MAVLink 3D Visualizer

This project provides a bridge between a Software-In-The-Loop (SITL) simulator (e.g., ArduPilot SITL) and a web-based 3D visualization tool. It enables real-time rendering of MAVLink-enabled vehicles (drones, planes, VTOLs) in a 3D environment using Three.js for graphics, Ammo.js for physics, and MAVLink for telemetry parsing. The bridge converts UDP packets from the simulator to WebSocket messages for the browser, allowing interactive 3D maps with optional real-world terrain (via Mapbox or Three-Geo).

The visualization supports multiple vehicle types, camera views, physics simulations, and dynamic terrain loading based on vehicle position.

Documentation

• Project Wiki: wiki/
  This folder contains developer and user docs. Link here stays stable as docs evolve.

Mavlink3DMap

Mavlink3DMap is a Node.js‑based tool for visualizing MAVLink telemetry on an interactive 3D map in the browser.
It provides:

• Backend: Bridges MAVLink data received over UDP into WebSocket streams.
• Frontend: A WebGL/3D scene that renders the vehicle and environment in real time.
• SITL Helpers: Convenience scripts for running ArduPilot SITL (plane / quad / VTOL) with preconfigured parameters.

This README describes the project based on the current repository structure and script names.
If your local setup differs, adjust paths/commands accordingly.

---

Features

• UDP → WebSocket bridge

  • Backend listens to MAVLink‑compatible UDP telemetry.
  • Forwards selected data to browser clients via WebSocket.

• 3D visualization in the browser

  • Frontend uses JavaScript 3D scenes (under frontend/src/js/scenes) to render:
    • Vehicle attitude and position.
    • World reference / environment objects (depending on chosen scene).

• Multiple scenes / views

  • Modular scene files in frontend/src/js/scenes.
  • View controller in frontend/src/js/js_view.js.
  • World / environment logic in frontend/src/js/js_world.js.

• Streaming utilities

  • backend/src/udp2websocket.js: Bridge for UDP → WebSocket.
  • backend/src/websocket_bridge.js: WebSocket ↔ WebSocket bridge between two WS ports suitable for DroneEngage Webclient.
  • backend/src/websocket_streaming.js: Manages streaming data to clients.

• SITL integration helpers

  • Root scripts like:
    • runSITLPlane.sh
    • runSITLQuad.sh
  • Parameter files:
    • VTOL_TRI.parm
    • quadPlus_2.parm

• Simple local run scripts

  • run_web.sh to start the web frontend.
  • run.sh as a generic entry point (depending on how you use it).

---

Project Structure

High‑level overview:

.
├── backend/
│   ├── public/
│   ├── scripts/
│   │   └── prepack.js
│   ├── src/
│   │   ├── cli.js
│   │   ├── mavlink.js
│   │   ├── udp2websocket.js
│   │   └── websocket_streaming.js
│   └── package.json   (backend dependencies)
├── frontend/
│   ├── public/
│   │   ├── models/
│   │   ├── app_logo.png
│   │   └── favicon.ico
│   ├── src/
│   │   ├── index.js
│   │   ├── index_4w.js
│   │   ├── css/
│   │   ├── js/
│   │   │   ├── js_view.js
│   │   │   ├── js_world.js
│   │   │   └── scenes/
│   │   │       └── ... (3D scene definitions)
│   │   └── textures/
│   ├── index.html
│   └── package.json   (frontend dependencies, if present)
├── resources/
│   ├── app_logo.png
│   └── fav.ico
├── wiki/
│   ├── DEV_DATAFLOW.md
│   └── SCENES_GUIDE.md
├── run.sh
├── run_web.sh
├── runSITLPlane.sh
├── runSITLQuad.sh
├── VTOL_TRI.parm
├── quadPlus_2.parm
└── package.json       (root metadata / scripts)

Key pieces:

• Backend (backend/src): MAVLink parsing and streaming utilities.
• Frontend (frontend/src): 3D visualization logic and UI.
• Wiki (wiki/): Additional developer documentation (dataflow, scenes).
• Scripts (root): Helper scripts for running SITL and the web server.

---

Requirements

• OS: Linux (scripts are .sh and project is developed/tested on Linux).
• Node.js: LTS version (e.g. 18.x or later).
• npm or yarn.
• MAVLink data source:
  • ArduPilot SITL or a real autopilot streaming MAVLink over UDP.

---

Using via npm (CLI)

You can run Mavlink3DMap without cloning the repository by using the published npm package mavlink3dmap.
This single CLI package can:

• Serve the web UI
• Run the UDP → WebSocket bridge
• (Linux only) Stream video frames to a v4l2loopback virtual camera via ffmpeg

Quick usage (no install)

Use npx to run directly:

# Start everything: web UI + UDP→WS bridge
npx mavlink3dmap up --port 8080 --udp-port 16450

# Serve the built web UI only
npx mavlink3dmap serve -p 8080

# Run only the UDP→WebSocket bridge (WS on 8811)
npx mavlink3dmap udp2ws --udp-port 16450

Install globally

npm i -g mavlink3dmap

Usage

# Start everything: web UI + UDP→WS bridge
mavlink3dmap up --port 8080 --udp-port 16450

# Serve the built web UI only
mavlink3dmap serve -p 8080

# Run only the UDP→WebSocket bridge (WS on 8811)
mavlink3dmap udp2ws --udp-port 16450

---

Code Installation

1. Clone the repository

git clone https://github.com/HefnySco/Mavlink3DMap.git
cd Mavlink3DMap

2. Install backend dependencies

If the backend has its own package.json:

cd backend
npm install
# or
yarn install

3. Install frontend dependencies

If the frontend has its own package.json:

cd ../frontend
npm install
# or
yarn install

If there is a root‑level dependency setup, follow the scripts defined in the root package.json.

---

Running the Backend

The backend typically:

• Listens on a UDP port for MAVLink telemetry.
• Opens a WebSocket server for browser clients.

From the backend directory (or using root scripts if provided):

cd backend
npm start
# or a specific script, e.g.
# node src/udp2websocket.js
# node src/websocket_streaming.js

Check backend/package.json for the exact script names (start, dev, etc.), and adjust the command accordingly.

Configuration such as UDP port and WebSocket port is usually defined either:

• In environment variables, or
• In the backend source files (e.g. udp2websocket.js, websocket_streaming.js).

---

Running the Frontend

From the frontend directory:

cd frontend
npm start
# or
npm run dev
# or
npm run build && npm run serve

Refer to frontend/package.json for the exact commands.

Alternatively, you may use the provided root script (if configured that way):

cd <project-root>
./run_web.sh

This script typically:

• Builds/serves the frontend.
• Optionally starts a static server.

---

Using with SITL (ArduPilot)

The repository includes convenience scripts and parameter files for SITL:

• Scripts:

  • runSITLPlane.sh
  • runSITLQuad.sh

• Parameter files:

  • VTOL_TRI.parm
  • quadPlus_2.parm

A typical workflow:

1. Start SITL with one of the provided scripts:

   ./runSITLPlane.sh
   # or
   ./runSITLQuad.sh

2. Ensure SITL is configured to stream MAVLink telemetry to the UDP port expected by udp2websocket.js.

3. Start the backend (UDP → WebSocket bridge).

4. Start the frontend and open it in a browser.

If needed, adjust SITL parameters and UDP endpoints so that the backend receives the telemetry.

---

Frontend Scenes and Views

The 3D visualization is broken into several components:

• frontend/src/js/js_view.js
  Manages overall view logic, initializing the renderer, handling WebSocket connections, and orchestrating scenes.

• frontend/src/js/js_world.js
  Contains world/environment‑level objects (ground, axes, skybox, etc., depending on scene implementation).

• frontend/src/js/scenes/
  Contains specific 3D scene definitions. Each file typically:

  • Sets up cameras, lights, and meshes.
  • Defines update loops for vehicle pose and telemetry.

For more details, consult:

• wiki/DEV_DATAFLOW.md – data flow and architecture.
• wiki/SCENES_GUIDE.md – information about each scene and how to add new ones.

---

Development Notes

• Code style:

  • Plain JavaScript in both frontend and backend.
  • Scenes are modular under frontend/src/js/scenes.

• Extending the viewer:

  • Add new scenes under frontend/src/js/scenes.
  • Add new telemetry fields into mavlink.js and forward them via websocket_streaming.js and frontend WebSocket handlers.
  • Modify js_view.js / js_world.js to integrate new visual elements.

• Logging & debugging:

  • Use browser DevTools for frontend console logs and network/WebSocket inspection.
  • Use console.log (or your logger of choice) in backend scripts for telemetry and connection debugging.

---

Troubleshooting

• No data in the 3D view:

  • Verify SITL or flight controller is sending MAVLink to the correct UDP port.
  • Check that udp2websocket.js is running and that the WebSocket server is reachable.
  • Confirm the frontend is connecting to the correct WebSocket URL (hostname, port, protocol).

• Frontend cannot connect to WebSocket:

  • Check backend logs for errors.
  • Ensure ports are open and not blocked by firewall.
  • Confirm that the URL used in js_view.js or related config matches the backend address.

• Performance issues:

  • Reduce the number of rendered objects in the active scene.
  • Throttle update frequency from backend if very high.

---
