Add index_options to semantic_text field mappings #119967

kderusso · 2025-01-10T16:15:38Z

Adds index_options support for semantic_text fields using dense models.

Example:

PUT _inference/text_embedding/my-e5-model
{
  "service": "elasticsearch",
  "service_settings": {
    "num_allocations": 1,
    "num_threads": 1,
    "model_id": ".multilingual-e5-small"
  }
}

PUT my-semantic-index
{
  "mappings": {
    "properties": {
      "inference_field": {
        "type": "semantic_text",
        "inference_id": "my-e5-model",
        "index_options": {
          "dense_vector": {
            "type": "bbq_hnsw",
            "ef_construction": 100
           }
        }
      }
    }
  }
}

elasticsearchmachine · 2025-01-10T16:38:05Z

Hi @kderusso, I've created a changelog YAML for you.

elasticsearchmachine · 2025-01-10T16:39:12Z

Pinging @elastic/es-search-relevance (Team:Search Relevance)

elasticsearchmachine · 2025-01-10T16:39:12Z

Pinging @elastic/search-eng (Team:SearchOrg)

elasticsearchmachine · 2025-01-10T16:39:12Z

Pinging @elastic/search-relevance (Team:Search - Relevance)

Mikep86

Good start to this! I have a bunch of comments, but they're mostly interrelated, so it's not as much as it seems.

docs/changelog/119967.yaml

docs/reference/mapping/types/semantic-text.asciidoc

...ugin/inference/src/main/java/org/elasticsearch/xpack/inference/mapper/SemanticTextField.java

...e/src/yamlRestTest/resources/rest-api-spec/test/inference/10_semantic_text_field_mapping.yml

...ugin/inference/src/main/java/org/elasticsearch/xpack/inference/mapper/SemanticTextField.java

This reverts commit b08e2a1.

This reverts commit aedfafe.

jimczi

I left one comment regarding validation but this feels very close @kderusso !

...nference/src/main/java/org/elasticsearch/xpack/inference/mapper/SemanticTextFieldMapper.java

github-actions · 2025-06-17T11:57:54Z

🔍 Preview links for changed docs:

docs/reference/elasticsearch/mapping-reference/semantic-text.md

🔔 The preview site may take up to 3 minutes to finish building. These links will become live once it completes.

Samiul-TheSoccerFan

Nice implementation and tests, left a few nitpick comments.

docs/changelog/119967.yaml

...nce/src/test/java/org/elasticsearch/xpack/inference/mapper/SemanticTextFieldMapperTests.java

jimczi

elasticsearchmachine · 2025-06-17T19:02:55Z

💔 Backport failed

Status	Branch	Result
❌	8.19	Commit could not be cherrypicked due to conflicts

You can use sqren/backport to manually backport by running backport --upstream elastic/elasticsearch --pr 119967

* Add index_options parameter to semantic_text field mapping * Cleanup & tests * Update docs * Update docs/changelog/119967.yaml * Addressed some PR feedbak * Update yaml tests * Refactoring * Cleanup * Fix some tests * Hack in inferring text_embedding task type from index options * [CI] Auto commit changes from spotless * Fix error inferring model settings * Update docs * Update tests * Update docs/reference/mapping/types/semantic-text.asciidoc Co-authored-by: Mike Pellegrini <[email protected]> * Address some minor PR feedback * Remove partial model_settings with inferred task type * Cleanup * Remove unnecessary changes * Fix errors from merge * [CI] Auto commit changes from spotless * Cleanup * Checkpoint, saving changes before merge * Update parsing * [CI] Auto commit changes from spotless * Stash changes * Fix compile errors * [CI] Auto commit changes from spotless * Cleanup error * fix test * fix test * Fix another test * A bit of cleanup * Fix tests * Spotless * Respect index options if set over defaults * Cleanup * [CI] Auto commit changes from spotless * Support updating to compatible versions, add some cleanup and validation * Remove test that can't be done here - needs to be unit test * Add validation * Cleanup * Fix some yaml tests * [CI] Auto commit changes from spotless * Happy path early index validation works now; edge cases surrounding default BBQ remain * Always emit index options, even when using defaults * Minor cleanup * Fix test compilation failures * Fix some tests * Continue to iterate on test failures * Remove index options from inference field metadata as it is only needed at field creation time * Fix some tests * Remove transport version, no longer needed * Fix yaml tests * Add tests * IndexOptions don't need to implement Writeable * [CI] Auto commit changes from spotless * Refactor - move SemanticTextIndexOptions * Remove writeable * Move index_options parsing to semantic text field mapper * Cleanup * Fix test compilation issue * Cleanup * Remove whitespace * Remove writeables from index options * Disable merging null options? * Add docs * [CI] Auto commit changes from spotless * Revert "Disable merging null options?" This reverts commit 2ef8b1d. * Remove default serialization * Include default index option type to defaults * [CI] Auto commit changes from spotless * Go back to allowing null updateS * Cleanup * Fix validation error * Revert "Include default index option type to defaults" This reverts commit b08e2a1. * Update tests * Revert "Update tests" This reverts commit aedfafe. * Better fix for null inputs * Remove redundant merge validation --------- Co-authored-by: elasticsearchmachine <[email protected]> Co-authored-by: Mike Pellegrini <[email protected]> (cherry picked from commit 813814b) # Conflicts: # docs/reference/elasticsearch/mapping-reference/semantic-text.md # server/src/main/java/org/elasticsearch/index/mapper/vectors/DenseVectorFieldMapper.java # x-pack/plugin/inference/src/main/java/org/elasticsearch/xpack/inference/mapper/SemanticTextFieldMapper.java # x-pack/plugin/inference/src/test/java/org/elasticsearch/xpack/inference/mapper/SemanticTextFieldMapperTests.java

kderusso · 2025-06-17T19:18:31Z

💚 All backports created successfully

Status	Branch	Result
✅	8.19

Questions ?

Please refer to the Backport tool documentation

kderusso · 2025-06-18T12:04:25Z

Had to create a manual backport: #129626

…129626) * Add index_options to semantic_text field mappings (#119967) * Add index_options parameter to semantic_text field mapping * Cleanup & tests * Update docs * Update docs/changelog/119967.yaml * Addressed some PR feedbak * Update yaml tests * Refactoring * Cleanup * Fix some tests * Hack in inferring text_embedding task type from index options * [CI] Auto commit changes from spotless * Fix error inferring model settings * Update docs * Update tests * Update docs/reference/mapping/types/semantic-text.asciidoc Co-authored-by: Mike Pellegrini <[email protected]> * Address some minor PR feedback * Remove partial model_settings with inferred task type * Cleanup * Remove unnecessary changes * Fix errors from merge * [CI] Auto commit changes from spotless * Cleanup * Checkpoint, saving changes before merge * Update parsing * [CI] Auto commit changes from spotless * Stash changes * Fix compile errors * [CI] Auto commit changes from spotless * Cleanup error * fix test * fix test * Fix another test * A bit of cleanup * Fix tests * Spotless * Respect index options if set over defaults * Cleanup * [CI] Auto commit changes from spotless * Support updating to compatible versions, add some cleanup and validation * Remove test that can't be done here - needs to be unit test * Add validation * Cleanup * Fix some yaml tests * [CI] Auto commit changes from spotless * Happy path early index validation works now; edge cases surrounding default BBQ remain * Always emit index options, even when using defaults * Minor cleanup * Fix test compilation failures * Fix some tests * Continue to iterate on test failures * Remove index options from inference field metadata as it is only needed at field creation time * Fix some tests * Remove transport version, no longer needed * Fix yaml tests * Add tests * IndexOptions don't need to implement Writeable * [CI] Auto commit changes from spotless * Refactor - move SemanticTextIndexOptions * Remove writeable * Move index_options parsing to semantic text field mapper * Cleanup * Fix test compilation issue * Cleanup * Remove whitespace * Remove writeables from index options * Disable merging null options? * Add docs * [CI] Auto commit changes from spotless * Revert "Disable merging null options?" This reverts commit 2ef8b1d. * Remove default serialization * Include default index option type to defaults * [CI] Auto commit changes from spotless * Go back to allowing null updateS * Cleanup * Fix validation error * Revert "Include default index option type to defaults" This reverts commit b08e2a1. * Update tests * Revert "Update tests" This reverts commit aedfafe. * Better fix for null inputs * Remove redundant merge validation --------- Co-authored-by: elasticsearchmachine <[email protected]> Co-authored-by: Mike Pellegrini <[email protected]> (cherry picked from commit 813814b) # Conflicts: # docs/reference/elasticsearch/mapping-reference/semantic-text.md # server/src/main/java/org/elasticsearch/index/mapper/vectors/DenseVectorFieldMapper.java # x-pack/plugin/inference/src/main/java/org/elasticsearch/xpack/inference/mapper/SemanticTextFieldMapper.java # x-pack/plugin/inference/src/test/java/org/elasticsearch/xpack/inference/mapper/SemanticTextFieldMapperTests.java * Fix errors in backport merge
