(Node Express) Docker Kubernetes Playground

Docker

Commands

Deploy

• Build: docker build -t <userame>/node-express-docker-kubernetes-playground .
• Run: docker run -p <local-port>:<exposed-container-port> -d <userame>/node-express-docker-kubernetes-playground
• Stop; docker stop <ContainerId>

Dockerhub

• Login: docker login -u="<username>" -p="<password>"
• Push: docker push <userame>/node-express-docker-kubernetes-playground
• Pull: docker pull <userame>/node-express-docker-kubernetes-playground

Info

• See images: docker images
• See running containers: docker ps
• See output: docker logs <container id>
• Enter the container: docker exec -it <container id> /bin/bash

Kubernetes

Infos

• Node
  • Also refered to as Worker Nodes
  • Physical/virtual server instance (e.g. AWS EC2 instance), which runs 0 - N pods
  • Receives commands / pod specs (.yml or .json files) and is monitored via the Kubelet (process running on every node)
• Pod
  • 1 - N Containers sharing the same excecution enviorment, which allows inter-process communication
  • Has a unique IP address in the cluster
  • Pods shouldn't be run without a ReplicaSet or Deployment (described later)
• Master node aka API Server
  • The node to interact with the cluster (starting, stopping, monitoring the nodes/pods)
• Config Map
  • Used to configure Pods
• Service
  • Defines a set of pods and how to access them (discovering & exposing of pods)
  • Acts as the entry point to a set of pods
  • When discovering services (e.g. from another service) two ways are supported: Environment variables and DNS More Infos
  • Types:
    • ClusterIP: exposed just inside the clusters
    • NodePort: exposed to the outside via <NodeIP>:<NodePort>
    • LoadBalancer: Exposes the service externally using a cloud provider’s load balancer via <ClusterIP>:<Port>
    • ExternalName: Maps the service to the contents of the externalName field (e.g. foo.bar.example.com)
  • Canary release
    • It's possible to spin up pods with the same name, but the new container (v1 -> v2). The service will pick up the new instances.
    • Another way would be to use an ingress controller like: Zalando Ingress Contrller
• ReplicaSet
  • Ensures that a specified number of pod replicas are running at any given time
  • It's recommanded to use Deployments to manage those
• Job
  • Creates one or more pods and ensures that a specified number of them successfully complete
  • Well suited for tasks that need to run only once (complementary to ReplicaSet)
• Deployment
  • Higher-level concept to manage Pods and ReplicaSets
  • Different strategies to replace pods with new versions: Recreate or RollingUpdate
  • Continuous delivery is not covered by default, instead the image (tag) has to be changed for every deploy More Infos
• DaemonSet
  • Similar to Deployments (create Pods which are not expected to terminate)
  • Use when it is important that a Pod always runs on certain hosts, and when it needs to start before other Pods
  • Deployment for stateless services where it's not important which host the Pod runs on
• StatefulSets
  • Like a deployment, but each pod has it's unique identiy (network, storage etc.), that will be kept across rescheduling
  • It's also possible to define the order pods are started/exchanged and make sure pods are always unique
• Namespace
  • Provides: unique naming scope, constraints for resource consumption, authentication
  • When no namespace is set, the default namespace is used
• ResourceQuota
  • Can be assigned to namespaces, to restrict how much of cluster resources can be consumed across all resources in a namespace
  • Can include things like: cpu, memory, pods, services, ...
• NetworkPolicy
  • Specify how pods are allowed to communicate with each other and other network endpoints
  • Needs a NetworkController like: Calico or Weave Net
  • By default (without a policy) all incoming (ingress) and outgoing (egress) traffic from/to pods is allowed
  • Examples: deny-everything and other-options
• Ingress
  • Is a collection of rules that allow incoming connections to reach the cluster services (usually services and pods have cluster internal IPs)
  • It can an be configured to give services public URLs, balance traffic, terminate SSL etc.
  • Needs an IngressController:
    • List if possibilities
    • On AWS, using the A(pplication)L(oad)B(alancers) to allow L7 (http) rules: aws-alb-ingress-controller
  • Possibility to expose a singel service, path-based-routing, host-based-routing
  • Enable TLS (termination) by providing a private key and a certificate (e.g. using a Secret) more
  • Other Kubernetes concepts like a LoadBalancer service, also allow to expose a single Service to the outside world
• Charts
  • Collection of files that describe a set of Kubernetes resources (e.g. one pod like memcached or a whole app stack like wordpress etc.)
  • The files need to ne laid out in a particular directory tree and include files like a Chart.yml or requirements.yml
• Helm
  • Tool to manage Kubernetes Charts, similar to a package manager like apt or npm

SetUp

• Running a kubernetes cluster on your local machine
  • Minikube
  • OSX: brew cast install minikube
  • Provides only one Node
• CLI/Client to make requests to the Kubernetes API server / master node
  • Kubectl
  • OSX: brew install kubectl

Commands

Minikube

• Start the cluster: minikube start
• Get the cluster ip address: minikube ip
• Get the cluster status: minikube status
• Open a service running minikube in the browser: minikube service <service-name>
• Stop the cluster: minikube stop

Kubectl

• Run a container with a given name as/in a pod (deployment): kubectl run <name> --image=<imagename> --labels="<labels>" --port=<port>
• Running a spec file: kubectl apply/create -f <filename>.yaml
• Get the logs of a running pod: kubectl logs <pod-name>
• Open a shell in your pod: kubectl exec <name>delet -it /bin/bash
• Get a list of running pods/deployments/services/...: kubectl get <pods/deployments/services/nodes/...>
• Get pods/deployments/services/... infos: kubectl describe <pod/deployment/service/noide/...> <name>
• Delete a pods/deployments/services/...: kubectl delete <pod/deployment/service/...> <name>
• Apply a ConfigMap to the nodes in the cluster: kubectl apply -f <filename>.yaml
• Merge two kubectl-config files: KUBECONFIG=<path/file1>:<path/file2> kubectl config view --flatten > <outputfile>
• List and switch between clusters/contexts: kubectl config get-contexts, kubectl config current-context, kubectl config use-context
• Mark node as not usable (no new pods will be scheduled): kubectl drain <node>

Kubectl - Proxy

• It's possible to start a proxy to the Kubernetes API server: kubectl proxy --port=<local-port>
• Afterwards it's possible to explore the API suing http requests like:
  • curl http://localhost:8080/api/
  • curl http://localhost:8080/api/v1/namespaces/default/pods
• It also allows to expose a "public" endpoint to a service running in the cluster

Access pods/app

• Forward a port: kubectl port-forward <pod-name> <local-port>:<app-pod-port>
• OR write a service spec file and run it: kubectl create -f <service-spec>
• BUT when running on minikube, no EXTERNAL-IP will be available, solution: minikube service <service-name> will open the browser with the exposed service
• Also possible to use just the cli
  1. Expose a pod as a service: kubectl expose pod <pod-name> --port=<to-the-outside> --target-port=<container-port> --name=<service-name>
  2. Start a Proxy: kubectl proxy --address 0.0.0.0 --accept-hosts '.*' --port <service-port>
  3. Should be visible under: https://ENVIRONMENT_ID.vfs.cloud9.REGION_ID.amazonaws.com/api/v1/proxy/namespaces/default/services/SERVICE-NAME/

Rollouts

• Record depolyments for later rollback: kubectl create/apply -f ... --record
• Take a look at the last deplyments/roll-outs: kubectl rollout history deployment <name>
• Roll-back: kubectl rollout undo deployment <name> --to-revision=<revision-number>

Dealing with credentials / private docker images

• Creating a docker-hub secret to access private images: kubectl create secret docker-registry <name-for-secret> --docker-server=https://index.docker.io/v1/ --docker-username=<your-name> --docker-password=<your-pword> --docker-email=<your-email>
• List secrets: kubectl get secret
• Delete a secret: kubectl delete secret <name>

Horizontal Pod Autoscaler

• Create an autoscaler: kubectl autoscale deployment webapp --cpu-percent=80 --min=1 --max=10
  • tries to maintain average CPU utilization of 80%, with a max of 10 pods running
• Get the Autoscaler state: kubectl get hpa
• Simple methode to run a load test: kubectl run -i --tty load-generator --image=busybox /bin/sh
  • On the bash run: while true; do wget -q -O- <service-url>; done

Helm

• Install a chart: helm install <chart-name>
• Take a look at the manifests before installing: helm install --dry-run --debug <chart-name>
• List or delete depolyed charts: helm list and helm delete
• Find issues with your own chart: helm lint <chart-name>
• Package and share your own chart: helm package and helm serve
