"	no
oci_vcn_cidr_subnet	CIDR Subnet Address for OCI Networks	string	"10.1.1.0/24"	no
oci_vm_count	OCI Free Tier Ampere A1 is four instances	number	2	no
private_key_path	Local path to the OCI private key file	any	n/a	yes
tenancy_ocid	OCI Tenancy ID for Free-Tier Account	any	n/a	yes
user_ocid	OCI User ID for Free-Tier Account	any	n/a	yes
wrk_duration	duration to use when running wrk	string	"30s"	no
wrk_number_of_conns	Number of connections to use when running wrk	string	"1000"	no
wrk_number_of_threads	Number of Threads to use when running wrk	string	"10"	no
wrk_requests_per_second	Number of requests per second to use when running wrk	string	"5000"	no

Modules

No modules.

Outputs

Name	Description
AmpereA1_DeathStarBench_BootVolumeIDs	Output the boot volume IDs of the instance
AmpereA1_DeathStarBench_PrivateIPs	Output the private IP(s) of the instance(s)
AmpereA1_DeathStarBench_PublicIPs	Output the public IP(s) of the instance(s)
AmpereA1_DeathStarBench_RESULTS_URL	Output the URL of the WRK2 Output/Results
AmpereA1_DeathStarBench_URL	Output the url of the DeathStarBench application
OCI_Availability_Domains	Output Availability Domain Results
Ubuntu-20_04-aarch64-latest_name	Output the Ubuntu 20.04 image name
Ubuntu-20_04-aarch64-latest_ocid	Output the Ubuntu 20.04 image OCID
oci_home_region	Output the OCI Home Region
oci_ssh_private_key	Output OCI SSH Private Key
oci_ssh_public_key	Output OCI SSH Public Key

Providers

Name	Version
local	n/a
null	n/a
oci	n/a
random	n/a
tls	n/a

Resources

Name	Type
local_file.oci-ssh-privkey	resource
local_file.oci-ssh-pubkey	resource
null_resource.execute_wrk	resource
null_resource.populate_dsb_backend	resource
oci_core_instance.ampere_a1	resource
oci_core_internet_gateway.ampere_internet_gateway	resource
oci_core_route_table.ampere_route_table	resource
oci_core_security_list.ampere_security_list	resource
oci_core_subnet.ampere_subnet	resource
oci_core_virtual_network.ampere_vcn	resource
random_uuid.random_id	resource
tls_private_key.oci	resource
oci_core_images.ubuntu-20_04-aarch64	data source
oci_identity_availability_domains.ads	data source
oci_identity_regions.regions	data source
oci_identity_tenancy.tenancy	data source

Requirements

No requirements.

References

• https://docs.oracle.com/en-us/iaas/Content/API/SDKDocs/terraformproviderconfiguration.htm
• Where to Get the Tenancy's OCID and User's OCID
• API Key Authentication
• Instance Principal Authorization
• Security Token Authentication
• How to Generate an API Signing Key
• Bootstrapping a VM image in Oracle Cloud Infrastructure using Cloud-Init
• Oracle makes building applications on Ampere A1 Compute instances easy
• scross01/oci-linux-instance-cloud-init.tf
• scross01/autonomous_linux_7.7.tf
• Oracle Cloud Always Free
• OCI Terraform Level 200
• OCI Stacks
• An Open-Source Benchmark Suite for Microservices and Thier Hardware-Software Implications for Cloud & Edge Systems
• The Morning Paper: An open-source benchmark suite for microservices and their hardware-software implications for cloud & edge systems
• Ampere DeathStarBench workload Brief
• Up to 44% Lower Latency on Ampere than x86 on DeathStarBench
• Up to 73% Higher Performance and Better Consistency than x86 on DeathStarBench
