C# Asynchronous Programming Full Tutorial : Async / Await / Task and Deadlock Fix by ConfigureAwait

Full tutorial link > https://www.youtube.com/watch?v=I4cnX_odC1M

C# Asynchronous Programming Full Tutorial : Async / Await / Task and Deadlock Fix by ConfigureAwait

image Hits Patreon BuyMeACoffee Furkan Gözükara Medium Codio Furkan Gözükara Medium

YouTube Channel Furkan Gözükara LinkedIn Udemy Twitter Follow Furkan Gözükara

In this lecture video, I am going to explain #asynchronous #programming concepts when using .NET Core 7 with C# #programming language. I will code a #WPF application to demonstrate #Async, #Await, #ConfigureAwait, and #Task concepts while doing asynchronous coding. I will show how ConfigureAwait is important to prevent deadlocks while using "async" and "await" keywords.

The code repository of this lecture :

https://github.com/FurkanGozukara/C-Async-Await-Task-Deadlock-Fix-by-ConfigureAwait-Full-Tutorial-Asynchronous-Programming

Moreover, we cover the following #howto topics:

  • How to do asynchronous programming with C# and .NET

  • How to use Async, Await and ConfigureAwait

  • How to use Task, Task.Wait and ContinueWith

  • How to utilize Dispatcher.BeginInvoke to update UI elements from different tasks, sub-tasks, threads

  • How to utilize Thread.CurrentThread.ManagedThreadId to see which code is executed in which thread

  • How to download source of a web page / URL asynchronously and properly with using HttpClient and Content.ReadAsStringAsync

00:00:00 Introduction Task, Async, Await and composing the demo application

00:02:18 Generating Async deadlock causing example

00:08:03 How to see thread IDs during the runtime

00:11:47 How to fix deadlock

00:13:50 How to use ConfigureAwait properly

00:14:48 How to make UI responsive with proper Async Await usage

00:17:09 How to make async but main thread blocking code with TaskFactory.StartNew and Task.Wait

00:20:52 How to make fully asynchronous and non-blocking UI with TaskFactory and ContinueWith

00:23:36 How to update UI thread from sub-thread with Dispatcher

We have manually corrected the subtitles for the video so watch the tutorial with subtitles on if you have a hard time understand

Please join Our Discord server for asking questions and have discussions: https://discord.gg/rfttctFewW

Please follow us on Twitter: https://twitter.com/SECourses

Please follow us on Facebook: https://www.facebook.com/OfficialSECourses

If you are interested in programming our playlists will teach you how to program and code from scratch: https://www.youtube.com/c/SECourses/playlists

[1] Introduction to Programming Full Course with C# playlist

[2] Advanced Programming with C# Full Course Playlist

[3] Object Oriented Programming Full Course with C# playlist

[4] Asp #NETCore V5 - MVC Pattern - Bootstrap V5 - Responsive Web Programming with C# Full Course Playlist

[5] Artificial Intelligence (AI) and Machine Learning (ML) Full Course with C# Examples playlist

[6] Software Engineering Full Course playlist

[7] Security of Information Systems Full Course playlist

Thumbnail: Freepik (@fullvector) - Data processing, software program development, code review, database concept. #dotnet #dotnet7 #csharp

Video Transcription

  • 00:00:00 Hello everyone. I am Dr. Furkan Gözükara. In this  lecture video, I am going to explain asynchronous

  • 00:00:07 programming concepts when using .NET Core 7 with  C-Sharp programming language. I will code a WPF

  • 00:00:14 application to demonstrate async, await, configure  await and task concepts while doing asynchronous

  • 00:00:21 coding. I will show how ConfigureAwait is  important to prevent deadlocks while using

  • 00:00:27 async and await keywords. Let's start coding  with composing a .NET Core 7 WPF application.

  • 00:00:33 If your Visual Studio is lacking .NET Core 7,  just download latest Visual Studio Community

  • 00:00:39 Edition and update it to the latest version. Here  let me show you how to update your Visual Studio.

  • 00:01:01 As you can see, my Visual Studio is up  to date. Its version is 17.4.1. Okay,

  • 00:01:08 so let's start composing our WPF project.  I am going to pick WPF application. You

  • 00:01:15 can also look for it with searching WPF. And  then you see there is ASP.NET Core WPF app.

  • 00:01:24 Then click next. Okay, it will  be in my desktop. Let's say

  • 00:01:32 async programming. I am going to pick .NET  7 and this is .NET Core web app. Let's fix

  • 00:01:41 it quickly. Okay, here WPF application  and it is with .NET Core. Okay, next.

  • 00:01:53 You see it says that there is WPF  application. Okay .NET Core 7.

  • 00:02:06 Okay, application is started now. The  interface is loaded. So let's start

  • 00:02:14 with generating a button control. First I will  show you how a deadlock can happen when we are

  • 00:02:23 doing asynchronous programming with async and  await keywords. Let's say test async deadlock.

  • 00:02:42 Okay and with double clicking it I  am going to compose click event here.

  • 00:02:49 Okay, so let's assume that we have an  async method that will return a string.

  • 00:02:57 Let's say return source code of  a web page as a string. Okay.

  • 00:03:18 I will use HTTP client.

  • 00:03:24 Okay and inside here we will use.

  • 00:03:34 We will use HTTP response.

  • 00:03:40 Okay. Sorry not not necessarily we need that.

  • 00:03:56 You see it has suggested me to auto complete is  like this and it's correct. And we will return.

  • 00:04:09 Response request. Content. Okay,  then let's see. Okay, like this.

  • 00:04:24 All right. However, since this is asynchronous  with async keyword. We need to say await here.

  • 00:04:34 And since this is an async method, we can't just  return it like this. We have to return a task

  • 00:04:43 like this. Okay. And let's add a label or a text

  • 00:04:49 block to display source code.  I'm going to pick a text block.

  • 00:04:57 Okay, let's name it as block source code.

  • 00:05:05 Okay, I have named it as txt block source code.

  • 00:05:10 Then let's assign text of txt block  source code equal to return source code of

  • 00:05:21 my developed web game web based game, which  is HTTPS www monsters MMORPG.com. Okay.

  • 00:05:33 However, to access result of async method, we  have to get result. So what does this async do?

  • 00:05:45 Async means that that method is asynchronous and  it will not block the thread that it is executed.

  • 00:05:58 However, to get its result,  I need to use await keyword.

  • 00:06:04 And when you use await keyword, then  you don't need to access it by result.

  • 00:06:12 So when I run this code, what will happen? Let's  see. Let's run and run our application and see.

  • 00:06:26 Okay, I am clicking it and you see it has returned  the result as expected. Because because there is a

  • 00:06:39 key issue here, you see my button click is now  also asynchronous. However, if I don't want to

  • 00:06:48 make it asynchronous, then I need to return  async keyword here that the Visual Studio

  • 00:06:54 did put automatically and I need to use result  like this. Okay, let's see now what happens.

  • 00:07:06 Okay, I'm clicking and my application  is completely frozen. Do you know why?

  • 00:07:13 Because currently the UI thread  is blocked. The reason is that UI

  • 00:07:20 thread is waiting to waiting the result  of this method call and this method call

  • 00:07:28 is not able to execute because the UI thread is  already frozen. So how can I solve this problem?

  • 00:07:40 So for solving this problem, I can use configure  await. So when you set configure await false

  • 00:07:49 on an async method, this means that this  method can now run on a different thread.

  • 00:07:59 Okay, so to see the thread IDs that each method  is running, let's use managed thread ID code.

  • 00:08:11 Okay, let's write it to our  output window with thread.

  • 00:08:23 Okay, current thread manage thread  ID. Okay, so it says that thread is

  • 00:08:27 not existing in the current context  for that I am adding using threads.

  • 00:08:34 Okay, so this will print the thread ID of the  thread that this line is executed. Then let's

  • 00:08:42 also see the thread ID here. Let's also  add some extra information as the inside

  • 00:08:54 here. Then let's also write it as like  this inside here. And then one second.

  • 00:09:08 Okay, inside the first using statement inside  using HTTP client and inside here. Okay, so

  • 00:09:28 first, let's run it without configure,  await and see which output we are getting.

  • 00:09:40 Okay, let's check out the output window. So, okay,  we see that inside btnTestAsyncDeadLock_Click,

  • 00:09:51 which is here, the thread ID is one. It is  expected because we are currently inside

  • 00:09:58 the main UI thread, and it is one and in the  source code. So it has entered here, we are

  • 00:10:06 still inside thread ID one. And then we have  entered here as well inside using HTTP client.

  • 00:10:16 However, since we are doing await here,  now it becomes asynchronous call and it

  • 00:10:27 locks our execution. And you see we didn't  enter inside here because the UI thread is

  • 00:10:37 now awaiting that response. So the main  thread is UI thread is locked, frozen.

  • 00:10:46 And this execution is waiting that thread to be  released. Okay, so when I add this execution,

  • 00:11:00 configure await as false. Now let's see  how to output. Let's see the output again.

  • 00:11:11 Okay, the button is still frozen because it is  not anymore asynchronous. However, now we can

  • 00:11:17 see inside using response. You see inside here now  running in a different thread and the thread ID is

  • 00:11:24 six. Okay, so this is where configure await is  very useful because when you set ConfigureAwait

  • 00:11:36 false, then that asynchronous method call becomes,  starts running in a different thread. Okay,

  • 00:11:48 so if we don't want the interface to be  frozen, let's copy and paste this button.

  • 00:11:54 And let's say btn test proper async  code. Okay, proper async code.

  • 00:12:05 Okay, so this will cause a deadlock,  so I'm going to delete this.

  • 00:12:13 All right. Oh, we don't need that actually.  So this is return source code with

  • 00:12:23 or let's say let's add an option here.  Bool cause deadlock equal to false. Okay.

  • 00:12:37 Okay, so if you don't want to cause deadlock,  then configure await. Then I need to

  • 00:12:46 give opposite of this. So by default it will  cause a deadlock and to cause a deadlock. We need

  • 00:12:54 to give configure await true. Okay. Maybe this  make make you confused. So let's say bl configure

  • 00:13:06 await by default. Let's make it  false so it won't cause a deadlock.

  • 00:13:13 Okay, now it won't cause a deadlock. So to cause  a deadlock, I need to provide it true. Okay. Yes,

  • 00:13:25 now it will cause a deadlock. Let's try. Okay,  so you see we are never getting inside here.

  • 00:13:36 So now it is deadlocked because main thread the  UI thread is awaiting the result and the result

  • 00:13:45 is awaiting main thread UI thread to be released  to run. Okay, so each one is awaiting each one

  • 00:13:54 and it causes a deadlock. All right, so let's  make this as none that's locking or let's say

  • 00:14:07 configure await asynchronous code. Okay,  I need to change its click event. We can

  • 00:14:18 configure await async code. Okay. This time we  are just going to run it with false and let's try.

  • 00:14:36 Okay, still, the interface is frozen during  the runtime because this button click is not

  • 00:14:42 asynchronous. However, it is not that locked.  Okay. And let's also add another button, which

  • 00:14:52 will be responsive. We can responsive. Okay, async  click. Let's say it as responsive async click.

  • 00:15:08 Okay, and I need to generate a new click event.  Okay, so I'm going to mark this method as async

  • 00:15:20 and I can also let Visual Studio to mark  it as async automatically with await.

  • 00:15:30 Okay, now you see it is  automatically marked as async. Okay,

  • 00:15:38 now in this case, it will not freeze the  interface. Let's try. Okay, let's try again.

  • 00:15:49 Okay, the interface is not freezing. However,  meanwhile, the text block is getting updated.

  • 00:15:56 During that time, the interface will freeze,  of course, because it is getting updated.

  • 00:16:02 And since source code is pretty big,  it is not displayed entirely here.

  • 00:16:09 It takes some time. Actually, maybe we can  fix it with. Okay. I don't know. Let's see.

  • 00:16:19 Max with max height, for example, let's  say 6000 and let's see what happens.

  • 00:16:28 Okay, probably we need to add scroll bars.  Let's see horizontal alignment. No scroll,

  • 00:16:37 scroll bar. Okay, scroll. No. Okay, anyway, it is  not important for this lecture. And there is one

  • 00:16:48 another methodology, one more method, actually  two more methodology. So let's also see them.

  • 00:16:54 I'm going to expand this a  little bit more. Why? Okay,

  • 00:17:07 here. Okay. Now I will use task  methodology. Okay, so btnTaskExample.

  • 00:17:17 I will call this as task version one. Okay, and  let's generate this click event. So this time I

  • 00:17:28 will start this code inside or let's say as a task  task. Let's say var task = Task.Factory.StartNew.

  • 00:17:42 Okay. It automatically completes. Very  nice. And let's call it like this.

  • 00:17:50 And by the way, still this is a async  method. So I need to call await.

  • 00:17:59 And I need to assign this into a string  variable. Let's say string source.

  • 00:18:10 Like this. And let's say the source  is equal to await.result. Okay. Okay.

  • 00:18:24 I need to provide the source code, of course.  I mean the URL. All right. And no result. Okay.

  • 00:18:34 And then what do I need to do is. I can do  task.wait. This will make it synchronous.

  • 00:18:45 And then I can assign the source like this.  Okay. It says that this can be null here. So

  • 00:18:57 let's initialize it like this. All right.  You see, it is still pretty responsive.

  • 00:19:08 But we never get the result. So in this  case. We need to set configure await true.

  • 00:19:20 Otherwise it will return from that asynchronous  and the task wait will never work. I suppose.

  • 00:19:28 Let's try. Yes, we did enter inside the request.  Okay. All right. This is the sound of my girl.

  • 00:19:42 Okay, we do. We do enter inside the request.  However, it is obvious that the source code

  • 00:19:52 is immediately executed without waiting. So  the task is completed immediately. Since we

  • 00:20:00 are doing an asynchronous call here. And  therefore, maybe we need to do. Let's see.

  • 00:20:11 Okay, we need to turn this asynchronous call into  a synchronous call because we are already spawning

  • 00:20:18 a new task. And here we just need to provide  or let's say, get result. Okay. And we need to

  • 00:20:28 remove the wait keyword. All right. Now, since  this will run inside a different thread than the

  • 00:20:37 main thread, then it won't cause any problem as  a deadlock. However, our interface will be still

  • 00:20:46 frozen. Let's try. Okay. It is working. Now let's  make another example of task with ContinueWith. So

  • 00:20:58 I will call this task as version two. Okay.  And let's say btn task version two. All right.

  • 00:21:11 Okay. Okay. So in this case, we are  going to use a different methodology as

  • 00:21:23 continue with. All right. And it says we need a  new action. Okay. Action. Okay. And. It says task.

  • 00:21:43 Okay, one moment. It is pretty simple, actually.  So we are going to call this T1 parameter,

  • 00:21:53 which will be when we hover it, we see that it  is task T1. So this means that it is the result

  • 00:21:59 of execution of this task. Okay. And inside that  we will have the result of the task. Therefore,

  • 00:22:10 I will assign. I don't need this  anymore. The text as equal to Ok.

  • 00:22:21 T1. Okay. Result. Okay. And I just need to  return the result of the inner execution. Okay.

  • 00:22:35 Now this is supposed to not block anything  and update the text block. Let's try. Okay.

  • 00:22:41 It is not block it. Okay. Inside is called. All  right. So we have a little bit. Another problem.

  • 00:22:51 Okay. Which is this is task return. Okay.  We are waiting it. We are locking it.

  • 00:22:59 So let's try. Maybe we didn't wait. Okay. We  did enter inside. Oh, we have a system invalid

  • 00:23:08 operation exception somewhere. Okay. Let's put  a break point here. Maybe our error is there.

  • 00:23:17 Okay. And. When we debug the result. Okay. The  result is there as well. Oh, I know the reason.

  • 00:23:26 I know the problem. The problem is we cannot  update the UI element inside another task. So

  • 00:23:37 I need to do use dispatcher.  Let's say begin invoke new action.

  • 00:23:45 And inside that I need to assign it. Okay. So you  see it defines a new action like this. And it's

  • 00:23:54 anonymous call because we don't get we don't  need any parameter. Actually, it is like here,

  • 00:24:00 as you can see. But this is empty action.  And yes, now it should work. Let's try.

  • 00:24:10 OK. All right. I have shown multiple ways to use  async and task to do asynchronous programming.

  • 00:24:22 I hope you have enjoyed. Please ask your questions  in the comments section. Hopefully see you

  • 00:24:30 in another video. Let me know through comment  section that what questions do you have? What

  • 00:24:39 topics do you wonder? What would you like to see  in my next video? OK. Hopefully see you later.

Clone this wiki locally
