ECE496 Capstone

Here is a quick demo:

Docker Setup

This is the easiest way to start working on our project.

Make sure you are in the root directory of our project (where the docker-compose.yml file is located).

Verify Docker Installation

To verify Docker is installed, run:

docker --version

Starting Docker Containers

To start the Docker containers, use:

docker compose up

If you need to rebuild the images, use:

docker compose up --build

After running these commands, you should be able to access the frontend and the backend in the browser using the links displayed.

Stopping Docker Containers

To stop the Docker containers, use:

docker compose down

Running Commands in Docker Containers

When running a Docker container, you can use these commands:

Make Migrations for the Database

docker compose exec backend python /app/backend/manage.py makemigrations

Run Migrate Command

docker compose exec backend python /app/backend/manage.py migrate

Create Superuser

docker compose exec backend python /app/backend/manage.py createsuperuser

Django Backend

To connect to the backend on your browser you can either:

1. Run the server locally, and connect via http://localhost:8000/api/ or http://127.0.0.1:8000/api/
   • Do the Set up
   • See The Starting the development server section
2. to view examples of requests that can be made see the TeamBuilder\api\test.rest file.

Set up

1. install python

2. install python virtual environments using

   • C:\...\Backend> pip install virtualenv

3. Create the virtual environment using:

   • C:\...\Backend> python -m venv venv
   • Ensure the venv folder was created in the project folder

4. Start the virtual environment: Run:
   C:\...\Backend> ./venv/scripts/activate\

5. Install Django: https://docs.djangoproject.com/en/5.1/howto/windows/

6. if you are developing on the backend you will also need to install the package requirements from requirements.txt

   • C:\...\Backend> pip install -r requirements.txt
   • You can also run (Windows only) ./runserver.bat which installs packages as well.

7. You will need to set up secret keys in /TeamBuilder/Settings.py (Do not push these keys to github) .
   Change: "SIGNING_KEY": os.environ["SECRET_KEY"] to "SIGNING_KEY": "ARandomSecretKey"
   Change: SECRET_KEY = os.environ["SECRET_KEY"] to SECRET_KEY = "ARandomSecretKey"

8. To make the database you need to run:
   Run:
   C:\...\Backend> python /TeamBuilder/manage.py makemigrations
   Then:
   C:\...\Backend> python /TeamBuilder/manage.py migrate

9. Create a super user (admin user) so you can login to the admin site and view the database.
   Type and fill in the prompts:
   C:\...\Backend> python /TeamBuilder/manage.py createsuperuser

Starting the development Server

1. install python and python virtual environments if not already installed.
2. To start the development Server, run the (Windows only) runserver.bat script or run the below commands.
   • This will launch the virtual environment, install packages, and then run the Django server on port 8000

Type:
C:\...\Backend> .\runserver.bat
or
Run:
C:\...\Backend> ./venv/scripts/activate
Then:
C:\...\Backend> pip install -r requirements.txt
Then the start command:
C:\...\Backend> python /TeamBuilder/manage.py runserver

Virtual Environments

[!WARNING]
It is important when working in the backend to always install python packages in the virtual environment.

To activate the virtual environment, type:
C:\...\Backend> ./venv/scripts/activate

To update the included packages in the git repo run the following in the virtual environment:
(venv) PS C:\...\Backend> pip freeze > requirements.txt

To deactivate the virtual environment type:
(venv) PS C:\...\Backend> deactivate

Accessing the admin site

In the admin site you can view all models in the database, as well as any objects created. To access the site you need to have created a super user (See the Set up) Then go to: http://127.0.0.1:8000/admin/ and login.

React Frontend

To connect to the frontend on your browser you can

1. Run the server locally, and connect via localhost
   • Do the Set Up
   • See Starting the frontend section
2. Connect to ... (Work in progress)

Frontend set Up

1. Install Node.js and clone this repository
2. go into the "frontend" folder using cd frontend
3. download the latest packages for the frontend automatically using npm install

Running the frontend in browser

1. Use the command npm run dev
2. Click on the localhost link that appears in your terminal to see the frontend in browser

Frontend Prototype

Figma File
