Pytest Boardfarm

---

pytest-boardfarm3 is the extension that integrates Boardfarm with Pytest. It adapts Boardfarm's plugin/runner lifecycle into Pytest sessions and exposes convenient fixtures for tests and interactive sessions.

Prerequisites

• Boardfarm must be installed and available on the Python path (the plugin expects boardfarm3 APIs).
• Python 3.11+ is recommended (Boardfarm uses modern Python features).
• Pytest (and optionally pytest-html if you want HTML reports).

---

Table of contents

• Overview
• Quick install
• How the plugin loads
• Command-line options and selection
• Fixtures provided
• Markers
• Running tests — examples
• How the plugin orchestrates Boardfarm
• HTML report integration
• Troubleshooting & tips
• Development notes
• License

---

Overview

pytest-boardfarm is responsible for the following operations:

• Registers Boardfarm fixtures and a BoardfarmPlugin object that coordinates environment parsing, device registration, deployment and teardown.
• Exposes device_manager, boardfarm_config, bf_context and bf_logger fixtures to tests.
• Orchestrates a multi-phase boot/config lifecycle via Boardfarm pluggy hooks when pytest runs (deploys devices before tests and releases them at the end).
• Adds a small test selector (--test-names) to limit which tests are executed by name.
• Integrates with pytest-html to add Boardfarm deployment metadata and captured images to generated HTML reports.

---

Quick install

pip install "boardfarm3[pytest]"

Development Install

Install Boardfarm and the pytest plugin. If the plugin is packaged locally, install it in editable mode for development.

git clone http://github.com/lgirdk/pytest-boardfarm
cd pytest-boardfarm
pip install -e .     # if plugin packaged locally with proper entry-point

The plugin package should expose the pytest entry point so pytest can auto-discover it. Ensure boardfarm is also installed in the same environment.

How the plugin loads

There are two important registration points in the plugin code:

1. An early conftest hook registers a minimal fixtures module so small utilities are available early (bf_context, bf_logger). The heavier BoardfarmPlugin instance is registered conditionally based on detected command-line args.

2. The BoardfarmPlugin class is the main integration surface. It adds CLI args via boardfarm_add_cmdline_args, parses inventory and env JSONs, registers and sets up devices through Boardfarm pluggy hooks, and performs teardown and release at session end.

This separation allows lightweight test runs to use a couple of fixtures without provisioning devices, and it enables full Boardfarm provisioning only when requested.

Command-line options and selection

The plugin adds a test selection option named --test-names which accepts a space-separated list of logical test names. When provided, collected tests are filtered: only items matching normalized test_<name>.

Boardfarm's own CLI options (for example: board-name, env-config, inventory-config, skip-boot, skip-contingency-checks, save-console-logs) are exposed by the plugin through the BoardfarmPlugin lifecycle. Once the plugin is active you can inspect available options using pytest's help output.

$ pytest -h
usage: pytest [options] [file_or_dir] [file_or_dir] [...]

...
boardfarm:
  --board-name=BOARD_NAME
                        Board name
  --env-config=ENV_CONFIG
                        Environment JSON config file path
  --inventory-config=INVENTORY_CONFIG
                        Inventory JSON config file path
  --legacy              allows for devices.<device> obj to be exposed (only for legacy use)
  --skip-boot           Skips the booting process, all devices will be used as they are
  --skip-contingency-checks
                        Skip contingency checks while running tests
  --save-console-logs=SAVE_CONSOLE_LOGS
                        Save the console logs at the give location
  --ignore-devices=IGNORE_DEVICES
                        Ignore the given devices (names are comma separated). Useful when a device is incommunicado

Custom options:
  --test-names=TEST_NAMES
                        Test names for which the execution will be performed

---

Fixtures provided

The plugin exposes several fixtures aimed at easing device interaction, configuration access and contextual logging. Most of these are session scoped.

• bf_context (function scope): Returns a ContextStorage instance useful for sharing ephemeral data within a single test.

  def test_example(bf_context):
      bf_context['foo'] = 'bar'

• bf_logger (session autouse): Returns a TestLogger instance for step-level logging and tracing.

  def test_log(bf_logger):
      bf_logger.step("Connect to DUT")

• boardfarm_config (session): Returns the resolved BoardfarmConfig that the plugin created by merging inventory, env files and CLI overrides. Use this to inspect provisioning mode and environment definitions.

  def test_config(boardfarm_config):
      assert boardfarm_config.get_prov_mode() in ("ipv4","ipv6","dual")

• device_manager (session): Returns the DeviceManager that holds instantiated device objects constructed from the inventory. Use it to query devices by template/interface or type.

  def test_device(device_manager):
      cpe = device_manager.get_device_by_type(CPE)
      assert cpe is not None

These fixtures are intended to be the main integration points for tests and interactive sessions.

Important: Tests should call use-cases and obtain devices through device_manager rather than instantiating devices directly.

Markers

@pytest.mark.env_req(...)

env_req is a custom marker introduced by the plugin to declare an environment requirement for the test. If the current Boardfarm environment does not satisfy the requested env_req, the test will be skipped.

Example scenario: mark tests that require dual-stack provisioning.

import pytest

@pytest.mark.env_req({"environment_def": {"board": {"eRouter_Provisioning_mode": ["dual"]}}})
def test_tr069_dual_mode(device_manager):
    ...

During pytest_runtest_setup, the plugin validates the marker against the loaded boardfarm_config.env_config. If matched, the plugin also runs the contingency_check hook to ensure devices are healthy before test execution.

---

Running tests — examples

Run pytest and let boardfarm provision the environment as part of test setup. (typical invocation — boardfarm CLI args are forwarded by the plugin):

pytest -s \
    --rootdir=. \
    --board-name prplos-docker-1 \
    --env-config ./boardfarm3/configs/boardfarm_env_example.json  \
    --inventory-config ./boardfarm3/configs/boardfarm_config_example.json \
    --junitxml ./results/pytest_run_report.xml \
    --html=./results/pytest_run_report.html  \
    --self-contained-html  \
    --save-console-logs=./results  \
    ./tests/

• The pytest-boardfarm plugin reads the --env-config and --inventory-config options and uses them to build a BoardfarmConfig and a DeviceManager.
• Unless you pass --skip-boot, the plugin will call Boardfarm pluggy hooks to reserve, boot and configure services and devices before tests run.
• During tests, fixtures like device_manager and boardfarm_config become available for use cases and tests.
• After the run, boardfarm plugin will run device teardown and release hooks, and store the collected logs/reports in ./results directory.

--skip-contingency-checks option

When passed, boardfarm will skip running the per-device contingency_check hooks that normally run just before a test starts (or during provisioning) to validate that devices/services are healthy and meet the test’s env_req expectations.

Where contingency checks run

The plugin calls device-level contingency_check(env_req, device_manager) hooks when a test is about to run (if the test has an @pytest.mark.env_req(...)) or during provisioning to ensure devices are responsive and in the expected state.

These checks typically run commands like TR-069 calls, IP checks, or basic service pings on each device.

Why you might use --skip-contingency-checks

• Faster iteration during development (avoid waiting for slow health checks).
• Quick smoke runs where you don’t want the plugin to gate tests.
• When contingency checks are known to be flaky and you’re debugging other layers.

Risks / tradeoffs (important)

• You may run tests against unhealthy or misconfigured devices. Skipping checks removes a safety gate that would otherwise detect unreachable consoles, missing services or mis-provisioned DUTs.

• More flaky failures: tests may fail with confusing symptoms because the device wasn’t validated first.

• Harder root-cause: the bug might be environment-related (power, network, container not up), but you’ll only see it when tests fail — later in the cycle.

Recommendation

Use --skip-contingency-checks only for short development loops or when you explicitly know the environment is already healthy. For CI and official runs, prefer not to skip contingency checks so tests are executed against validated devices.

How the plugin orchestrates Boardfarm

High-level lifecycle the plugin implements:

1. pytest starts and early fixtures are registered.
2. When BoardfarmPlugin is active it adds Boardfarm CLI args and, on session start:
   • Calls the boardfarm_reserve_devices hook to reserve lab hardware or otherwise prepare inventory.
   • Calls the boardfarm_parse_config hook to merge inventory, env JSON and CLI overrides into a BoardfarmConfig.
3. During the test run the plugin:
   • Registers and instantiates device classes via boardfarm_register_devices.
   • Calls boardfarm_setup_env (async-capable) which triggers device-level hooks to boot and configure servers, devices and attached clients in the documented order.
4. Tests execute and call use-cases that use templated APIs; DeviceManager supplies the correct concrete implementation at runtime.
5. After tests complete the plugin calls boardfarm_release_devices and device shutdown hooks to clean up resources.

Because the plugin uses Boardfarm’s pluggy hooks for the heavy lifting, tests remain concise and protocol-driven while the plugin ensures correct lifecycle orchestration.

HTML report integration

When pytest-html is present, the plugin enhances the generated HTML report by:

• Adding columns for test start time and hidden epoch time for sorting.
• Appending a Boardfarm section to the summary that shows deployment, environment and teardown details.
• Embedding captured PNG images attached to test results into the HTML output.

  Note: This feature is only available when a GUI test performs a screen shot and the fixture saves the attachment.

This provides a compact test execution summary together with environment metadata and visual evidence useful for debugging.

Troubleshooting & tips

• Plugin not loaded: make sure the plugin package is installed and the pytest entry points are configured. Use pytest's plugin diagnostics to verify loaded plugins.
• HTML report not showing Boardfarm data: confirm pytest-html is installed and enabled; the plugin only augments the HTML report when the html plugin is available.
• Tests skipped via env_req: verify that the env_req marker matches the keys and values declared in your env_config. Use the boardfarm_config fixture in a quick test to inspect resolved environment values.
• Test selection edge cases: the test selection option does pattern matching; ensure you provide normalized logical names that correspond to the collected test items.

Development notes

• The plugin exposes a minimal set of early fixtures so small helper functionality can be used even when full deployment is not performed.
• The BoardfarmPlugin uses hookwrapper-style pytest hooks to capture setup and teardown logs and to integrate cleanly with pytest's logging plugin.
• For extending functionality, add command-line args via boardfarm_add_cmdline_args, register device classes using boardfarm_add_devices / boardfarm_register_devices, and implement device hooks in plugin packages.

Contributing

Contributions are welcome. When adding or modifying plugin behavior follow these guidelines:

• Expose new CLI options via the boardfarm_add_cmdline_args hook so they participate in the standard parsing lifecycle.
• New device classes should be registered through boardfarm_add_devices, and any lifecycle orchestration should use core hooks rather than modifying runner internals.
• Add tests for fixture behavior using pytest's testing helpers and ensure HTML reporting integration remains intact where applicable.

License

The pytest-boardfarm3 plugin follows the same licensing as Boardfarm (Clear BSD). See the top-level LICENSE file for details.
