Pointax: JAX-Native PointMaze Environment

High-performance JAX implementation of PointMaze environments with MuJoCo-inspired physics.

Pointax provides a complete JAX implementation of the PointMaze environment from Gymnasium Robotics, featuring full JIT compilation, vectorization support, and a simplified but accurate 2D physics engine inspired by MuJoCo.

Physics Engine

Pointax implements a simplified but accurate 2D physics engine inspired by MuJoCo while being fully differentiable and JIT-compilable:

• Collision Detection: Sphere-AABB intersection with anti-sticking mechanisms
• Force Integration: Proper velocity and position updates with motor scaling
• Boundary Handling: Smooth wall interactions with friction coefficients
• Parameter Matching: Robot radius (0.1m), motor gear (100x), and dynamics match MuJoCo reference

Quick Start

import jax
import pointax

# Create environment
env = pointax.make_umaze()
params = env.default_params

# Reset and step
key = jax.random.PRNGKey(42)
obs, state = env.reset_env(key, params)

action = jax.numpy.array([0.5, 0.0])  # Move right
obs, state, reward, done, info = env.step_env(key, state, action, params)

print(f"Reward: {reward}, Success: {info['is_success']}")

Installation

From GitHub (not yet on PyPi):

pip install git+https://github.com/riiswa/pointax.git

From source:

git clone https://github.com/riiswa/pointax.git
cd pointax
pip install -e .

Environment Catalog

Standard Mazes

Environment	Size	Description
UMaze	5×5	U-shaped maze with single path
Open	7×5	Open rectangular arena
Medium	8×8	Moderately complex maze
Large	12×9	Large complex maze
Giant	16×12	Very large maze

Diverse Goal Mazes

Environment	Description
Open_Diverse_G	Open maze with multiple goal locations
Medium_Diverse_G	Medium maze with diverse goal placement
Large_Diverse_G	Large maze with many goal options

Diverse Goal-Reset Mazes

Environment	Description
Open_Diverse_GR	Open maze with flexible goal/reset locations
Medium_Diverse_GR	Medium maze with combined goal/reset spots
Large_Diverse_GR	Large maze with maximum location diversity

Usage Examples

Basic Environments

import pointax

# Standard environments
env = pointax.make_umaze(reward_type="sparse")
env = pointax.make_large(reward_type="dense")

# Diverse environments
env = pointax.make_open_diverse_g()
env = pointax.make_large_diverse_gr(reward_type="dense")

Custom Maze Creation

Create environments from simple 2D layouts:

# Simple custom maze (1=wall, 0=empty)
custom_maze = [
    [1, 1, 1, 1, 1],
    [1, 0, 0, 0, 1],
    [1, 0, 1, 0, 1],
    [1, 0, 0, 0, 1],
    [1, 1, 1, 1, 1]
]
env = pointax.make_custom(custom_maze)

# Maze with specific goal/reset locations
maze_with_goals = [
    [1, 1, 1, 1, 1, 1, 1],
    [1, 'R', 0, 0, 0, 'G', 1],  # 'R'=reset, 'G'=goal
    [1, 0, 1, 1, 1, 0, 1],
    [1, 0, 0, 'G', 0, 0, 1],     # Multiple goals
    [1, 'C', 0, 0, 0, 'C', 1],   # 'C'=combined goal/reset
    [1, 1, 1, 1, 1, 1, 1]
]
env = pointax.make_custom(maze_with_goals, reward_type="dense")

# Boolean maze (intuitive for many users)
bool_maze = [
    [True,  True,  True ],   # True = wall
    [True,  False, True ],   # False = empty
    [True,  True,  True ]
]
env = pointax.make_custom(bool_maze, maze_id="MyMaze")

JAX Transformations

Pointax is designed for JAX workflows:

import jax
import jax.numpy as jnp

env = pointax.make_medium()
params = env.default_params

# JIT compilation
@jax.jit
def fast_step(key, state, action):
    return env.step_env(key, state, action, params)

# Vectorization
@jax.vmap
def batch_step(keys, states, actions):
    return env.step_env(keys, states, actions, params)

# Use with batches
batch_size = 64
keys = jax.random.split(jax.random.PRNGKey(42), batch_size)
actions = jnp.zeros((batch_size, 2))
# ... batch operations

Environment Specification

Observation Space

• Type: Box(-inf, inf, (6,), float32)
• Contents: [pos_x, pos_y, vel_x, vel_y, goal_x, goal_y]

Action Space

• Type: Box(-1.0, 1.0, (2,), float32)
• Contents: Continuous forces in x and y directions

Rewards

• Sparse: 1.0 when goal reached (distance ≤ 0.45m), 0.0 otherwise
• Dense: -distance_to_goal (negative distance for gradient-based learning)

Maze Symbols

Symbol	Value	Description
1 or True	1	Wall (impassable)
0 or False	0	Empty space
'G'	2	Goal location
'R'	3	Reset location
'C'	4	Combined goal/reset location

Contributing

We welcome contributions! Please see CONTRIBUTING.md for guidelines.

Citation

If you use Pointax in your research, please cite:

@misc{pointax2025,
  title={Pointax: JAX-Native PointMaze Environment},
  author={Waris Radji},
  year={2025},
  url={https://github.com/riiswa/pointax}
}

License

This project is licensed under the MIT License - see the LICENSE file for details.

Acknowledgments

• Original PointMaze environment from Gymnasium Robotics
• Gymnax for their API
• MuJoCo physics engine for inspiration
• JAX team for the excellent framework

Related Work

Pointax builds upon and complements several excellent JAX-based RL environments:

• JaxGCRL: Brax-accelerated goal-conditioned RL environments including maze implementations.

• QDax: Quality-Diversity optimization library containing an alternative PointMaze environment.

Pointax differentiates itself by providing, a pure JAX implementation without Brax overhead.
