n8n-agentic

n8n with AI coding agent integration. This fork adds a chat sidebar and "Fix with vibe8n" button to help you build and debug workflows.

What's This?

Two UI additions to n8n:

1. "vibe8n" button - Opens AI agent chat sidebar
2. "Fix with vibe8n" - Auto-debug button in error dialogs

The agent can list workflows, execute them, help debug errors, and answer questions about n8n.

Quick Start

1. Install and Build

git clone https://github.com/guillaumegay13/n8n-agentic.git
cd n8n-agentic
pnpm install
pnpm build > build.log 2>&1

2. Choose Your Agent Backend

Option A: Use Hosted vibe8n API (easiest)

1. Set the API URL:

export VITE_MCP_AGENT_API_URL='https://api.vibe8n.io'

2. Expose your local n8n with a tunnel (required for cloud agent):

   The built-in n8n tunnel (hooks.n8n.cloud) does not work because it blocks API access. You must use a full tunnel like ngrok.

   • Install ngrok: brew install ngrok/ngrok/ngrok (or download from ngrok.com)

   • Start the tunnel:

     ngrok http 5678

   • Copy the generated URL (e.g., https://your-name.ngrok-free.app).

   • When you open the vibe8n Agent Sidebar in the UI (after step 3 below), paste this URL into the sidebar to configure the agent's connection.

3. Start the n8n frontend:

pnpm --filter n8n-editor-ui serve

Open http://localhost:5678, click the "vibe8n" button, and sign up for an API key if prompted.

Option B: Run Example Agent (Self-Hosted)

This runs everything locally, so no tunnel is needed.

# In examples/ directory
cd examples
pip install -r requirements.txt

# Configure (create .env with your settings)
export ANTHROPIC_API_KEY=sk-ant-...
export MCP_SERVER_COMMAND=npx
export MCP_SERVER_ARGS=n8n-mcp
export MCP_SERVER_ENV_N8N_API_URL=http://localhost:5678
export MCP_SERVER_ENV_N8N_API_KEY=your-key

# Start simple agent
python simple_agent.py

# In another terminal, start n8n frontend
export VITE_MCP_AGENT_API_URL='http://localhost:8000'
pnpm --filter n8n-editor-ui serve

See examples/README.md for details on the reference implementation.

Option C: Build Your Own Agent

See "Building Your Own Agent" section below for API contract details.

3. Test It

1. Click the "vibe8n" button (lower-right corner)
2. Send a message: List my workflows
3. The agent responds with your n8n workflows

Authentication

The vibe8n panel uses smart authentication that adapts based on the API URL:

Cloud (vibe8n.io):

• Authentication is always required (cannot be bypassed for security)
• Users sign up with email to receive an API key
• Keys are stored in browser localStorage and sent via Authorization: Bearer header

Self-hosted (localhost, custom domains):

• Authentication is optional - disabled by default for easy local development
• No signup required - works immediately out-of-the-box
• Set VITE_MCP_AGENT_REQUIRE_AUTH=true to enable email signup for your self-hosted instance

Example - Enable auth for self-hosted:

export VITE_MCP_AGENT_API_URL='https://my-agent.example.com'
export VITE_MCP_AGENT_REQUIRE_AUTH=true
pnpm --filter n8n-editor-ui serve

Switching Between Hosted and Local

Just change the environment variable before starting the frontend:

# Use hosted API
export VITE_MCP_AGENT_API_URL='https://api.vibe8n.io'

# OR use local agent
export VITE_MCP_AGENT_API_URL='http://localhost:8000'

# Then start frontend
pnpm --filter n8n-editor-ui serve

Pro Tip: Create shell aliases:

# Add to ~/.bashrc or ~/.zshrc
alias n8n-hosted='export VITE_MCP_AGENT_API_URL="https://api.vibe8n.io" && pnpm --filter n8n-editor-ui serve'
alias n8n-local='export VITE_MCP_AGENT_API_URL="http://localhost:8000" && pnpm --filter n8n-editor-ui serve'

Building Your Own Agent

The vibe8n panel is agent-agnostic - it works with any backend that implements the /chat API contract.

Quick Start: Use the Example Agent

We provide a minimal reference implementation in examples/simple_agent.py:

• ~400 lines of Python
• Connects to any MCP server (n8n-mcp, filesystem, GitHub, etc.)
• No auth, no billing, no database - pure protocol demo
• Perfect starting point for customization

See examples/README.md for setup instructions.

Building From Scratch

Want to build a custom agent? You need an HTTP API with one endpoint:

Required: POST /chat

Request:

{
  "prompt": "User's message",
  "session_id": "optional-session-id"
}

Response:

{
  "session_id": "session-id",
  "events": [
    {
      "type": "assistant_message",
      "content": "Your response here",
      "metadata": {}
    }
  ],
  "final": "Your response here"
}

Event Types

• assistant_message - Final response (required)
• tool_call - When calling a tool (e.g., "list_workflows")
• tool_result - Tool execution result
• thought - Agent's reasoning steps
• system_notice - Status updates

UI Components

The integration adds these files to n8n:

• Sidebar: packages/frontend/editor-ui/src/components/McpAgent/
  • McpAgentSidebar.vue - Chat interface
  • McpAgentFloatingButton.vue - "vibe8n" button
• Store: packages/frontend/editor-ui/src/stores/mcpAgent.store.ts
• Error Button: packages/frontend/editor-ui/src/components/Error/NodeErrorView.vue

Environment Variables:

• VITE_MCP_AGENT_API_URL - Agent API endpoint (defaults to http://localhost:8000)
• VITE_MCP_AGENT_REQUIRE_AUTH - Enable authentication for self-hosted setups (defaults to false for localhost, always true for vibe8n.io)
• VITE_MCP_AGENT_API_TOKEN - Optional static auth token for simple token-based auth

Features

Agent Sidebar

• Natural language workflow operations
• Real-time "thinking timeline" (tool calls, reasoning steps)
• Session persistence across requests
• User authentication with API keys

Fix with vibe8n Button

• Appears in error dialogs when nodes fail
• Automatically includes:
  • Workflow/execution IDs
  • Node config and error details
  • Stack traces and input data
• Opens sidebar with pre-filled diagnostic prompt

Event Streaming (Optional)

If your agent implements GET /sessions/:id/events (Server-Sent Events), the UI shows real-time updates as the agent thinks and works.

Troubleshooting

Connection Issues: Cloud Agent vs. Localhost n8n

If you are using the Cloud Agent (https://api.vibe8n.io) and your n8n is running locally (http://localhost:5678), you might see errors like:

"n8n instance is not accessible" or "Network Error"

Reason: The Cloud Agent running on our servers cannot see your localhost.

Solution: You must expose your local n8n to the internet using a tunnel.

Note: Do not use pnpm run start:tunnel (hooks.n8n.cloud) as it blocks API access. Use ngrok instead:

1. Install & start ngrok:

   ngrok http 5678

2. Copy the generated URL (e.g., https://your-name.ngrok-free.app).
3. Paste this URL into the vibe8n Agent Sidebar.

Alternatively, use a self-hosted agent (see "Option B" in Quick Start) which can connect to localhost.

Button doesn't appear:

• Set VITE_MCP_AGENT_API_URL before starting frontend
• Restart dev server: Ctrl+C then pnpm --filter n8n-editor-ui serve

CORS errors: Add CORS middleware to your agent (see example above)

Local agent won't start:

# Check database is running
docker-compose ps

# Check Python dependencies
pip install -r requirements.txt

# Check n8n is accessible
curl http://localhost:5678/healthz

Connection refused:

• Verify agent is running: curl http://localhost:8000/health
• Check the URL matches: echo $VITE_MCP_AGENT_API_URL

Development

Making UI Changes

Edit files in packages/frontend/editor-ui/src/components/McpAgent/ - changes hot-reload automatically.

Adding Event Types

1. Edit mcpAgent.store.ts:

type McpAgentEventType = 'assistant_message' | 'tool_call' | 'your_new_type';

2. Update summariseEvent() function to handle the new type

3. Emit from your agent backend

Testing

# Frontend tests
cd packages/frontend/editor-ui
pnpm test

# Lint and typecheck
pnpm lint && pnpm typecheck

Deployment

Build for production:

export VITE_MCP_AGENT_API_URL='https://api.vibe8n.io'
pnpm build

Deploy packages/frontend/editor-ui/dist/ to your hosting platform.

License

Inherits n8n's Sustainable Use License.

The vibe8n Agent API is a separate service.

Support

• UI Issues: https://github.com/guillaumegay13/n8n-agentic/issues
• vibe8n API: guillaume.gay@protonmail.com

---

Quick Commands Reference:

# Use hosted vibe8n API
export VITE_MCP_AGENT_API_URL='https://api.vibe8n.com'
pnpm --filter n8n-editor-ui serve

# Use your custom agent
export VITE_MCP_AGENT_API_URL='http://localhost:8000'
pnpm --filter n8n-editor-ui serve

# Test custom agent API
curl http://localhost:8000/health
curl -X POST http://localhost:8000/chat -H "Content-Type: application/json" -d '{"prompt":"Hello"}'
