PX4-XPlane - PX4 X-Plane Integration Plugin

This project establishes a robust connection between X-Plane and PX4 SITL (Software In The Loop) to simulate drone flight in the X-Plane environment. Our goal is to deliver a realistic simulation experience where PX4 can control various drones within X-Plane, and with our continuous improvements, it's getting better all the time.

Latest Release - Version 3.0.0 (January 2025)

🎥 Video Tutorial

🆕 NEW VIDEO COMING SOON: A comprehensive PX4-XPlane 3.0 tutorial showcasing the major improvements, enhanced EKF stability, multi-threaded communication architecture, and automated setup workflow will be available soon! Stay tuned for the updated demonstration.

Current Video: Check out our v2.0.0 demo video for installation guide and basic features.

🎉 Major Release - Breaking Changes

⚠️ BREAKING CHANGES: Version 3.0.0 introduces significant structural changes for X-Plane SDK compliance and professional CI/CD workflows. Migration required from v2.x.

What's New in Version 3.0.0

🚁 Core Simulation Improvements

• 🎯 EKF2 Stability Fixes (Critical):

  • Resolved altitude drift and height estimate reset issues
  • GPS altitude noise reduced from σ=0.5m to σ=0.15m (3.3× improvement)
  • EKF2_GPS_P_NOISE properly tuned (0.01 → 0.15) across all aircraft
  • Barometer (±3mm) now correctly prioritized over GPS (±30cm)
  • Height estimate resets reduced from ~10/hour to rare occurrences
  • Eliminated false climb/descent detections caused by GPS noise

• ⚡ Multi-Threaded Communication Architecture:

  • Robust, stable PX4 ↔ X-Plane MAVLink communication
  • Asynchronous sensor data processing with thread-safe queues
  • HIL_SENSOR update rate increased to 250Hz (matches PX4 Gazebo standard)
  • Enhanced barometer noise modeling (3cm std dev) for proper liveness detection
  • Synchronized GPS-Barometer altitude quantization (5mm resolution)
  • Prevents sensor timeout/STALE errors

• 📡 Improved State Estimators:

  • EKF2 innovation gates relaxed for SITL environment (BARO_GATE: 8.0, GPS_V_GATE: 8.0)
  • COM_ARM_EKF_VEL tuned (0.8) to prevent false preflight velocity errors
  • Better sensor fusion between GPS, barometer, IMU
  • Stable attitude, position, and velocity estimation

🤖 Development & CI/CD

• 🤖 Automated CI/CD System: GitHub Actions workflows for cross-platform builds:

  • Automatic builds on every push to master (Windows, Linux, macOS in parallel)
  • Automated releases with pre-built binaries via version tags
  • 90-day artifact retention for testing builds
  • Real-time build status badges on README

• 📁 Plugin Structure Reorganization (X-Plane SDK Standards):

  • config.ini moved to 64/ folder (WITH the binary, not parent folder)
  • PX4 parameters organized in px4_airframes/ subdirectory
  • Consistent structure across all build methods (CMake, Visual Studio, Make)
  • Standard X-Plane fat plugin format (SDK 2.0)

• 🔧 Critical Build Fixes:

  • Fixed Linux case-sensitive include errors
  • Fixed macOS missing headers and linker errors
  • Fixed Windows MSVC output path issues
  • Proper Eigen library submodule integration

• 🍎 macOS Improvements:

  • Fixed framework linking (using flat namespace with dynamic lookup)
  • Universal Binary support (Intel x86_64 + Apple Silicon ARM64)
  • Proper X-Plane plugin runtime symbol resolution

• 📦 Build System Consistency:

  • CMakeLists.txt updated to v3.0.0 with file organization
  • Visual Studio Debug/Release now produce identical structures
  • All platforms build successfully via GitHub Actions

🖥️ User Interface

• Connection Status HUD: Professional on-screen feedback for SITL connection
  • Real-time progress indicator with elapsed time (0-30 seconds)
  • Visual states: WAITING (yellow), CONNECTED (green), TIMEOUT (red), ERROR (orange)
  • Auto-fade success notification after 3 seconds
  • Configurable via show_connection_status_hud in config.ini

⚠️ Migration from v2.x to v3.0.0

Old Structure (v2.x):

px4xplane/
├── config.ini                    ← Root folder
├── 64/win.xpl
└── 5001_xplane_cessna172         ← Scattered params

New Structure (v3.0.0):

px4xplane/
├── 64/
│   ├── win.xpl
│   └── config.ini                ← WITH binary
├── px4_airframes/                ← Organized
│   ├── 5001_xplane_cessna172
│   ├── 5002_xplane_tb2
│   ├── 5010_xplane_ehang184
│   ├── 5020_xplane_alia250
│   └── 5021_xplane_qtailsitter
└── README.md

To upgrade: Remove old v2.x installation and download v3.0.0 from Releases. See CHANGELOG.md for complete migration guide.

🚀 PX4 Official Integration Status

Coming Soon: px4xplane is being prepared for official integration into the main PX4-Autopilot repository. Until the pull request is merged:

• Use the automated setup script (recommended): Installs PX4 SITL with px4xplane support automatically

  cd ~ && curl -O https://raw.githubusercontent.com/alireza787b/px4xplane/master/setup/setup_px4_sitl.sh && bash setup_px4_sitl.sh

• Or use the forked PX4 repo: PX4-Autopilot-Me (branch: px4xplane-sitl)
• Full installation guides: See Usage Guide below for detailed instructions

Once merged with official PX4, you'll be able to use the standard PX4-Autopilot repository directly.

---

Previous Release - Version 2.5.2 (January 2025)

🎥 Video Tutorials

Current Video: Check out our v2.0.0 demo video where we walk you through the simplified setup process, showcase the multi-airframe support, and test various drones like the Ehang 184, Alia 250, Cessna 172, and Bayraktar TB2.

👉 Watch the current demo and installation guide here!

🆕 NEW VIDEO COMING SOON: A comprehensive PX4-XPlane 2.5 tutorial showcasing the latest improvements, enhanced UI, and cross-platform support will be available soon! Stay tuned for the updated demonstration.

What's New in Version 2.5.2

• 🔨 Unified Cross-Platform Build System: Complete build system overhaul with CMake support:
  • CMakeLists.txt: Modern cross-platform build configuration (Windows, Linux, macOS)
  • Makefile.linux: Native Linux builds with GCC/Clang
  • Makefile.macos: Native macOS builds with Universal Binary support (Intel + Apple Silicon)
  • Single unified build process across all platforms
  • Easy for contributors and developers
• 📖 Comprehensive Build Documentation: New detailed Build Guide with:
  • Step-by-step build instructions for all platforms
  • Prerequisites and troubleshooting
  • IDE integration guides (VS Code, CLion, Xcode)
  • Advanced build options
• 🧹 Project Organization: Clean separation of build artifacts with proper .gitignore patterns

Previous Release - Version 2.5.1 (January 2025)

• 🎯 Height Estimate Stability Fix: Resolved altitude drift and EKF2 reset issues:
  • Reduced GPS altitude noise from 0.5m to 0.15m (matches high-quality GPS vertical accuracy)
  • Updated EKF2_GPS_P_NOISE parameter from 0.01 to 0.15 across all aircraft configurations
  • Eliminated ±1m GPS altitude jumps that caused EKF2 to incorrectly detect climbing/descending
  • Height estimate now stable with barometer (±3mm) properly prioritized over GPS (±30cm)
• 🖥️ Connection Status HUD: Professional HUD-style overlay for connection feedback:
  • Real-time connection progress indicator with elapsed time display
  • 30-second timeout with clear warning messages
  • Auto-fade success notification after 3 seconds
  • Clean, minimal design following X-Plane standards (top-center positioning)
  • Configurable via show_connection_status_hud in config.ini
• 🔧 Parameter Cleanup: Removed non-existent PX4 parameters causing errors:
  • Cleaned up VT_F_TRANS_RAMP, VT_DWN_PITCH_MAX, FW_T_SPD_OMEGA, FW_T_I_GAIN_THR from Alia250 config
  • Added explanatory comments for all removed parameters
• ⚡ Performance Optimization: Debug logging disabled by default for production use

Previous Release - Version 2.5.0 (January 2025)

• 🎯 Critical Sensor Stability Fix: Resolved BARO STALE errors and vertical velocity oscillation issues:
  • Increased HIL_SENSOR update rate from 100Hz to 250Hz (matches PX4 Gazebo SITL standard)
  • Enhanced barometer noise modeling (3cm std dev) for proper liveness detection
  • Synchronized GPS-Barometer altitude quantization (5mm resolution) to eliminate EKF2 innovation conflicts
  • Relaxed EKF2 innovation gates (BARO_GATE, GPS_V_GATE: 8.0) for SITL environment
  • Tuned COM_ARM_EKF_VEL parameter (0.8) to prevent false preflight velocity errors
• 🖥️ Enhanced User Interface: Professional high-contrast UI system with centralized version management and color-coded status indicators
• 🐧🍎 Cross-Platform Support: Native Linux and macOS makefile support for seamless compilation across all major platforms
• 📦 Portability Improvements: Project uses relative paths and external dependencies properly excluded from version control
• 🔧 Stability Enhancements: Multiple under-the-hood improvements for reliable SITL simulation performance

Previous Features (v2.0.0)

• Sensor Improvements: Fixed many sensor problems and inconsistencies.
• Multi-Airframe Support: Native support for multiple airframes including:
  • Ehang 184
  • Alia 250
  • Cessna 172
  • Bayraktar TB2
• In-Menu Airframe Selection: Change airframes directly from the X-Plane menu.
• Automated Setup Script: A full automation script that sets everything up for you in WSL or Linux environments.
• Detailed Configuration Instructions: The config.ini file includes instructions for building custom airframes.
• Pre-Loaded Parameters: Parameters are automatically loaded in PX4 build commands.

Check out the latest features in the v2.5.0 release.

Video Tutorials

For setup guidance and demonstrations, visit our YouTube playlist, which includes detailed tutorials and showcases the plugin in action!

Introduction

We bridge X-Plane and PX4 using the Simulator MAVLink API, which facilitates the exchange of sensor and actuator data, providing a rich and accurate simulation environment.

The following table illustrates the message flow:

Message	Direction	Description
MAV_MODE:MAV_MODE_FLAG_HIL_ENABLED	NA	Mode flag when using simulation. All motors/actuators are blocked, but internal software is fully operational.
HIL_ACTUATOR_CONTROLS	PX4 to Sim	PX4 control outputs (to motors, actuators).
HIL_SENSOR	Sim to PX4	Simulated IMU readings in SI units in NED body frame.
HIL_GPS	Sim to PX4	The simulated GPS RAW sensor value.
HIL_OPTICAL_FLOW	Sim to PX4	Simulated optical flow from a flow sensor (e.g., PX4FLOW or optical mouse sensor).
HIL_STATE_QUATERNION	Sim to PX4	Contains the actual "simulated" vehicle position, attitude, speed, etc. This can be logged and compared to PX4's estimates for analysis and debugging.
HIL_RC_INPUTS_RAW	Sim to PX4	The RAW values of the RC channels received.

Building from Source

The px4xplane plugin supports true cross-platform development on Windows, Linux, and macOS.

Quick Build Guide

CMake (Recommended - All Platforms):

git clone --recursive https://github.com/alireza787b/px4xplane.git
cd px4xplane
mkdir build && cd build
cmake .. -DCMAKE_BUILD_TYPE=Release
cmake --build .

Windows (Visual Studio):

1. Open px4-xplane.sln in Visual Studio 2019/2022
2. Select Release | x64
3. Build → Build Solution

Linux:

make -f Makefile.linux

macOS:

make -f Makefile.macos

📖 For detailed build instructions, prerequisites, and troubleshooting, see the comprehensive Build Documentation.

Pre-Built Binaries (Recommended for Users)

Don't want to build from source? Download pre-built binaries from the Releases page:

• 🪟 Windows (x64)
• 🐧 Linux (x64)
• 🍎 macOS (Universal: Intel + Apple Silicon)

All platforms are automatically built and tested via GitHub Actions CI/CD on every release.

Development Workflow

For Contributors:

• Work on master branch for regular development
• Push to master triggers builds (artifacts kept 90 days)
• Create version tag (v3.1.0) to trigger automatic release with binaries

📖 For complete developer workflow, versioning, and CI/CD, see Developer Guide.

---

Known Issues

• Performance: Ensure X-Plane runs at high FPS for optimal EKF performance.
• Temporary Fix: This plugin is a temporary fix until merged with the official PX4 repository. For now, we use a forked version of PX4 with custom airframes and modifications.
• Bug Reports: If you find any bug, please report it on the GitHub issues page.

Usage Guide

For full step-by-step instructions, follow the Version 2 Documentation.

Automated Setup Script

This automated script is optimized for WSL (Windows Subsystem for Linux), where X-Plane runs on Windows and PX4 SITL runs on Linux (WSL). It also works natively on Ubuntu, Linux, and macOS distributions.

To quickly set up PX4 with X-Plane using WSL (Ubuntu 22.04 or newer), follow this simple step:

1. Run the setup script directly from your terminal:

   First, make sure you are in your WSL Ubuntu terminal (launch it from PowerShell), then enter the following command:

   cd ~ && curl -O https://raw.githubusercontent.com/alireza787b/px4xplane/master/setup/setup_px4_sitl.sh && bash setup_px4_sitl.sh

Script Features

• Auto-Update Detection: Automatically checks for updates on subsequent runs
• Self-Updating: Script updates itself when new versions are available
• Quick Skip: Press 's' during update check for instant start (perfect for quick iterations)
• Smart Defaults: Auto-proceeds with sensible defaults if no input provided
• Robust Error Handling: Graceful fallbacks if network is unavailable
• Repair Mode: Use --repair flag to force full re-setup if needed

Important Notes

• First-Time Setup: The installation may take 10-20 minutes, depending on your system, especially the first time
• Subsequent Runs: Script automatically detects existing installation and offers to check for updates
• Interactive Prompts: You can customize the setup or use defaults (auto-proceeds after timeout)
• Cross-Platform: Supports WSL, native Linux, and macOS
• Update Check: Press 's' to skip update check for quick start, or wait 5 seconds to check for updates

Typical Usage after first setup

Subsequent runs (with update check):

px4xplane
# Wait 5 seconds or press any key to check for updates
# Select airframe and run

Quick start (skip updates):

px4xplane
# Press 's' immediately to skip update check
# Instant start

Force update/repair:

px4xplane --repair
# Forces full setup and update

Available Airframes

The script supports 5 pre-configured X-Plane airframes:

• xplane_cessna172 - Cessna 172 (fixed-wing trainer)
• xplane_tb2 - TB2 UAV (fixed-wing)
• xplane_ehang184 - Ehang 184 (quadcopter airtaxi)
• xplane_alia250 - Alia-250 (eVTOL quadplane)
• xplane_qtailsitter - Quantix (quad tailsitter VTOL)

Uninstall

To remove the global paths and the px4xplane command:

px4xplane --uninstall

This will remove:

• The global px4xplane command
• The PX4-Autopilot-Me repository
• Configuration files

Troubleshooting

Update check fails:

• Script continues with local version
• Or use repair mode: px4xplane --repair

Build errors:

• Try clean build: px4xplane
• When prompted, type 'c' for clean or 'd' for distclean

Script outdated:

• Script auto-updates itself
• Or manually download latest:

cd ~ && curl -O https://raw.githubusercontent.com/alireza787b/px4xplane/master/setup/setup_px4_sitl.sh && bash setup_px4_sitl.sh

Manual Advanced Setup

For advanced users who prefer manual control, you can clone and set up the environment using the forked PX4 repository:

1. Clone the repository:

   git clone https://github.com/alireza787b/PX4-Autopilot-Me.git --recursive
   cd PX4-Autopilot-Me
   git checkout px4xplane-sitl

2. Set up the environment:

   bash ./Tools/setup/ubuntu.sh

3. Configure PX4 SITL (WSL users only):

   • In Windows Terminal, check your IP address (e.g., 172.21.144.1):

     ipconfig

   • In the WSL Terminal, inside the PX4-Autopilot-Me directory, set the PX4 simulation hostname with your IP:

     export PX4_SIM_HOSTNAME=172.21.144.1

4. Build the desired airframe:

   make px4_sitl_default xplane_ehang184

   Replace xplane_ehang184 with your desired airframe from the list above.

Note for Native Linux Users: If both X-Plane and PX4 run on the same Linux machine, the IP configuration step (step 3) may not be needed. You can use localhost or 127.0.0.1.

Refer to the PX4 official documentation for more details, but use the forked repository (PX4-Autopilot-Me branch px4xplane-sitl) instead of the official PX4 repo.

Temporary Notice

⚠️ Testing Phase: This setup currently uses a forked PX4 repository while X-Plane SITL support is being prepared for submission to the official PX4 repository. Once the pull request is merged into https://github.com/PX4/PX4-Autopilot, you will be able to use the official PX4 repository directly, and this fork will no longer be needed. The setup script will be updated accordingly.

Track progress: https://github.com/alireza787b/PX4-Autopilot-Me/tree/feature/xplane-sitl-integration

Defining Custom Airframes

If you need to define new airframes for your simulation, follow the detailed guide here:

👉 How to Define Custom Airframes in PX4-XPlane

This guide will walk you through the process of setting up custom configurations, mapping PX4 channels to X-Plane datarefs, and integrating new airframes into your simulations. Whether you're using existing X-Plane models or creating new ones in Plane Maker, this guide has you covered.

---

Technical Improvements in Version 2.5.0

Sensor Stability and EKF2 Performance

Version 2.5.0 addresses critical sensor timing and fusion issues that previously caused BARO STALE errors and vertical velocity instability:

HIL_SENSOR Update Rate Optimization

• Increased from 100Hz to 250Hz to match PX4's lockstep timing expectations
• Prevents sensor timeout/STALE errors by ensuring consistent high-frequency updates
• Aligns with PX4 Gazebo SITL standard for optimal sensor fusion

Barometer Modeling

• Enhanced noise model (3cm standard deviation) ensures PX4 properly detects sensor liveness
• Synchronized altitude quantization (5mm) with GPS to eliminate innovation conflicts
• Prevents temporal misalignment between different height sources in EKF2

EKF2 Parameter Tuning

• Relaxed innovation gates (EKF2_BARO_GATE: 8.0, EKF2_GPS_V_GATE: 8.0) for SITL environment
• Adjusted COM_ARM_EKF_VEL (0.8) to prevent false velocity limit exceeded errors
• Optimized for simulation timing characteristics while maintaining accuracy

User Interface Enhancements

Professional high-contrast UI system with:

• Centralized version management (VersionInfo.h)
• Color-coded connection status indicators
• Improved readability and real-time debugging information

Cross-Platform Compatibility

With native Linux and macOS makefile support, PX4-XPlane 2.5.0 ensures seamless compilation and operation across all major platforms, making it accessible to a broader range of developers and researchers.

---

Contribution and Support

Feel free to reach out to me in the issue section if you need help. Having experienced contributors is greatly appreciated!

License

This project is licensed under the MIT License. See the LICENSE file for more details.
