MimicKit Logo

Mimekit

MimeKit analyzes public GitHub repositories (or local repos) and generates an executable implementation blueprint -- a detailed plan that a coding agent (Claude Code, Codex, etc.) can follow to recreate the project from scratch.

It produces:

  • Architecture model (components, edges, tech mapping)
  • Detected stack fingerprint (frontend, backend, DB, auth, infra)
  • Behavioral intent spec (purpose, features, flows, rules, contracts)
  • Executable build prompt with route blueprints, data models, and design system
  • Stack swap rewrites without full re-analysis

How It Works

flowchart TD
    subgraph input [Input]
        githubUrl["GitHub URL\n--github https://github.com/org/repo"]
        localPath["Local Path\n--repo /path/to/repo"]
    end

    subgraph fetch [Stage 1 - Fetch]
        gitClone["git clone --depth=1\nShallow clone into .runs/workspace/"]
        skipFetch["Skip\nUse local path directly"]
    end

    subgraph ingest [Stage 2 - Ingest]
        walkFS["Walk filesystem\nSkip node_modules, .git, dist, build"]
        selectFiles["Select files\nPriority: README, package.json, schema.prisma,\n.env.example, API routes, config files\n+ top N largest source files"]
        readContents["Read contents\nBudget: 90K tokens max\nFiles capped at 120KB each"]
        githubAPI["GitHub API\nRepo metadata + language breakdown"]
    end

    subgraph analyze [Stage 3-5 - Analyze]
        stackDetect["Stack Detection\nLocal: parse deps, match patterns\nNo API call"]
        archExtract["Architecture Extraction\nClaude API call #1\nBudget-capped prompt ~40K chars"]
        intentExtract["Intent Extraction\nClaude API call #2\nSmart file priority, ~35K chars"]
    end

    subgraph compile [Stage 6 - Compile]
        planCompile["Plan Compilation\nClaude API call #3\nStack + arch + intent + route hints"]
        renderMd["Render plan.md\n4-phase blueprint with route maps,\ndata models, design system, build steps"]
    end

    subgraph output [Output Artifacts]
        artifacts["artifacts/\n  fetch.json\n  ingest.json\n  run.json\n  plan.md"]
    end

    githubUrl --> gitClone
    localPath --> skipFetch
    gitClone --> walkFS
    skipFetch --> walkFS
    walkFS --> selectFiles
    selectFiles --> readContents
    readContents --> githubAPI
    githubAPI --> stackDetect
    stackDetect --> archExtract
    archExtract --> intentExtract
    intentExtract --> planCompile
    planCompile --> renderMd
    renderMd --> artifacts
Loading

Pipeline stages

Stage What it does API calls
Fetch Shallow git clone of the target repo (GitHub only; skipped for local repos) None (git)
Ingest Walks the filesystem, selects important + sampled files, reads contents with token budgets GitHub REST API (repo metadata + languages)
Stack Pattern-matches package.json, file extensions, config files to detect frameworks None (local)
Architecture Sends repo summary + stack to Claude, returns typed component/edge model Anthropic Messages API
Intent Sends prioritized file subset + condensed architecture to Claude, returns behavioral spec Anthropic Messages API
Plan Sends stack + architecture + intent + route/design hints to Claude, returns structured plan Anthropic Messages API

Each Claude call has retry logic (3 attempts with 15s/30s backoff on rate limits), a 240-second timeout, and a deterministic fallback that runs if the API is unavailable.

Stack

  • Next.js App Router + TypeScript
  • API routes (server-side pipeline)
  • Zod schema validation
  • Anthropic Claude API (Claude Sonnet 4.5)
  • simple-git for repository cloning
  • No database (in-memory run cache)

Quick Start

Web UI

cp .env.example .env
# Add your ANTHROPIC_API_KEY to .env
npm install
npm run dev

Open http://localhost:3000, paste a GitHub URL, and run.

CLI Harness

The harness runs the full pipeline from the command line. It clones repos locally via git (or reads a local directory), which gives richer file access than the GitHub Content API.

# Analyze a GitHub repository
npm run harness -- --github https://github.com/org/repo --scan-mode deep

# Analyze a local repository
npm run harness -- --repo /path/to/local/repo --scan-mode deep

# Quick scan (fewer files sampled)
npm run harness -- --github https://github.com/org/repo --scan-mode quick

# Specify a branch or tag
npm run harness -- --github https://github.com/org/repo --ref main --scan-mode deep

Options:

Flag Description
--github <url> GitHub repository URL to analyze
--repo <path> Local repository path to analyze
--ref <branch|tag|sha> Branch, tag, or commit to checkout (defaults to default branch)
--scan-mode quick|deep quick samples 10 source files, deep samples 30

Output:

.runs/run_<timestamp>_<id>/
  workspace/          # Cloned repo (GitHub) or symlinked (local)
  artifacts/
    fetch.json        # Git clone metadata (GitHub only)
    ingest.json       # Full repo snapshot with file contents
    run.json          # Complete analysis (snapshot + stack + architecture + intent + plan)
    plan.md           # Rendered executable blueprint

The plan.md is the primary artifact -- a self-contained markdown document you can feed directly to a coding agent.

Web UI vs CLI

Both paths share the same analysis engine (analysis.ts, claude.ts, prompt-compiler.ts, stack-detector.ts). The difference is how the repo is fetched:

Web UI CLI Harness
Entry point POST /api/analyze npm run harness
Repo access git clone (if git available) or GitHub Content API fallback git clone (GitHub) or direct filesystem (local)
Local repos Not supported --repo /path/to/repo
Artifacts In-memory run cache Written to .runs/ directory
Auth GitHub OAuth session None needed

Environment

Copy .env.example to .env and configure:

Variable Required Description
ANTHROPIC_API_KEY For LLM analysis Claude API key. Without it, deterministic fallbacks run instead.
GITHUB_TOKEN Optional Improves GitHub API rate limits for repo metadata
GITHUB_ID For web UI auth GitHub OAuth App client ID
GITHUB_SECRET For web UI auth GitHub OAuth App client secret
NEXTAUTH_SECRET For web UI auth Random secret for session encryption
NEXTAUTH_URL For web UI auth http://localhost:3000 in local dev

The CLI harness loads .env automatically. The web UI (Next.js) loads .env.local as usual.

Tuning limits

These can be set in .env to adjust ingestion behavior:

Variable Default Description
MAX_REPO_KB 50000 Max repo size to process (KB)
MAX_FILE_BYTES 120000 Max individual file size to read
MAX_SNAPSHOT_TOKENS 90000 Total token budget for ingested file contents
ANTHROPIC_MODEL claude-sonnet-4-5-20250929 Claude model to use
HARNESS_CLONE_DEPTH 1 Git clone depth
HARNESS_MAX_FILE_SIZE 120000 Max file size for harness ingest

GitHub OAuth Setup

  1. Create a GitHub OAuth App at https://github.com/settings/developers
  2. Set callback URL to http://localhost:3000/api/auth/callback/github
  3. Put client id/secret in .env as GITHUB_ID and GITHUB_SECRET
  4. Generate a random value for NEXTAUTH_SECRET
  5. Restart dev server and click Sign In with GitHub on the intake page

Testing

npm test            # Run all tests
npm run test:watch  # Watch mode
npm run typecheck   # TypeScript check

Prompts

This section documents the prompt templates used by the analysis pipeline.

Source files:

  • lib/services/claude.ts -- shared Claude caller with retry, timeout, schema validation
  • lib/services/analysis.ts -- architecture, intent, and stack-swap prompts
  • lib/services/prompt-compiler.ts -- plan compilation prompt and markdown renderer

Shared Claude System Prompt

All Claude JSON calls use this system instruction:

You are a strict JSON API. Return only valid JSON. Do not include markdown fences, comments, or prose.

Architecture Extraction

Defined in extractArchitecture() (lib/services/analysis.ts):

Return valid JSON only.

Task: extract architecture model for this repository summary.

Output schema:
<ARCHITECTURE_MODEL_SCHEMA_JSON>

Rules:
- components[] must include id, name, role, tech[], inputs[], outputs[]
- edges[] must use type in {request,data,event}
- no prose outside JSON

Repository summary:
<REPO_SNAPSHOT_SUMMARY (budget-capped ~40K chars)>

Detected stack:
<STACK_JSON>

Intent Extraction

Defined in extractIntent() (lib/services/analysis.ts). Uses a smart file selection strategy that prioritizes high-signal files (README, database schemas, API routes, config) and embeds a condensed architecture summary:

Return valid JSON only.

Task: extract behavioral intent spec for the TARGET REPOSITORY described below.
The system_purpose should describe what THIS application does (not the analysis tool).
The core_features should list the actual features of THIS application.

Output schema:
<INTENT_SPEC_SCHEMA_JSON>

Rules:
- use concise, concrete statements about the TARGET repository
- system_purpose: strip HTML tags, describe the app in plain text
- core_features: list actual features visible in the source code and README
- user_flows: derive from routes and UI components
- business_rules: derive from auth, validation, and config patterns
- include assumptions and unknowns
- no prose outside JSON

Repository and architecture summary:
<SMART_REPO_SUMMARY (prioritized files, condensed arch, ~35K chars)>

Stack Swap Intent Rewrite

Defined in rewriteIntentForStackSwap() (lib/services/analysis.ts):

Return valid JSON only.

Task: rewrite intent spec after tech stack swap.
Rewrite only impacted modules/interfaces/behavior.

Output schema:
<INTENT_SPEC_SCHEMA_JSON>

Swap descriptor:
<SWAP_DESCRIPTOR_JSON>

Architecture model:
<ARCHITECTURE_MODEL_JSON>

Existing intent:
<PREVIOUS_INTENT_JSON>

Repository summary:
<REPO_SNAPSHOT_SUMMARY>

Plan Compilation

Defined in compileExecutablePlan() (lib/services/prompt-compiler.ts):

Return valid JSON only.

Task: compile an executable build plan prompt for a coding agent.

Output schema:
<STRUCTURED_PLAN_SCHEMA_JSON>

Rules:
- keep build steps concrete, ordered, and directly executable
- include route-level plan with page layout descriptions for each user-facing route
- preserve source layout paradigms (floating menus, sticky bars, command overlays)
- describe functionality logic and rule enforcement, not just feature names
- if DB signals exist, include concrete schema/index/migration guidance
- include design system with explicit color tokens, radius scale, motion, and distinctive traits
- include concrete UI token guidance with hex colors and component styling behavior
- keep string values concise; total JSON output MUST be under 9000 tokens
- derive from architecture + intent + inferred route/design hints
- avoid placeholders like 'as needed'

Artifacts:
<PLAN_ARTIFACTS_JSON>

Runtime Behavior

  • Each prompt response is validated against a Zod schema
  • If ANTHROPIC_API_KEY is missing, deterministic fallback generators produce a baseline plan
  • Claude JSON parsing includes schema drift normalization (for common fields like type, from, to)
  • Failed Claude calls retry 3 times with 15s/30s exponential backoff on rate limits and server errors
  • A 240-second fetch timeout prevents silent connection drops
  • Output truncation (stop_reason: max_tokens) is detected and logged
  • All Claude calls log stage label, attempt number, prompt size, and error details

About

A system that turns any codebase or product into a model-readable build plan that can be regenerated, adapted, and reimplemented in another stack using LLMs.
