Gicisky BLE Label Home Assistant Integration

Gallery

Size	Example
2.1" (250x128)
2.9" (296x128)
10.2" (960x640)

What Is an Electronic Label?

An Electronic Label (also known as an Electronic Shelf Label, ESL) is a small display device that uses
electronic paper (e-paper) instead of traditional paper.

Once content is displayed, it remains visible without consuming power,
making electronic labels extremely energy-efficient and well suited for always-on information display.

This project uses electronic labels manufactured by Gicisky.

Key Characteristics

• 📄 E-paper display
  • Paper-like appearance with excellent readability
• 🔋 Ultra-low power consumption
  • Power is only used when the display is updated
• 📡 Wireless communication
  • Display content can be updated remotely
• 📐 Compact and lightweight
  • Easy to mount on walls, shelves, doors, or devices

Although electronic labels are commonly associated with retail price tags,
their core value lies in being small, persistent, and power-efficient displays.

Why Electronic Labels?

Electronic labels are ideal for displaying information that:

• Needs to be visible at all times
• Does not change frequently
• Must be shown in locations where continuous power is impractical

This project focuses on these fundamental characteristics and explores electronic labels
beyond their traditional use cases.

💬 Feedback & Support

🐞 Found a bug? Let us know via an Issue.
💡 Have a question or suggestion? Join the Discussion!

---

Supported Models

Type	Size	Resolution	Colors
TFT	2.1"	250 × 132	BW
EPD	2.1"	250 × 128	BWR
EPD	2.9"	296 × 128	BW
EPD	2.9"	296 × 128	BWR
EPD	2.9"	296 × 128	BWRY
EPD	3.7"	240 × 416	BWR
EPD	4.2"	400 × 300	BWR
EPD	7.5"	800 × 480	BWR
EPD	10.2"	960 × 640	BWR

Where to Buy

• In my country, I can purchase from the official site linked below, but I am not sure if it is available for purchase in all countries.

• AliExpress - Gicisky Official Store

• AliExpress - Gicisky Official Store

Installation

1. Install this integration with HACS (adding repository required), or copy the contents of this repository into the custom_components/gicisky directory.
2. Restart Home Assistant.

⚠️ Important Notice

• It is strongly recommended to use a Bluetooth proxy instead of a built-in Bluetooth adapter.
  Bluetooth proxies generally offer more stable connections and better range, especially in environments with multiple BLE devices.

Tip

For hardware recommendations, refer to Great ESP32 Board for an ESPHome Bluetooth Proxy.

• When using a Bluetooth proxy, it is strongly recommended to keep the scan interval at its default value.
  Changing these values may cause issues with Bluetooth data transmission.

• bluetooth_proxy: must always have active: true.

  Example (recommended configuration with default values):

  esp32_ble_tracker:
    scan_parameters:
      active: true

  bluetooth_proxy:
    active: true

Options

After adding a device, you can configure the following options via Settings > Devices & Services > Gicisky > Configure:

Option	Default	Range	Description
Retry Count	3	1–10	Number of retry attempts when BLE write fails
Write Delay (ms)	0	0–1000	Delay in milliseconds between each BLE write operation
Prevent Duplicate Send	false	true/false	If enabled, prevents sending the same image data consecutively to save battery and reduce traffic

Tip

If you experience frequent write failures, try increasing the Retry Count.
If writes are unstable, try setting Write Delay to 50–100 ms to give the device more time to process each packet.

---

Service: gicisky.write

Service Parameters

Parameter	Required	Default	Description
payload	✅	—	List of drawing elements (see Payload Element Types)
rotate	❌	0	Image rotation: 0, 90, 180, 270
background	❌	white	Background color: white, black, red
threshold	❌	128	Black binary threshold (0–255)
red_threshold	❌	128	Red binary threshold (0–255)
dry_run	❌	false	Generate preview image without sending to device

Basic Usage

action: gicisky.write
data:
  payload:
    - type: text
      value: Hello World!
      x: 10
      y: 10
      size: 40
target:
  device_id: <your device>

Rotation & Background

action: gicisky.write
data:
  rotate: 90
  background: black
  payload:
    - type: text
      value: Rotated!
      x: 10
      y: 10
      size: 30
      color: white
target:
  device_id: <your device>

Dry Run (Preview Only)

Preview image is available via the Camera entity without sending data to the physical device.

Tip

You can use the Gicisky Payload Editor to design a rough layout via drag-and-drop in your browser and automatically generate YAML. Use the generated YAML with dry_run: true to preview it without sending data to the actual device.

action: gicisky.write
data:
  dry_run: true
  payload:
    - type: text
      value: Preview Test
      x: 10
      y: 10
      size: 30
target:
  device_id: <your device>

---

Payload Element Examples

Tip

All elements support the visible field (true/false) to conditionally show or hide them.

text

- type: text
  value: "Hello World!"
  x: 10
  y: 10
  size: 40
  font: "fonts/NotoSansKR-Bold.ttf"
  color: black
  anchor: lt            # Pillow anchor (e.g. lt, mt, rt, lm, mm, rm)
  align: left           # left, center, right
  spacing: 5
  stroke_width: 1
  stroke_fill: white
  max_width: 200        # Auto-wrap text within this pixel width

If y is omitted the element stacks below the previous element automatically (y_padding controls the gap, default 10).

multiline

- type: multiline
  value: "Line1;Line2;Line3"
  delimiter: ";"
  x: 10
  start_y: 10           # Starting Y position (auto-stacks if omitted)
  offset_y: 25           # Y spacing between lines (required)
  size: 20
  font: "fonts/NotoSansKR-Regular.ttf"
  color: black
  anchor: lm
  stroke_width: 0
  stroke_fill: white

line

- type: line
  x_start: 0
  x_end: 250
  y_start: 64
  y_end: 64
  fill: black
  width: 2

If y_start is omitted the line is drawn at the current auto-stack Y position (y_padding offset).

rectangle

- type: rectangle
  x_start: 5
  y_start: 5
  x_end: 100
  y_end: 60
  fill: red
  outline: black
  width: 2
  radius: 10            # Corner radius for rounded rectangle
  corners: "top_left,top_right"  # all / top_left / top_right / bottom_right / bottom_left

rectangle_pattern

- type: rectangle_pattern
  x_start: 10
  y_start: 10
  x_size: 20
  y_size: 20
  x_repeat: 5
  y_repeat: 3
  x_offset: 5
  y_offset: 5
  fill: black
  outline: black
  width: 1
  radius: 5
  corners: "all"

circle

- type: circle
  x: 125               # Center X
  y: 64                 # Center Y
  radius: 30
  fill: red
  outline: black
  width: 2

ellipse

- type: ellipse
  x_start: 50
  y_start: 20
  x_end: 200
  y_end: 100
  fill: red
  outline: black
  width: 1

icon

Uses Material Design Icons. You can use the icon name with or without the mdi: prefix.

- type: icon
  value: "weather-sunny"     # or "mdi:weather-sunny"
  x: 10
  y: 10
  size: 48
  color: black               # or use fill
  anchor: la
  stroke_width: 0
  stroke_fill: white

dlimg

Supports HTTP/HTTPS URLs, local file paths, and Base64 data URIs.

- type: dlimg
  url: "https://example.com/image.png"
  x: 10
  y: 10
  xsize: 100
  ysize: 100
  rotate: 0

# Local file
- type: dlimg
  url: "/config/www/images/photo.png"
  x: 0
  y: 0
  xsize: 250
  ysize: 128

# Base64 data URI
- type: dlimg
  x: 10
  y: 10
  xsize: 50
  ysize: 50

qrcode

- type: qrcode
  data: "https://www.home-assistant.io"
  x: 140
  y: 10
  boxsize: 2
  border: 1
  color: black
  bgcolor: white

barcode

- type: barcode
  data: "123456789012"
  x: 10
  y: 80
  code: code128             # code128, ean13, ean8, upc, isbn13, etc.
  color: black
  bgcolor: white
  module_width: 0.2
  module_height: 7
  quiet_zone: 6.5
  font_size: 5
  text_distance: 5.0
  write_text: true

diagram

- type: diagram
  x: 0
  y: 0
  width: 250
  height: 128
  margin: 20
  font: "fonts/NotoSansKR-Regular.ttf"
  bars:
    values: "Mon,10;Tue,25;Wed,15;Thu,30;Fri,20"
    color: black
    margin: 10
    legend_size: 10
    legend_color: black

plot

Reads entity history from Home Assistant Recorder.

- type: plot
  data:
    - entity: sensor.temperature
      color: black
      width: 2
  duration: 86400          # Seconds (default: 86400 = 1 day)
  x_start: 30
  y_start: 10
  x_end: 290
  y_end: 120
  size: 10
  font: "fonts/NotoSansKR-Regular.ttf"
  low: 15                  # Fixed Y-axis minimum
  high: 35                 # Fixed Y-axis maximum
  ylegend:
    width: -1              # Auto-calculate
    color: black
    position: left         # left or right
  yaxis:
    width: 1
    color: black
    tick_width: 2
    tick_every: 5
    grid: 5
    grid_color: black
  debug: false

progress_bar

- type: progress_bar
  x_start: 10
  y_start: 100
  x_end: 240
  y_end: 120
  progress: 75
  direction: right          # right, left, up, down
  background: white
  fill: red
  outline: black
  width: 1
  show_percentage: true

---

Combined Example

action: gicisky.write
data:
  rotate: 0
  background: white
  payload:
    - type: text
      value: "Home Status"
      x: 10
      y: 5
      size: 24
      font: "fonts/NotoSansKR-Bold.ttf"
    - type: line
      x_start: 0
      x_end: 250
      y_start: 35
      y_end: 35
      fill: black
      width: 1
    - type: icon
      value: thermometer
      x: 10
      y: 45
      size: 24
      color: black
    - type: text
      value: "{{ states('sensor.temperature') }}°C"
      x: 40
      y: 48
      size: 20
    - type: progress_bar
      x_start: 10
      y_start: 80
      x_end: 240
      y_end: 95
      progress: "{{ states('sensor.humidity') | int }}"
      direction: right
      fill: black
      show_percentage: true
    - type: qrcode
      data: "https://www.home-assistant.io"
      x: 180
      y: 40
      boxsize: 2
      border: 1
target:
  device_id: <your device>

---

Payload Element Types

Tip

All elements support the visible field (true/false, default: true) to conditionally show or hide them.

Type	Required Fields	Optional Fields	Description
text	x, value	y, size(20), font, color(black), anchor(lt), align(left), spacing(5), stroke_width(0), stroke_fill(white), max_width, y_padding(10)	Draws text (auto-wrap if max_width provided). Auto-stacks if y omitted.
multiline	x, value, delimiter, offset_y	start_y, size(20), font, color(black), anchor(lm), stroke_width(0), stroke_fill(white), y_padding(10)	Splits text by delimiter and draws each line with offset_y spacing.
line	x_start, x_end	y_start, y_end, fill(black), width(1), y_padding(0)	Draws a straight line. Auto-stacks if y_start omitted.
rectangle	x_start, x_end, y_start, y_end	fill, outline(black), width(1), radius(0), corners(all)	Draws a rectangle with optional rounded corners.
rectangle_pattern	x_start, y_start, x_size, y_size, x_repeat, y_repeat, x_offset, y_offset	fill, outline(black), width(1), radius(0), corners(all)	Repeated grid of rectangles (pattern/tiling).
circle	x, y, radius	fill, outline(black), width(1)	Draws a circle at center (x, y).
ellipse	x_start, x_end, y_start, y_end	fill, outline(black), width(1)	Draws an ellipse inside a bounding box.
icon	x, y, value, size	color/fill(black), anchor(la), stroke_width(0), stroke_fill(white)	Draws Material Design Icons. Supports mdi: prefix.
dlimg	x, y, url, xsize, ysize	rotate(0)	Loads image from URL, local path, or Base64 data URI.
qrcode	x, y, data	color(black), bgcolor(white), border(1), boxsize(2)	Generates and embeds a QR code.
barcode	x, y, data	color(black), bgcolor(white), code(code128), module_width(0.2), module_height(7), quiet_zone(6.5), font_size(5), text_distance(5.0), write_text(true)	Draws various barcode formats.
diagram	x, y, height	width(canvas), margin(20), font, bars	Creates a bar chart. bars object: values(required, "name,val;...") color(required), margin(10), legend_size(10), legend_color(black).
plot	data([{entity}])	duration(86400), x_start(0), y_start(0), x_end, y_end, size(10), font, low, high, ylegend, yaxis, debug(false)	Time-series graph from HA Recorder. Per-series: entity(required), color(black), width(1), joint.
progress_bar	x_start, x_end, y_start, y_end, progress	direction(right), background(white), fill(red), outline(black), width(1), show_percentage(false)	Draws a progress bar. direction: right/left/up/down.

plot Sub-Objects

Sub-Object	Field	Default	Description
ylegend	width	-1 (auto)	Legend width in pixels
	color	black	Legend text color
	position	left	left or right
	font	(inherits)	Legend font file
	size	(inherits)	Legend font size
yaxis	width	1	Axis line width
	color	black	Axis color
	tick_width	2	Tick mark width
	tick_every	1	Tick interval (value unit)
	grid	5	Grid dot spacing (pixels)
	grid_color	black	Grid color

---

Fonts

The text, multiline, diagram, and plot elements accept a font field.
The default font is fonts/NotoSansKR-Regular.ttf.

Built-in Fonts

Family	Weights
CookieRun	fonts/CookieRunRegular.ttf, fonts/CookieRunBold.ttf, fonts/CookieRunBlack.ttf
Gmarket Sans	fonts/GmarketSansTTFLight.ttf, fonts/GmarketSansTTFMedium.ttf, fonts/GmarketSansTTFBold.ttf
Noto Sans KR	fonts/NotoSansKR-Thin.ttf, fonts/NotoSansKR-ExtraLight.ttf, fonts/NotoSansKR-Light.ttf, fonts/NotoSansKR-Regular.ttf, fonts/NotoSansKR-Medium.ttf, fonts/NotoSansKR-SemiBold.ttf, fonts/NotoSansKR-Bold.ttf, fonts/NotoSansKR-ExtraBold.ttf, fonts/NotoSansKR-Black.ttf
OwnglyphParkDaHyun	fonts/OwnglyphParkDaHyun.ttf

Custom Fonts

You can also use your own .ttf font files by placing them in your Home Assistant www/fonts directory:

/config/www/fonts/MyCustomFont.ttf

Then reference them by filename only:

- type: text
  value: "Custom Font"
  x: 10
  y: 10
  size: 30
  font: "MyCustomFont.ttf"

Note

The integration first looks for fonts in its own fonts/ directory, then falls back to www/fonts/ in your Home Assistant config.

---

Examples

Size	Example	Preview	Yaml
2.1" (250×128)	Date		2.1" Date
2.1" (250×128)	Naver Weather		2.1" Naver Weather
2.1" (250×128)	Waste Collection		2.1" Waste Collection
2.1" (250×128)	Wifi		2.1" Wifi
2.1" (250×128)	TMap time		2.1" TMap time
2.9" (296×128)	Google Calendar		2.9" Google Calendar
2.9" (296×128)	Presence Display		2.9" Presence Display
4.2" (400×300)	Image		4.2" Image
4.2" (400×300)	Naver Weather		4.2" Naver Weather
4.2" (400×300)	Date Weather		4.2" Date Weather
4.2" (400×300)	3D Print		4.2" 3D Print
7.5" (800×480)	Google Calendar		7.5" Google Calendar
7.5" (800×480)	Date Weather		7.5" Date Weather
10.2" (960×640)	Calendar Weather		10.2" Calendar Weather
10.2" (960×640)	Calendar		10.2" Calendar

---

Tools

Gicisky Image Edit & Uploader

Gicisky Payload Editor

---

Appendix

T-Map Integration

# https://openapi.sk.com/products/detail?linkMenuSeq=46
rest_command:
  request_tmap_routes:
    url: https://apis.openapi.sk.com/tmap/routes?version=1
    method: POST
    headers:
      appKey: !secret tmap_api_key
      accept: "application/json, text/html"
    content_type: "application/json; charset=utf-8"
    payload: >-
      {
        "startX": {{ startX }},
        "startY": {{ startY }},
        "endX": {{ endX }},
        "endY": {{ endY }},
        "searchOption": {{ searchOption }},
        "totalValue": 2,
        "trafficInfo ": "Y",
        "mainRoadInfo": "Y",
      }

Google Calendar

Remote Calendar -> Add google *.ics

Third-Party Custom Components

• Naver Weather (minumida)
• Waste Collection Schedule (mampfes)

---

References

• ATC GICISKY ESL (atc1441)
• OpenEPaperLink
• bthome
• bthome-ble
