Project Structure:

• cloudflare: Secure serverless hosting
• cloudflare workers: Running the Hono rest API
• cloudflare pages - NextJS Frontend: NextJS15 frontend
• cloudflare D1: SQLite's database for pages and workers to query

custos/
├── README.md
├── database/
│   └── init.sql
├── frontend/
│   └── (Next.js application files)
├── workers/
│   └── api/
│       ├── package.json
│       ├── wrangler.toml
│       ├── src/
│       │   └── index.js
│       └── dist/
│           └── (compiled worker files)
└── terraform/
    ├── main.tf
    ├── variables.tf
    ├── outputs.tf
    ├── terraform.tfvars
    └── modules/
        ├── cloudflare-pages/
        │   ├── main.tf
        │   ├── variables.tf
        │   └── outputs.tf
        ├── cloudflare-workers/
        │   ├── main.tf
        │   ├── variables.tf
        │   └── outputs.tf
        ├── cloudflare-d1/
        │   ├── main.tf
        │   ├── variables.tf
        │   └── outputs.tf
        └── cloudflare-dns/
            ├── main.tf
            ├── variables.tf
            └── outputs.tf

Repository layout

Path	Purpose
terraform/	Root Terraform configuration plus modules for D1, Workers, Pages, and DNS.
frontend/	Next.js application bundled with @opennextjs/cloudflare for Pages.
workers/api/	Hono API worker targeting D1 and exposing /api/users, /api/posts, and health endpoints.
database/	Cloudflare D1 assets and supporting SQL files.
steps.md	Field notes and caveats gathered during manual setup—mirrored throughout this README.

API Endpoints

The API is built using Hono on Cloudflare Workers, providing various endpoints to interact with the D1 database. Base URL: http://api.custos.space (Note: Cloudflare typically redirects HTTP requests to HTTPS for security. Your API will most likely be accessed via https://api.custos.space).

Endpoints:

• Healthcheck:

  • GET http://api.custos.space/health
  • Checks the health and responsiveness of the API.

• Users:

  • GET http://api.custos.space/users
  • Retrieves a list of users. Supports keyset pagination.
  • Query Parameters:
    • limit: (Optional) Maximum number of users to return (default: 20, max: 100).
    • cursor_id: (Optional) The ID of the last user from the previous page for pagination.
  • Example (first 2 users): http://api.custos.space/users?limit=2
  • Example (next 2 users after ID 2): http://api.custos.space/users?limit=2&cursor_id=2
  • GET http://api.custos.space/users/:id
  • Retrieves a single user by their ID.
  • Example: http://api.custos.space/users/1

Prerequisites

• Active Cloudflare account with a domain delegate-able to Cloudflare DNS.
• Terraform ≥ 1.0.
• Node.js 20+ (or Bun) for the frontend and worker builds.
• Wrangler CLI (installed via bun install --global wrangler or using the project-local dependency).
• GitHub repository containing the frontend code (required for Pages deployment).

Provisioning workflow

1. Delegate DNS to Cloudflare

   • Add your domain to Cloudflare, update registrar nameservers, and wait until the zone status is Active.
   • Record the zone ID (cloudflare_zone_id) and account ID (cloudflare_account_id).

2. Create a scoped API token

   • Minimum scopes: Zone:Read, Zone:DNS:Edit, Account:Workers Scripts:Edit, Account:D1 Databases:Edit (or Write), Account:Cloudflare Pages:Edit, Account Settings:Read.
   • Export it for Terraform (export TF_VAR_cloudflare_api_token="<token>") or populate terraform/terraform.tfvars (avoid committing secrets).

3. Wire Cloudflare Pages to GitHub

   • Install the Cloudflare Pages GitHub App and grant access to the repository referenced by github_repo.
   • Ensure the production_branch (default production) builds locally with the configured command (build_config.build_command).

4. Local preparation

   • API worker

     cd workers/api
     bun install
     bun run build:bundle   # produces dist/worker.js for validation

     The Terraform module expects api_worker_script_path to point at the compiled module (default ./workers/api/src/index.js). Adjust the variable if you relocate the bundle.

   • Frontend

     cd frontend
     bun install
     bun run build

     Development uses Turbopack (next dev --turbopack), but keep the production build command as plain next build—do not enable Turbopack for the build script OpenNext deployments on cloudflare break with the turbopack flag enabled.

5. Configure Terraform variables

   • Edit terraform/terraform.tfvars and set:

     cloudflare_account_id = "..."
     cloudflare_zone_id    = "..."
     domain                = "custos.space"
     project_name          = "custos-frontend-production"
     project_name_staging  = "custos-frontend-staging"
     github_repo           = "owner/repo"
     production_branch     = "production"
     production_branch_staging = "staging"
     api_subdomain         = "api"

   • Add optional maps for frontend_environment_vars and api_environment_vars.

6. Apply Terraform

   cd terraform
   terraform init
   terraform plan
   terraform apply

   The apply will:

   • Create the D1 database and attach it to the Worker.
   • Upload the API Worker, bind the D1 database, and register routes at https://<api_subdomain>.<domain>/*.
   • Create production and staging Cloudflare Pages projects, configure environment variables (including NEXT_PUBLIC_API_URL), and connect builds to GitHub.
   • Create DNS records for the Pages project and API subdomain.

7. Verify the deployment

   • DNS: In Cloudflare → DNS, ensure A/CNAME records exist for the domain and the API subdomain.
   • Worker: Hit https://api.<domain>/api/health (or /api/healthcheck) once DNS propagates.
   • Pages: Cloudflare → Pages → project → confirm the build succeeded and the site responds at https://<domain>.

Environment configuration

Terraform inputs

• cloudflare_api_token (sensitive)
• cloudflare_account_id, cloudflare_zone_id
• domain, api_subdomain
• github_repo, production_branch, production_branch_staging
• build_config (build_command, destination_dir, root_dir) – adjust if your build output differs from .vercel/output/static.
• frontend_environment_vars, api_environment_vars – maps merged into the Pages project and Worker respectively.

Worker variables

• CORS_ORIGIN (comma-separated list). Production defaults to https://custos.space, development to *; update via Terraform's api_environment_vars for multiple origins.

Frontend variables

• NEXT_PUBLIC_API_URL is injected automatically by Terraform.
• Wallet connectivity expects NEXT_PUBLIC_WALLET_CONNECT_PROJECT_ID referenced in frontend/src/components/Providers/Web3ModalProvider.

Local development

API worker

cd workers/api
bun install
bun run dev

Frontend

cd frontend
bun install
bun run dev

When running locally, set NEXT_PUBLIC_API_URL (for example via .env.local) so the app points to the dev worker or production endpoint.

Deployment tips

• Build the frontend for Cloudflare before deploying:

  cd frontend
  rm -rf .open-next
  npx opennextjs-cloudflare build
  bunx wrangler deploy -c wrangler.jsonc -e production

• Use bun for consistency across local development and CI (bun install, bun run dev).
• The Worker build script (bun run build) performs a dry-run deploy for validation; review the generated bundle in dist/ if you change dependencies.

GitHub Actions & branch protections

• deploy-production.yml auto-builds the frontend with Bun/OpenNext and deploys to the production worker on every push to the production branch.
• deploy-staging.yml runs for pushes and pull requests targeting staging, deploying to the staging worker and optionally creating preview aliases per branch.
• protect-production.yml fails any pull request into production unless the source branch is staging, enforcing the staging → production promotion flow.
• Protect the production branch in GitHub (required reviews, status checks) so merges only happen via approved PRs from staging. Similarly, protect staging to ensure features merge via pull requests before promotion.

Troubleshooting

• Frontend routing: Confirm wrangler.jsonc lists the production routes:

  {
    "env": {
      "production": {
        "name": "cloudflare-fullstack-frontend",
        "routes": ["custos.space/*", "www.custos.space/*"]
      }
    }
  }

• Monitoring: Tail production worker logs with bunx wrangler tail -c wrangler.jsonc -e production --format pretty.

• API errors: The Hono app logs to console.error; inspect the Wrangler tail output for stack traces and ensure CORS_ORIGIN includes the calling origin.

Useful commands quick reference

# Terraform
terraform fmt && terraform validate
terraform apply -target=module.cloudflare_dns

# Wrangler
bunx wrangler deploy -c workers/api/wrangler.jsonc -e production
bunx wrangler tail -c workers/api/wrangler.jsonc -e production --format pretty

# Health checks
curl -i https://custos.space

# API calls (If under attack mode is set in cloudflare you cannot make CURL calls through terminal)
curl -i https://api.custos.space/health"  | jq .
curl "https://api.custos.space/users?limit=8&cursor_id=2" | jq .
curl "https://api.custos.space/posts?limit=8&cursor_id=2" | jq .

Keep steps.md updated alongside infrastructure changes so this README remains accurate.
