Web Admin Interface

Password-protected admin UI for runtime bot and policy management.

Access and Session Model

• Default bind: WEB_BIND_HOST=127.0.0.1, WEB_PORT=8080
• Built-in HTTPS bind: WEB_HTTPS_PORT=8081
• Typical container bind: WEB_BIND_HOST=0.0.0.0 with host/proxy controls
• If no TLS files exist, the bot generates a self-signed certificate under ${DATA_DIR}/ssl/.
• Replace ${DATA_DIR}/ssl/tls.crt and ${DATA_DIR}/ssl/tls.key with your own files if you want a browser-trusted HTTPS listener.
• Login uses email + password (web-only account model)
• Optional "Keep me signed in" extends session to 5 days on device
• Inactivity timeout is configurable: 5, 10, 15, 20, 30, 45, 60, 90, or 120 minutes
• Theme options in header: Light and Black

Security controls include:

• Login rate limiting
• CSRF enforcement
• Same-origin POST checks
• Strict cookie settings and browser hardening headers

User and Identity Fields

Each web user includes:

• Email (login identifier)
• Password hash
• First name
• Last name
• Display name (shown in GUI)
• Role (Admin, Read-only, Glinet-Read-Only, or Glinet-RW)
• Password age metadata (90-day rotation enforcement)

User self-service capabilities:

• Change password
• Change email
• Update first/last/display names

Admin-only user management capabilities:

• Create users
• Delete users
• Promote/demote admin users
• Reset user credentials as needed

Read-only capabilities:

• Can sign in and navigate all admin pages
• Can view all settings/options/data exposed by the web GUI
• Cannot apply management/configuration changes (save/update/delete/restart actions are blocked server-side)

Glinet-Read-Only capabilities:

• Can sign in
• Is automatically pinned to the primary Discord server (intended for the GL.iNet Community Discord)
• Can view the guild-scoped GL.iNet pages for that primary server, including dashboard, command permissions, actions, feeds, bot profile, guild settings, tag responses, bulk role CSV, and member activity
• Can export member-activity ZIP archives from /admin/member-activity/export
• Can manage their own /admin/account page
• Cannot access global settings, logs, documentation, user management, or other non-guild/global admin pages

Glinet-RW capabilities:

• Includes all Glinet-Read-Only viewing access
• Is pinned to the same primary Discord server only
• Can save guild-scoped settings/pages for that server:
  • command permissions
  • guild settings
  • Reddit/YouTube/LinkedIn/Beta subscriptions
  • tag responses
  • bot nickname on the selected server
• Cannot access global settings, user management, container restart, or cross-guild selection

No Discord /login or !login flow exists for web-user creation.

Password Policy

All web passwords must satisfy:

• Minimum 6 characters
• Maximum 16 characters
• At least 2 numbers
• At least 1 uppercase letter
• At least 1 symbol

UI forms include show/hide password toggles and validation feedback.

Navigation and Layout

• Main page lists the Discord servers the bot is currently in.
• Select a server first, then open the server dashboard for guild-scoped admin actions.
• Top menu uses dropdown-based section navigation.
• Direct Logout action is available from the top header on desktop and mobile layouts.
• Mobile layout uses a compact quickbar plus collapsible menu drawer for server jump, account access, theme switching, and primary page links.
• Dedicated dashboard link is shown beside the dropdown.
• Dashboard includes direct action buttons/cards for major admin workflows.
• Mobile layout is responsive for smaller screens and touch interaction.

Command Permissions

• /admin/command-permissions manages command access per selected guild.
• Available modes:
  • Default rule: follow the bot's built-in default access policy for that command
  • Public: allow any guild member
  • Disabled: turn the command off for that guild
  • Custom roles: restrict the command to one or more selected roles
• Custom-role mode requires at least one role ID or selected role.
• Reddit feed management page lets admins map subreddits to Discord text channels and set the polling interval from a dropdown.
• LinkedIn profile management page lets admins map public LinkedIn profiles to Discord text channels for new-post notifications.
• GL.iNet beta program page lets admins map the public GL.iNet beta-testing page to Discord text channels for added/removed program notifications.
• Tag responses and guild settings pages now follow the selected server context instead of using one global mapping.
• Member activity page shows top-20 member activity windows for the selected server.
• Member activity exports are generated for the selected server only and match the currently retained 90-day dataset.
• Guild settings also control per-server welcome messages, optional join DMs, and optional uploaded welcome images.

Admin Pages and Capabilities

/admin

• Server selector / entry page
• Lists every Discord server the bot can currently access
• Sets the active server context used by guild-scoped admin pages
• Admin users can remove the bot from a server directly from this page using the per-server Remove Bot action
• Glinet-Read-Only and Glinet-RW users do not stay here; they are redirected to /admin/dashboard using the primary guild

/admin/dashboard

• Server dashboard overview
• Quick links to settings, users, moderation tooling, and logs-related actions for the selected server
• Includes a Command Status table for the selected server
• Lists each command with:
  • effective access level (Public, Mod Only, Named Roles, Custom Roles, or Disabled)
  • current enabled/disabled state
• Uses the same guild-scoped command-permissions data the bot enforces at runtime

/admin/guild-settings

• Scoped to the selected server
• Per-guild overrides for:
  • bot log channel
  • moderation log channel
  • firmware notify channel
  • self-assign access role
  • welcome channel
  • welcome channel message
  • welcome DM enable/disable
  • welcome DM message
  • uploaded welcome image
  • image attachment enable/disable for channel and DM
• Blank values fall back to the global runtime environment settings

Welcome-message placeholders:

• {member_mention}
• {member_name}
• {display_name}
• {guild_name}
• {member_count}
• {account_created_at}

How to configure welcome automation:

1. Open /admin/guild-settings
2. Select the target guild
3. Set Welcome Channel if you want a public join post
4. Enter Welcome Channel Message, or leave it blank to use the default
5. Enable Send Welcome DM if you want a DM on join
6. Enter Welcome DM Message, or leave it blank to use the default
7. Upload a welcome image if desired
8. Enable image attachment for channel, DM, or both
9. Save the guild settings

Notes:

• If no welcome channel is selected, the bot will not post a public welcome message
• If the member blocks DMs, the DM send is skipped and the join flow continues normally
• Supported image formats: PNG, JPG, JPEG, WEBP, GIF
• Upload size follows the configured web avatar upload limit (WEB_AVATAR_MAX_UPLOAD_BYTES; default 2097152 bytes / 2048 KiB)
• Welcome images must be between 64x64 and 4096x4096
• The page shows current uploaded image metadata:
  • filename
  • media type
  • size in bytes / KiB
  • width x height
• Recommended welcome image layout is landscape artwork around 1200x675 for clearer preview sizing inside Discord

/admin/settings

• Global environment-backed settings editor
• Live dropdowns for known channel and role fields load from the currently selected server
• Managed-guild allowlist and utility integration settings
• Web-session/security settings
• Auto-logout selection (5, 10, 15, 20, 30, 45, 60, 90, 120 minutes)
• Writes to WEB_ENV_FILE, which should point to a writable path such as ${DATA_DIR}/web-settings.env

/status/everything (Public Read-Only Status)

• Runtime observability view in web GUI
• CPU, memory, I/O, network, and uptime snapshot cards
• 24-hour rolling metrics summary (min/avg/max) retained in-memory
• Manual refresh plus auto-refresh interval dropdown (1, 5, 10, 30, 60, 120 seconds)
• Public and read-only (no login required)
• /admin/observability redirects to /status/everything

/admin/logs (Login Required)

• Log viewer with dropdown selection (bot.log, bot_log.log, container_errors.log, web_gui_audit.log, web_probe.log)
• Refresh button plus auto-refresh interval dropdown (1, 5, 10, 30, 60, 120 seconds)
• Requires web GUI login

/admin/actions

• Scoped to the selected server
• Read-only activity history for moderation actions and server-event log writes
• Useful for reviewing what the bot did without reading raw log files

/admin/account

• Self-service account page for the current web GUI user
• Change password
• Change email
• Update first name, last name, and display name

/admin/member-activity

• Scoped to the selected server
• Read-only top 20 member activity tables for:
  • last 90 days
  • last 30 days
  • last 7 days
  • last 24 hours
• Each table shows:
  • message count
  • active day count
  • last seen timestamp
• Export option at the bottom of the page downloads a compressed ZIP archive for the selected server
• Export respects the selected server context; there is no cross-guild combined export
• Export includes:
  • per-window leaderboard CSV files
  • raw member activity summary CSV
  • raw hourly activity CSV
  • JSON summary manifest

/admin/command-permissions

• Per-command access policy editor for the selected server
• Modes: default, public, disabled, custom_roles
• Multi-select role dropdown by role name
• Manual role-ID entry fallback if catalog is incomplete

/admin/reddit-feeds

• Scoped to the selected server
• Add a subreddit feed using a subreddit name or Reddit /r/ URL
• Pick the target Discord text channel from a live dropdown
• Global Reddit polling interval dropdown (default every 30 minutes)
• Feed list shows enabled state, last checked time, last posted time, and last error
• New subscriptions baseline existing posts first, then only publish newer Reddit submissions

/admin/youtube

• Scoped to the selected server
• Add a YouTube channel URL and target Discord text channel
• Stores last seen video metadata so only newer uploads are posted
• Per-subscription enable/disable and delete controls

/admin/linkedin

• Scoped to the selected server
• Add a public LinkedIn profile URL and target Discord text channel
• Uses the public profile page to detect newer visible posts
• Stores last seen post metadata so only newer posts are announced
• Best-effort public-profile monitoring: private or login-gated activity will not be detected

/admin/beta-programs

• Scoped to the selected server
• Add the public GL.iNet beta-testing page monitor and target Discord text channel
• Detects when beta programs are added to or removed from the page
• Stores the last seen program snapshot per guild/channel so only changes are announced
• Best-effort public-page monitoring: if GL.iNet changes the page structure, the watcher may need adjustment

/admin/documentation

• Built-in documentation page inside the web GUI
• Presents operator guidance and shortcuts for bot administration topics

/admin/wiki

• Embedded wiki/documentation viewer in the web GUI
• Useful when the operator wants docs without leaving the admin interface

/admin/tag-responses

• JSON tag editor scoped to the selected server
• Save + runtime reload
• Dynamic slash refresh trigger (restart not required)

/admin/bulk-role-csv

• Scoped to the selected server
• CSV upload and target-role selection
• Assignment execution with timeout protections
• Structured results with unmatched/ambiguous/failure sections

/admin/users

• User and role management (Admin / Read-only / Glinet-Read-Only / Glinet-RW)
• User creation with password policy enforcement
• Admins can edit another web user's:
  • first name
  • last name
  • display name
  • email
• Admins can reset another web user's password from the same page
• Password visibility toggle in create/reset forms

/admin/bot-profile

• Read bot identity
• Update server nickname/listing label for the selected server using a guild-scoped form
• Rename bot username using a separate dedicated global form/action
• Upload avatar image

Rename/profile updates are admin-only and web-GUI-only (read-only users can view this page but cannot apply changes).

Scope notes:

• Guild-scoped:
  • /admin/dashboard
  • /admin/guild-settings
  • /admin/actions
  • /admin/member-activity
  • /admin/command-permissions
  • /admin/reddit-feeds
  • /admin/youtube
  • /admin/linkedin
  • /admin/tag-responses
  • /admin/bulk-role-csv
  • server nickname in /admin/bot-profile
• Global:
  • .env settings in /admin/settings
  • bot username/avatar in /admin/bot-profile
  • web users
  • logs and observability

Reverse Proxy Behavior

Recommended for production:

• Put web UI behind HTTPS reverse proxy
• Set WEB_PUBLIC_BASE_URL to exact external origin
• Keep WEB_TRUST_PROXY_HEADERS=true only for trusted proxy
• Keep CSRF and same-origin checks enabled

If behind proxy, ensure forwarded headers include:

• Host
• X-Forwarded-Host
• X-Forwarded-Proto
• X-Forwarded-For

Common Login Issues

• Blocked request due to origin policy.
  • WEB_PUBLIC_BASE_URL mismatch with browser origin
  • missing/incorrect forwarded host headers
• Login loops back to login page
  • session secret/cookie settings issue
  • HTTPS mismatch when secure cookies enabled
• Proxy-only login failure
  • check trusted proxy header forwarding and origin alignment

Browser/Accessibility Notes

• Password field uses autocomplete="current-password"
• Labels are explicitly associated with form controls (for + id)
• Inputs are styled to consistent size/shape for usability

Environment Variables (Web)

• WEB_ENABLED
• WEB_BIND_HOST
• WEB_PORT
• WEB_HTTP_PUBLISH
• WEB_HTTPS_PUBLISH
• LOG_HARDEN_FILE_PERMISSIONS
• WEB_SESSION_TIMEOUT_MINUTES
• WEB_PUBLIC_BASE_URL
• WEB_ENV_FILE
• WEB_RESTART_ENABLED
• WEB_GITHUB_WIKI_URL
• WEB_ADMIN_DEFAULT_USERNAME
• WEB_ADMIN_DEFAULT_PASSWORD
• WEB_ADMIN_SESSION_SECRET
• WEB_SESSION_COOKIE_SECURE
• WEB_TRUST_PROXY_HEADERS
• WEB_ENFORCE_CSRF
• WEB_ENFORCE_SAME_ORIGIN_POSTS
• WEB_HARDEN_FILE_PERMISSIONS
• WEB_DISCORD_CATALOG_TTL_SECONDS
• WEB_DISCORD_CATALOG_FETCH_TIMEOUT_SECONDS
• WEB_BULK_ASSIGN_TIMEOUT_SECONDS
• WEB_BULK_ASSIGN_MAX_UPLOAD_BYTES
• WEB_BULK_ASSIGN_REPORT_LIST_LIMIT
• WEB_BOT_PROFILE_TIMEOUT_SECONDS
• WEB_AVATAR_MAX_UPLOAD_BYTES
• MANAGED_GUILD_IDS
• ENABLE_MEMBERS_INTENT
• COMMAND_RESPONSES_EPHEMERAL
• PUPPY_IMAGE_API_URL
• PUPPY_IMAGE_TIMEOUT_SECONDS
• SHORTENER_ENABLED
• SHORTENER_BASE_URL
• SHORTENER_TIMEOUT_SECONDS
• YOUTUBE_NOTIFY_ENABLED
• YOUTUBE_POLL_INTERVAL_SECONDS
• YOUTUBE_REQUEST_TIMEOUT_SECONDS
• UPTIME_STATUS_ENABLED
• UPTIME_STATUS_PAGE_URL
• UPTIME_STATUS_TIMEOUT_SECONDS

Related Pages

• Reverse Proxy Web GUI
• Environment Variables
• Security Hardening
