Transform natural-language policy documents into executable governance graphs for AI agent routing, enforcement, and auditing.
Markdown Policy Governance Graph Visualization
┌─────────────────┐ ┌─────────────────┐ ┌─────────────────┐
│ # Data Security │ │ { │ │ ┌─────────┐ │
│ - Encrypt data │ ──► │ "nodes": [...│ ──► │ │ Section │ │
│ - Log access │ │ "edges": [...│ │ └────┬────┘ │
│ │ │ } │ │ ┌───┴───┐ │
└─────────────────┘ └─────────────────┘ │ ┌──┴─┐ ┌──┴─┐ │
│ │Rule│ │Rule│ │
│ └────┘ └────┘ │
└─────────────────┘
AI agents need machine-readable policies to make governance decisions. This tool bridges the gap between human-readable policy documents and structured data that agents can query and enforce.
Use cases:
- Agent routing decisions based on policy rules
- Compliance checking and audit trails
- Multi-agent coordination protocols
- Automated policy enforcement
# Clone and setup
git clone https://github.com/NathanMaine/governance-graph-compiler.git
cd governance-graph-compiler
pip install -e .
# Compile a policy
ggc compile --policy policies/example.md --out out/Output:
out/graph.json- Structured graph with nodes and edgesout/graph.dot- Graphviz DOT format for visualization
Input: policies/example.md
# Data handling
- Encrypt data in transit
- Log access attempts
## Access control
- Least privilege for agents
- Rotate credentials every 90 daysOutput: graph.json
{
"nodes": [
{"id": "section-1", "label": "Data handling", "type": "section", "level": 1},
{"id": "rule-1", "label": "Encrypt data in transit", "type": "rule"},
{"id": "rule-2", "label": "Log access attempts", "type": "rule"},
{"id": "section-2", "label": "Access control", "type": "section", "level": 2},
{"id": "rule-3", "label": "Least privilege for agents", "type": "rule"},
{"id": "rule-4", "label": "Rotate credentials every 90 days", "type": "rule"}
],
"edges": [
{"from": "section-1", "to": "rule-1", "label": "contains"},
{"from": "section-1", "to": "rule-2", "label": "contains"},
{"from": "section-2", "to": "rule-3", "label": "contains"},
{"from": "section-2", "to": "rule-4", "label": "contains"}
]
}Here's a comprehensive AI governance policy compiled into a graph:
Click to expand full policy
# Autonomous Agent Constitution
## Core Directives
- Agent must identify itself as AI in first interaction
- Never impersonate humans or other agents
- Terminate session if user requests illegal activity
- Preserve audit trail for all decisions
## Knowledge Boundaries
- Admit uncertainty rather than hallucinate
- Cite sources for factual claims
- Defer to domain experts for medical, legal, financial advice
- Update knowledge cutoff disclaimer when relevant
# Tool Execution Framework
## Permission Levels
- Level 1: Read-only operations (no approval needed)
- Level 2: Reversible writes (user confirmation required)
- Level 3: Irreversible actions (human supervisor approval)
- Level 4: Financial transactions (dual approval + audit)
## Sandboxing Rules
- Code execution isolated in ephemeral containers
- Network access restricted to allowlisted domains
- File system access limited to designated workspace
- Memory wiped between sessions
## Rate Limiting
- Maximum 50 API calls per minute
- Batch operations capped at 100 items
- Long-running tasks require heartbeat every 30 seconds
# Multi-Agent Coordination
## Hierarchy Protocol
- Orchestrator agent holds delegation authority
- Specialist agents cannot spawn sub-agents
- Cross-agent communication logged to central bus
- Deadlock detection triggers automatic escalation
## Conflict Resolution
- Later instructions override earlier ones
- User intent takes precedence over system defaults
- Ambiguity resolved by asking clarifying questions
- Unresolvable conflicts escalate to human
# Failure Modes
## Graceful Degradation
- Network failure: switch to cached responses
- Model timeout: return partial results with disclaimer
- Resource exhaustion: queue requests, notify user of delay
## Recovery Procedures
- Auto-retry transient failures (max 3 attempts)
- Checkpoint long operations every 5 minutes
- Rollback on corruption detection
- Alert on-call engineer for cascading failures| Metric | Value |
|---|---|
| Total Nodes | 47 |
| Sections | 13 |
| Rules | 34 |
| Edges | 34 |
Section Breakdown:
─────────────────────────────────────────────────────
Autonomous Agent Constitution │ 0 rules (container)
├── Core Directives │ 4 rules
├── Knowledge Boundaries │ 4 rules
Tool Execution Framework │ 0 rules (container)
├── Permission Levels │ 4 rules
├── Sandboxing Rules │ 4 rules
├── Rate Limiting │ 3 rules
Multi-Agent Coordination │ 0 rules (container)
├── Hierarchy Protocol │ 4 rules
├── Conflict Resolution │ 4 rules
Failure Modes │ 0 rules (container)
├── Graceful Degradation │ 3 rules
└── Recovery Procedures │ 4 rules
─────────────────────────────────────────────────────
The compiled DOT output renders to this governance graph:
View DOT source
digraph G {
"section-1" [label="Autonomous Agent Constitution"];
"section-2" [label="Core Directives"];
"rule-1" [label="Agent must identify itself as AI in first interaction"];
"rule-2" [label="Never impersonate humans or other agents"];
"rule-3" [label="Terminate session if user requests illegal activity"];
"rule-4" [label="Preserve audit trail for all decisions"];
"section-3" [label="Knowledge Boundaries"];
"rule-5" [label="Admit uncertainty rather than hallucinate"];
"rule-6" [label="Cite sources for factual claims"];
"rule-7" [label="Defer to domain experts for medical, legal, financial advice"];
"rule-8" [label="Update knowledge cutoff disclaimer when relevant"];
"section-4" [label="Tool Execution Framework"];
"section-5" [label="Permission Levels"];
"rule-9" [label="Level 1: Read-only operations (no approval needed)"];
"rule-10" [label="Level 2: Reversible writes (user confirmation required)"];
"rule-11" [label="Level 3: Irreversible actions (human supervisor approval)"];
"rule-12" [label="Level 4: Financial transactions (dual approval + audit)"];
"section-6" [label="Sandboxing Rules"];
"rule-13" [label="Code execution isolated in ephemeral containers"];
"rule-14" [label="Network access restricted to allowlisted domains"];
"rule-15" [label="File system access limited to designated workspace"];
"rule-16" [label="Memory wiped between sessions"];
"section-7" [label="Rate Limiting"];
"rule-17" [label="Maximum 50 API calls per minute"];
"rule-18" [label="Batch operations capped at 100 items"];
"rule-19" [label="Long-running tasks require heartbeat every 30 seconds"];
"section-8" [label="Multi-Agent Coordination"];
"section-9" [label="Hierarchy Protocol"];
"rule-20" [label="Orchestrator agent holds delegation authority"];
"rule-21" [label="Specialist agents cannot spawn sub-agents"];
"rule-22" [label="Cross-agent communication logged to central bus"];
"rule-23" [label="Deadlock detection triggers automatic escalation"];
"section-10" [label="Conflict Resolution"];
"rule-24" [label="Later instructions override earlier ones"];
"rule-25" [label="User intent takes precedence over system defaults"];
"rule-26" [label="Ambiguity resolved by asking clarifying questions"];
"rule-27" [label="Unresolvable conflicts escalate to human"];
"section-11" [label="Failure Modes"];
"section-12" [label="Graceful Degradation"];
"rule-28" [label="Network failure: switch to cached responses"];
"rule-29" [label="Model timeout: return partial results with disclaimer"];
"rule-30" [label="Resource exhaustion: queue requests, notify user of delay"];
"section-13" [label="Recovery Procedures"];
"rule-31" [label="Auto-retry transient failures (max 3 attempts)"];
"rule-32" [label="Checkpoint long operations every 5 minutes"];
"rule-33" [label="Rollback on corruption detection"];
"rule-34" [label="Alert on-call engineer for cascading failures"];
"section-2" -> "rule-1" [label="contains"];
"section-2" -> "rule-2" [label="contains"];
"section-2" -> "rule-3" [label="contains"];
"section-2" -> "rule-4" [label="contains"];
"section-3" -> "rule-5" [label="contains"];
"section-3" -> "rule-6" [label="contains"];
"section-3" -> "rule-7" [label="contains"];
"section-3" -> "rule-8" [label="contains"];
"section-5" -> "rule-9" [label="contains"];
"section-5" -> "rule-10" [label="contains"];
"section-5" -> "rule-11" [label="contains"];
"section-5" -> "rule-12" [label="contains"];
"section-6" -> "rule-13" [label="contains"];
"section-6" -> "rule-14" [label="contains"];
"section-6" -> "rule-15" [label="contains"];
"section-6" -> "rule-16" [label="contains"];
"section-7" -> "rule-17" [label="contains"];
"section-7" -> "rule-18" [label="contains"];
"section-7" -> "rule-19" [label="contains"];
"section-9" -> "rule-20" [label="contains"];
"section-9" -> "rule-21" [label="contains"];
"section-9" -> "rule-22" [label="contains"];
"section-9" -> "rule-23" [label="contains"];
"section-10" -> "rule-24" [label="contains"];
"section-10" -> "rule-25" [label="contains"];
"section-10" -> "rule-26" [label="contains"];
"section-10" -> "rule-27" [label="contains"];
"section-12" -> "rule-28" [label="contains"];
"section-12" -> "rule-29" [label="contains"];
"section-12" -> "rule-30" [label="contains"];
"section-13" -> "rule-31" [label="contains"];
"section-13" -> "rule-32" [label="contains"];
"section-13" -> "rule-33" [label="contains"];
"section-13" -> "rule-34" [label="contains"];
}Visualize it yourself: Paste the DOT code into GraphvizOnline
This compiler integrates with Google's Agent Development Kit as a custom agent:
from google.adk.agents import Agent
from google.adk.models.lite_llm import LiteLlm
from ggc.compiler import parse_policy, to_dot
def compile_policy(policy_text: str) -> str:
"""Compiles markdown policy into a governance graph."""
# ... implementation
return graph_json
root_agent = Agent(
name="governance_agent",
model=LiteLlm(model="openai/gpt-4o-mini"),
instruction="You are a Governance Graph Compiler agent...",
tools=[compile_policy, analyze_graph, graph_to_dot],
)The governance agent running in ADK's development UI:
| Compile | Analyze | Visualize |
|---|---|---|
 |
 |
 |
Write policies in Markdown using headings and bullet points:
# Main Section (level 1)
- Rule under main section
- Another rule
## Subsection (level 2)
- Rule under subsection
### Deep subsection (level 3)
- More specific ruleSupported syntax:
#,##,###... for section hierarchy-or*for rule bullet points- Plain text lines become rules under current section
ggc compile --policy <path> --out <directory>from pathlib import Path
from ggc.compiler import parse_policy, to_dot, write_graph
# Parse policy file
graph = parse_policy(Path("policy.md"))
# Access graph data
print(f"Sections: {len([n for n in graph.nodes if n['type'] == 'section'])}")
print(f"Rules: {len([n for n in graph.nodes if n['type'] == 'rule'])}")
# Export to DOT format
dot_string = to_dot(graph)
# Write both JSON and DOT files
write_graph(graph, Path("output/"))@dataclass
class Graph:
nodes: List[dict] # {"id", "label", "type", "level"?}
edges: List[dict] # {"from", "to", "label"}- Phase 1: Policy parsing (Markdown → AST)
- Phase 2: Graph construction (AST → Graph)
- Phase 3: Runtime simulation (Graph → Execution)
- Phase 4: Advanced visualization (Interactive UI)
MIT - See LICENSE for details.
Note: This is an exploratory research tool. Outputs are drafts requiring human review. Not a legal or compliance authority.
